    Lathe Tool Inserts for Multiple Materials

    Choose these premium carbide inserts to turn a variety of materials without changing out your tool. They’re made of higher-quality carbide than economy inserts, so they last longer and create a smoother finish. Install them into a matching holder. For the best performance, choose an insert designed for the material of your workpiece.
    Inserts with a larger nose angle and tip radius remove more material with each pass, but they cut less precisely than smaller inserts. Select the insert with the largest nose angle and tip radius that will turn your workpiece to the shape you want.
    CDHH (Diamond with 80° Nose Angle)—For CCBI, CCBM, CSBI, and CSBM Holders
    Image of Product. Front orientation. Lathe Tool Inserts. Lathe Tool Inserts for Multiple Materials, CDHH Insert.
    Image of Attribute. Front orientation. Contains Annotated. CDHH Insert.
    Image of Specification. Front orientation. Clear Plastic Case. Lathe Tool Inserts for Multiple Materials.

    Clear Plastic Case

    For Interrupted Cutting Conditions—Inserts for interrupted cutting conditions are best for workpieces that will come in and out of contact with the insert, such as hex bars.
    Individual—Inserts sold individually come packed in a clear plastic case to protect cutting edges during shipment.
    Package—Inserts sold in packages come factory sealed from the manufacturer for maximum traceability.
    Uncoated—Uncoated inserts are sharper than coated inserts, so they leave a better finish on softer metals, such as aluminum. They’re good for general purpose cutting and short production runs.
    Positive Rake Angle—Positive-rake inserts stick out in front of the holder to reach tight spaces on the workpiece. However, they only have cutting edges on one side.
    For Finishing Cutting Operation—Use finishing inserts at the end of your turning process to remove minimal material for a smooth surface finish.
    Chip Breakers—Inserts with chip breakers prevent long chips from forming, so they won’t block the flow of coolant or damage your tool.
    Individual
    Package
    Insert Code
    Finish
    IC
    Dia.
    Thk.
    Hole
    Dia.
    Cutting
    Edge Lg.
    Tip
    Radius
    Rake Angle
    Type
    For Cutting
    Operation
    Features
    Mfr.
    Includes
    Pkg.
    Qty.
    Pkg.
    Pkg.
    Qty.
    Pkg.
    For Use On Aluminum, Brass, Bronze, Cast Iron, Copper, Nickel, Stainless Steel, Steel, and Titanium

    For Interrupted Cutting Conditions
    CDHH-1.20.60.5Uncoated5/32"3/64"0.084"0.16"0.007"PositiveFinishingChip BreakersWidiaClear Plastic Case13867N61900000053867N631000000

    CDHH (Diamond with 80° Nose Angle)—For CCBI and CSBI Holders
    Image of Product. Front orientation. Lathe Tool Inserts. Lathe Tool Inserts for Multiple Materials, CDHH Insert.
    Image of Attribute. Front orientation. Contains Annotated. CDHH Insert.
    Image of Specification. Front orientation. Clear Plastic Case. Lathe Tool Inserts for Multiple Materials.

    Clear Plastic Case

    For Interrupted Cutting Conditions—Inserts for interrupted cutting conditions are best for workpieces that will come in and out of contact with the insert, such as hex bars.
    Individual—Inserts sold individually come packed in a clear plastic case to protect cutting edges during shipment.
    Package—Inserts sold in packages come factory sealed from the manufacturer for maximum traceability.
    Titanium Nitride (TiN) Coated—Titanium nitride (TiN) coated inserts create less friction than uncoated inserts, so they last longer when run at similar speeds.
    Positive Rake Angle—Positive-rake inserts stick out in front of the holder to reach tight spaces on the workpiece. However, they only have cutting edges on one side.
    For Finishing Cutting Operation—Use finishing inserts at the end of your turning process to remove minimal material for a smooth surface finish.
    Chip Breakers—Inserts with chip breakers prevent long chips from forming, so they won’t block the flow of coolant or damage your tool.
    Individual
    Package
    Insert Code
    Finish
    IC
    Dia.
    Thk.
    Hole
    Dia.
    Cutting
    Edge Lg.
    Tip
    Radius
    Rake Angle
    Type
    For Cutting
    Operation
    Coating Process
    Features
    Mfr.
    Includes
    Pkg.
    Qty.
    Pkg.
    Pkg.
    Qty.
    Pkg.
    For Use On Aluminum, Brass, Bronze, Cast Iron, Copper, Nickel, Stainless Steel, Steel, and Titanium

    For Interrupted Cutting Conditions
    CDHH-1.20.60.5Titanium Nitride (TiN) Coated5/32"3/64"0.084"0.16"0.007"PositiveFinishingPVD (Physical Vapor Deposition)Chip BreakersWidiaClear Plastic Case13315A51000000103315A2270000000


    Boring Lathe Tool Insert Holders

    Image of Product. Shown with Insert Installed. Front orientation. Lathe Tool Insert Holders. Boring Lathe Tool Insert Holders.

    Shown with Insert Installed

    Pair these holders with a carbide insert (not included) to enlarge existing holes to precise diameters. They’re made to ANSI standards. Face your lathe and use the direction the spindle rotates to choose an insert holder.
    CCBI Holders—For CDHB, CDHH Inserts
    Image of System. Front orientation. Exploded, ZoomedIn view. Contains Annotated. Lathe Tool Insert Holders. Boring Lathe Tool Insert Holders, CCBI Insert Holder.
    Image of Attribute. Front orientation. Contains Annotated. Lathe Tool Insert Holders. Boring Lathe Tool Insert Holders, CCBI Insert Holder.
    Right-Hand Cutting Direction—Use right-hand holders when the spindle of your lathe rotates counterclockwise.
    Carbide—Carbide holders are more rigid than steel holders, so they vibrate less and leave a smoother finish.
    Coolant Hole—Holders with a coolant hole deliver coolant through the holder from your lathe onto the workpiece to minimize heat.
    Holders
    Replacement
    Torx Screws
    Replacement
    Torx Keys
    For
    Insert
    Cutting
    Edge Angle
    Shank
    Dia.
    Min. Hole
    Dia.
    Max. Hole
    Dp.
    Overall
    Lg.
    IC
    Dia.
    Thk.
    Material
    Side
    End
    Features
    Mfr.
    Each
    Each
    Each
    Boring Cut

    Right-Hand Cutting Direction
    3/16"7/32"1 1/8"4"5/32"3/64"Carbide
    		5°5°Coolant HoleWidia1475N12100000003315A61000003315A6900000

    CSBI Holders—For CDHB, CDHH Inserts
    Image of System. Front orientation. Exploded, ZoomedIn view. Contains Annotated. Lathe Tool Insert Holders. Boring Lathe Tool Insert Holders, CSBI Insert Holder.
    Image of Attribute. Front orientation. Contains Annotated. Lathe Tool Insert Holders. Boring Lathe Tool Insert Holders, CSBI Insert Holder.
    Right-Hand Cutting Direction—Use right-hand holders when the spindle of your lathe rotates counterclockwise.
    Coolant Hole—Holders with a coolant hole deliver coolant through the holder from your lathe onto the workpiece to minimize heat.
    Holders
    Replacement
    Torx Screws
    Replacement
    Torx Keys
    For
    Insert
    Cutting
    Edge Angle
    Shank
    Dia.
    Min. Hole
    Dia.
    Max. Hole
    Dp.
    Overall
    Lg.
    IC
    Dia.
    Thk.
    Material
    Side
    End
    Features
    Mfr.
    Each
    Each
    Each
    Boring Cut

    Right-Hand Cutting Direction
    3/16"3/16"3/4"2 1/2"5/32"3/64"Steel
    		3°7°Coolant HoleWidia3315A1100000003315A61000003315A6900000
