Breathable Round Bellows with Cuff Ends
Sewn seams let these bellows breathe, so they retract quickly in fast-cycling applications. The seams will allow small amounts of moisture and dust to pass through. Slide these bellows over moving parts, such as rods and shafts, then secure the cuff ends with hose clamps (not included).
For technical drawings and 3-D models, click on a part number.
Length | |||||||||
|---|---|---|---|---|---|---|---|---|---|
| Extended | Retracted | Travel | Required ID Clearance | Cuff Lg. | Material | Material Thick. | Temp. Range, °F | Each | |
Protects Against Abrasive Grit, Coolant, Cutting Fluid, Dust, Metal Chips, Salt Water, Solvents, Synthetic Oil, Water, Wood Chips | |||||||||
3/4" ID × 3 1/4" OD | |||||||||
| 1 ft. | 3/4" | 11 1/4" | 3/16" | 1" | Neoprene-Coated Nylon Fabric | 0.022" | -60° to 250° | 0000000 | 000000 |
| 2 ft. | 1 1/2" | 22 1/2" | 3/16" | 1" | Neoprene-Coated Nylon Fabric | 0.022" | -60° to 250° | 0000000 | 000000 |
| 4 ft. | 3 1/2" | 44 1/2" | 3/16" | 1" | Neoprene-Coated Nylon Fabric | 0.022" | -60° to 250° | 0000000 | 000000 |
1" ID × 3 1/2" OD | |||||||||
| 1 ft. | 3/4" | 11 1/4" | 1/4" | 1" | Neoprene-Coated Nylon Fabric | 0.022" | -60° to 250° | 0000000 | 00000 |
| 2 ft. | 1 1/2" | 22 1/2" | 1/4" | 1" | Neoprene-Coated Nylon Fabric | 0.022" | -60° to 250° | 0000000 | 000000 |
| 4 ft. | 3 1/2" | 44 1/2" | 1/4" | 1" | Neoprene-Coated Nylon Fabric | 0.022" | -60° to 250° | 0000000 | 000000 |
1 1/4" ID × 3 3/4" OD | |||||||||
| 1 ft. | 3/4" | 11 1/4" | 1/4" | 1" | Neoprene-Coated Nylon Fabric | 0.022" | -60° to 250° | 0000000 | 00000 |
| 2 ft. | 1 1/2" | 22 1/2" | 1/4" | 1" | Neoprene-Coated Nylon Fabric | 0.022" | -60° to 250° | 0000000 | 000000 |
| 4 ft. | 3 1/2" | 44 1/2" | 1/4" | 1" | Neoprene-Coated Nylon Fabric | 0.022" | -60° to 250° | 0000000 | 000000 |
1 1/2" ID × 4" OD | |||||||||
| 1 ft. | 3/4" | 11 1/4" | 3/8" | 1" | Neoprene-Coated Nylon Fabric | 0.022" | -60° to 250° | 0000000 | 00000 |
| 2 ft. | 1 1/2" | 22 1/2" | 3/8" | 1" | Neoprene-Coated Nylon Fabric | 0.022" | -60° to 250° | 0000000 | 000000 |
| 4 ft. | 3 1/2" | 44 1/2" | 3/8" | 1" | Neoprene-Coated Nylon Fabric | 0.022" | -60° to 250° | 0000000 | 000000 |
1 3/4" ID × 4 1/4" OD | |||||||||
| 1 ft. | 3/4" | 11 1/4" | 3/8" | 1" | Neoprene-Coated Nylon Fabric | 0.022" | -60° to 250° | 0000000 | 00000 |
| 2 ft. | 1 1/2" | 22 1/2" | 3/8" | 1" | Neoprene-Coated Nylon Fabric | 0.022" | -60° to 250° | 0000000 | 000000 |
| 4 ft. | 3 1/2" | 44 1/2" | 3/8" | 1" | Neoprene-Coated Nylon Fabric | 0.022" | -60° to 250° | 0000000 | 000000 |
2" ID × 4 1/2" OD | |||||||||
| 1 ft. | 3/4" | 11 1/4" | 3/8" | 1" | Neoprene-Coated Nylon Fabric | 0.022" | -60° to 250° | 0000000 | 00000 |
| 2 ft. | 1 1/2" | 22 1/2" | 3/8" | 1" | Neoprene-Coated Nylon Fabric | 0.022" | -60° to 250° | 0000000 | 000000 |
| 4 ft. | 3 1/2" | 44 1/2" | 3/8" | 1" | Neoprene-Coated Nylon Fabric | 0.022" | -60° to 250° | 0000000 | 000000 |
2 1/4" ID × 4 3/4" OD | |||||||||
| 1 ft. | 3/4" | 11 1/4" | 3/8" | 1" | Neoprene-Coated Nylon Fabric | 0.022" | -60° to 250° | 0000000 | 00000 |
| 2 ft. | 1 1/2" | 22 1/2" | 3/8" | 1" | Neoprene-Coated Nylon Fabric | 0.022" | -60° to 250° | 0000000 | 000000 |
| 4 ft. | 3 1/2" | 44 1/2" | 3/8" | 1" | Neoprene-Coated Nylon Fabric | 0.022" | -60° to 250° | 0000000 | 000000 |
2 3/4" ID × 5 1/4" OD | |||||||||
| 1 ft. | 3/4" | 11 1/4" | 3/8" | 1" | Neoprene-Coated Nylon Fabric | 0.022" | -60° to 250° | 0000000 | 000000 |
| 2 ft. | 1 1/2" | 22 1/2" | 3/8" | 1" | Neoprene-Coated Nylon Fabric | 0.022" | -60° to 250° | 0000000 | 000000 |
| 4 ft. | 3 1/2" | 44 1/2" | 3/8" | 1" | Neoprene-Coated Nylon Fabric | 0.022" | -60° to 250° | 0000000 | 000000 |
3 1/4" ID × 5 3/4" OD | |||||||||
| 1 ft. | 3/4" | 11 1/4" | 3/8" | 1" | Neoprene-Coated Nylon Fabric | 0.022" | -60° to 250° | 0000000 | 000000 |
| 2 ft. | 1 1/2" | 22 1/2" | 3/8" | 1" | Neoprene-Coated Nylon Fabric | 0.022" | -60° to 250° | 0000000 | 000000 |
| 4 ft. | 3 1/2" | 44 1/2" | 3/8" | 1" | Neoprene-Coated Nylon Fabric | 0.022" | -60° to 250° | 0000000 | 000000 |
4 1/4" ID × 6 3/4" OD | |||||||||
| 1 ft. | 3/4" | 11 1/4" | 3/8" | 1" | Neoprene-Coated Nylon Fabric | 0.022" | -60° to 250° | 0000000 | 000000 |
| 2 ft. | 1 1/2" | 22 1/2" | 3/8" | 1" | Neoprene-Coated Nylon Fabric | 0.022" | -60° to 250° | 0000000 | 000000 |
| 4 ft. | 3 1/2" | 44 1/2" | 3/8" | 1" | Neoprene-Coated Nylon Fabric | 0.022" | -60° to 250° | 0000000 | 000000 |
5 1/4" ID × 7 3/4" OD | |||||||||
| 1 ft. | 3/4" | 11 1/4" | 3/8" | 1" | Neoprene-Coated Nylon Fabric | 0.022" | -60° to 250° | 0000000 | 000000 |
| 2 ft. | 1 1/2" | 22 1/2" | 3/8" | 1" | Neoprene-Coated Nylon Fabric | 0.022" | -60° to 250° | 0000000 | 000000 |
| 4 ft. | 3 1/2" | 44 1/2" | 3/8" | 1" | Neoprene-Coated Nylon Fabric | 0.022" | -60° to 250° | 0000000 | 000000 |
6 1/4" ID × 8 3/4" OD | |||||||||
| 1 ft. | 3/4" | 11 1/4" | 3/8" | 1" | Neoprene-Coated Nylon Fabric | 0.022" | -60° to 250° | 0000000 | 000000 |
| 2 ft. | 1 1/2" | 22 1/2" | 3/8" | 1" | Neoprene-Coated Nylon Fabric | 0.022" | -60° to 250° | 0000000 | 000000 |
| 4 ft. | 3 1/2" | 44 1/2" | 3/8" | 1" | Neoprene-Coated Nylon Fabric | 0.022" | -60° to 250° | 0000000 | 000000 |
Highly Compressible Round Bellows with Cuff Ends
Suitable for tight spaces, these highly compressible bellows have sealed seams to keep contaminants out. Air venting may be necessary in fast-cycling applications. Slide these bellows over moving parts, such as rods and shafts, then secure the cuff ends with hose clamps (not included).
For technical drawings and 3-D models, click on a part number.
Length | |||||||||
|---|---|---|---|---|---|---|---|---|---|
| Extended | Retracted | Travel | Required ID Clearance | Cuff Lg. | Material | Material Thick. | Temp. Range, °F | Each | |
Protects Against Abrasive Grit, Coolant, Cutting Fluid, Dust, Oil, Salt Water, Solvents, Synthetic Oil, Water, Wood Chips | |||||||||
1/2" ID × 2 1/2" OD | |||||||||
| 1 ft. | 1" | 11" | 1/8" | 1/2" | Polyurethane Rubber | 0.01" | -60° to 220° | 0000000 | 000000 |
| 2 ft. | 1 1/2" | 22 1/2" | 1/8" | 1/2" | Polyurethane Rubber | 0.01" | -60° to 220° | 0000000 | 000000 |
3/4" ID × 2 3/4" OD | |||||||||
| 1 ft. | 1" | 11" | 3/16" | 1/2" | Polyurethane Rubber | 0.01" | -60° to 220° | 0000000 | 00000 |
| 2 ft. | 1 1/2" | 22 1/2" | 3/16" | 1/2" | Polyurethane Rubber | 0.01" | -60° to 220° | 0000000 | 000000 |
1" ID × 3" OD | |||||||||
| 1 ft. | 1" | 11" | 1/4" | 1/2" | Polyurethane Rubber | 0.01" | -60° to 220° | 0000000 | 000000 |
| 2 ft. | 1 1/2" | 22 1/2" | 1/4" | 1/2" | Polyurethane Rubber | 0.01" | -60° to 220° | 0000000 | 000000 |
1 1/4" ID × 3 1/4" OD | |||||||||
| 1 ft. | 1" | 11" | 1/4" | 1/2" | Polyurethane Rubber | 0.01" | -60° to 220° | 0000000 | 000000 |
| 2 ft. | 1 1/2" | 22 1/2" | 1/4" | 1/2" | Polyurethane Rubber | 0.01" | -60° to 220° | 0000000 | 000000 |
1 1/2" ID × 3 1/2" OD | |||||||||
| 1 ft. | 1" | 11" | 3/8" | 1/2" | Polyurethane Rubber | 0.01" | -60° to 220° | 0000000 | 000000 |
| 2 ft. | 1 1/2" | 22 1/2" | 3/8" | 1/2" | Polyurethane Rubber | 0.01" | -60° to 220° | 0000000 | 000000 |
1 3/4" ID × 3 3/4" OD | |||||||||
| 1 ft. | 1" | 11" | 3/8" | 1/2" | Polyurethane Rubber | 0.01" | -60° to 220° | 0000000 | 000000 |
| 2 ft. | 1 1/2" | 22 1/2" | 3/8" | 1/2" | Polyurethane Rubber | 0.01" | -60° to 220° | 0000000 | 000000 |
2" ID × 4" OD | |||||||||
| 1 ft. | 1" | 11" | 3/8" | 1/2" | Polyurethane Rubber | 0.01" | -60° to 220° | 0000000 | 000000 |
| 2 ft. | 1 1/2" | 22 1/2" | 3/8" | 1/2" | Polyurethane Rubber | 0.01" | -60° to 220° | 0000000 | 000000 |
2 1/2" ID × 4 1/2" OD | |||||||||
| 1 ft. | 1" | 11" | 3/8" | 1/2" | Polyurethane Rubber | 0.01" | -60° to 220° | 0000000 | 000000 |
| 2 ft. | 1 1/2" | 22 1/2" | 3/8" | 1/2" | Polyurethane Rubber | 0.01" | -60° to 220° | 0000000 | 000000 |
3" ID × 5" OD | |||||||||
| 1 ft. | 1" | 11" | 3/8" | 1/2" | Polyurethane Rubber | 0.01" | -60° to 220° | 0000000 | 000000 |
| 2 ft. | 1 1/2" | 22 1/2" | 3/8" | 1/2" | Polyurethane Rubber | 0.01" | -60° to 220° | 0000000 | 000000 |
Metal Telescoping Bellows
Made of coiled spring steel, these bellows protect equipment from hot and sharp chips. Slide them over moving parts, such as rods and shafts, and their spring action will hold them in place as they extend and retract between two parallel surfaces. Choose a bellows with an ID that's at least 1/4" larger than the diameter of the item to be covered.
Length | ||||||||
|---|---|---|---|---|---|---|---|---|
| ID | OD | Extended | Retracted | Travel | Material | Material Thick. | Each | |
Protects Against Abrasive Grit, Coolant, Cutting Fluid, Dust, Metal Chips, Oil, Solvents, Sparks, Synthetic Oil | ||||||||
| 1/2" | 1" | 4" | 1/2" | 3 1/2" | Spring Steel | 0.01" | 00000000 | 000000 |
| 3/4" | 1 3/8" | 10" | 3/4" | 9 1/4" | Spring Steel | 0.01" | 00000000 | 00000 |
| 1" | 1 3/4" | 10" | 1" | 9" | Spring Steel | 0.015" | 00000000 | 00000 |
| 1 1/4" | 2 1/16" | 1 ft. | 1 3/8" | 10 5/8" | Spring Steel | 0.015" | 00000000 | 00000 |
| 1 1/2" | 2 1/4" | 10" | 1 3/8" | 8 5/8" | Spring Steel | 0.015" | 00000000 | 00000 |
| 1 1/2" | 2 3/8" | 1 1/2 ft. | 2" | 16" | Spring Steel | 0.015" | 00000000 | 00000 |
| 1 3/4" | 2 3/4" | 3 ft. | 3" | 33" | Spring Steel | 0.015" | 00000000 | 000000 |
| 2 1/4" | 3 5/8" | 3 ft. | 3" | 33" | Spring Steel | 0.02" | 00000000 | 000000 |
Rectangular Bellows
Slide these bellows over square rods and shafts. All are molded, which means they're airtight to keep contaminants out. Air venting may be necessary in fast-cycling applications. Screw mount the flange ends to surfaces, or add a mounting flange (sold separately) for stability.
For technical drawings and 3-D models, click on a part number.
Bellows | ||||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
Inside | Outside | Length | Mounting Flanges | |||||||||||
| Ht. | Wd. | Ht. | Wd. | Extended | Retracted | Travel | Material | Material Thick. | Temp. Range, °F | Mounting Fasteners Included | Each | Each | ||
Protects Against Abrasive Grit, Coolant, Cutting Fluid, Dust, Oil, Salt Water, Solvents, Synthetic Oil, Water, Wood Chips | ||||||||||||||
| 1" | 1" | 3" | 3" | 1 ft. | 1" | 11" | Polyurethane Rubber | 0.02" | -60° to 220° | No | 000000000 | 000000 | 0000000 | 000000 |
| 1" | 1" | 3" | 3" | 2 ft. | 2" | 22" | Polyurethane Rubber | 0.02" | -60° to 220° | No | 000000000 | 000000 | 0000000 | 00000 |
| 1" | 1" | 3" | 3" | 3 ft. | 3" | 33" | Polyurethane Rubber | 0.02" | -60° to 220° | No | 000000000 | 000000 | 0000000 | 00000 |
| 1" | 1" | 3" | 3" | 4 ft. | 4" | 44" | Polyurethane Rubber | 0.02" | -60° to 220° | No | 000000000 | 000000 | 0000000 | 00000 |
| 2" | 2" | 4" | 4" | 1 ft. | 1" | 11" | Polyurethane Rubber | 0.02" | -60° to 220° | No | 000000000 | 000000 | 0000000 | 00000 |
| 2" | 2" | 4" | 4" | 2 ft. | 2" | 22" | Polyurethane Rubber | 0.02" | -60° to 220° | No | 000000000 | 000000 | 0000000 | 00000 |
| 2" | 2" | 4" | 4" | 3 ft. | 3" | 33" | Polyurethane Rubber | 0.02" | -60° to 220° | No | 000000000 | 000000 | 0000000 | 00000 |
| 2" | 2" | 4" | 4" | 4 ft. | 4" | 44" | Polyurethane Rubber | 0.02" | -60° to 220° | No | 000000000 | 000000 | 0000000 | 00000 |
| 2 1/2" | 2 1/2" | 4 1/2" | 4 1/2" | 1 ft. | 1" | 11" | Polyurethane Rubber | 0.02" | -60° to 220° | No | 000000000 | 000000 | 0000000 | 00000 |
| 2 1/2" | 2 1/2" | 4 1/2" | 4 1/2" | 2 ft. | 2" | 22" | Polyurethane Rubber | 0.02" | -60° to 220° | No | 000000000 | 000000 | 0000000 | 00000 |
| 2 1/2" | 2 1/2" | 4 1/2" | 4 1/2" | 3 ft. | 3" | 33" | Polyurethane Rubber | 0.02" | -60° to 220° | No | 000000000 | 000000 | 0000000 | 00000 |
| 2 1/2" | 2 1/2" | 4 1/2" | 4 1/2" | 4 ft. | 4" | 44" | Polyurethane Rubber | 0.02" | -60° to 220° | No | 000000000 | 000000 | 0000000 | 00000 |
| 3" | 3" | 5" | 5" | 1 ft. | 1" | 11" | Polyurethane Rubber | 0.02" | -60° to 220° | No | 000000000 | 000000 | 0000000 | 00000 |
| 3" | 3" | 5" | 5" | 2 ft. | 2" | 22" | Polyurethane Rubber | 0.02" | -60° to 220° | No | 000000000 | 000000 | 0000000 | 00000 |
| 3" | 3" | 5" | 5" | 3 ft. | 3" | 33" | Polyurethane Rubber | 0.02" | -60° to 220° | No | 000000000 | 000000 | 0000000 | 00000 |
| 3" | 3" | 5" | 5" | 4 ft. | 4" | 44" | Polyurethane Rubber | 0.02" | -60° to 220° | No | 000000000 | 000000 | 0000000 | 00000 |
| 4" | 4" | 6" | 6" | 1 ft. | 1" | 11" | Polyurethane Rubber | 0.02" | -60° to 220° | No | 000000000 | 000000 | 0000000 | 00000 |
| 4" | 4" | 6" | 6" | 2 ft. | 2" | 22" | Polyurethane Rubber | 0.02" | -60° to 220° | No | 000000000 | 000000 | 0000000 | 00000 |
| 4" | 4" | 6" | 6" | 3 ft. | 3" | 33" | Polyurethane Rubber | 0.02" | -60° to 220° | No | 000000000 | 000000 | 0000000 | 00000 |
| 4" | 4" | 6" | 6" | 4 ft. | 4" | 44" | Polyurethane Rubber | 0.02" | -60° to 220° | No | 000000000 | 000000 | 0000000 | 00000 |
| 5" | 5" | 7" | 7" | 1 ft. | 1" | 11" | Polyurethane Rubber | 0.02" | -60° to 220° | No | 000000000 | 000000 | 0000000 | 00000 |
| 5" | 5" | 7" | 7" | 2 ft. | 2" | 22" | Polyurethane Rubber | 0.02" | -60° to 220° | No | 000000000 | 000000 | 0000000 | 00000 |
| 5" | 5" | 7" | 7" | 3 ft. | 3" | 33" | Polyurethane Rubber | 0.02" | -60° to 220° | No | 000000000 | 000000 | 0000000 | 00000 |
| 5" | 5" | 7" | 7" | 4 ft. | 4" | 44" | Polyurethane Rubber | 0.02" | -60° to 220° | No | 000000000 | 000000 | 0000000 | 00000 |
| 5" | 7" | 7" | 9" | 1 ft. | 1" | 11" | Polyurethane Rubber | 0.02" | -60° to 220° | No | 000000000 | 000000 | 00000000 | 00000 |
| 5" | 7" | 7" | 9" | 2 ft. | 2" | 22" | Polyurethane Rubber | 0.02" | -60° to 220° | No | 000000000 | 000000 | 00000000 | 00000 |
| 5" | 7" | 7" | 9" | 3 ft. | 3" | 33" | Polyurethane Rubber | 0.02" | -60° to 220° | No | 000000000 | 000000 | 00000000 | 00000 |
| 5" | 7" | 7" | 9" | 4 ft. | 4" | 44" | Polyurethane Rubber | 0.02" | -60° to 220° | No | 000000000 | 000000 | 00000000 | 00000 |
| 6" | 6" | 8" | 8" | 1 ft. | 1" | 11" | Polyurethane Rubber | 0.02" | -60° to 220° | No | 000000000 | 000000 | 0000000 | 00000 |
| 6" | 6" | 8" | 8" | 2 ft. | 2" | 22" | Polyurethane Rubber | 0.02" | -60° to 220° | No | 000000000 | 000000 | 0000000 | 00000 |
| 6" | 6" | 8" | 8" | 3 ft. | 3" | 33" | Polyurethane Rubber | 0.02" | -60° to 220° | No | 000000000 | 000000 | 0000000 | 00000 |
| 6" | 6" | 8" | 8" | 4 ft. | 4" | 44" | Polyurethane Rubber | 0.02" | -60° to 220° | No | 000000000 | 000000 | 0000000 | 00000 |
| 6 3/4" | 10 1/2" | 8 3/4" | 12 1/2" | 1 ft. | 1" | 11" | Polyurethane Rubber | 0.02" | -60° to 220° | No | 000000000 | 000000 | 00000000 | 00000 |
| 6 3/4" | 10 1/2" | 8 3/4" | 12 1/2" | 2 ft. | 2" | 22" | Polyurethane Rubber | 0.02" | -60° to 220° | No | 000000000 | 000000 | 00000000 | 00000 |
| 8" | 8" | 10" | 10" | 1 ft. | 1" | 11" | Polyurethane Rubber | 0.02" | -60° to 220° | No | 000000000 | 000000 | 0000000 | 00000 |
| 8" | 8" | 10" | 10" | 2 ft. | 2" | 22" | Polyurethane Rubber | 0.02" | -60° to 220° | No | 000000000 | 000000 | 0000000 | 00000 |
| 8" | 8" | 10" | 10" | 3 ft. | 3" | 33" | Polyurethane Rubber | 0.02" | -60° to 220° | No | 000000000 | 000000 | 0000000 | 00000 |
| 10" | 10" | 12" | 12" | 1 ft. | 1" | 11" | Polyurethane Rubber | 0.02" | -60° to 220° | No | 000000000 | 000000 | 0000000 | 00000 |
| 10" | 10" | 12" | 12" | 2 ft. | 2" | 22" | Polyurethane Rubber | 0.02" | -60° to 220° | No | 000000000 | 000000 | 0000000 | 00000 |
| 10" | 10" | 12" | 12" | 3 ft. | 3" | 33" | Polyurethane Rubber | 0.02" | -60° to 220° | No | 000000000 | 00000000 | 0000000 | 00000 |
High-Temperature Flat Bellows
These bellows withstand temperatures up to 500° F—more than twice as much as standard flat bellows. Use them to guard flat moving surfaces on machinery. Sewn seams let these bellows breathe, so they retract quickly in fast-cycling applications. The seams will allow small amounts of moisture and dust to pass through.
For technical drawings and 3-D models, click on a part number.
Length | ||||||||
|---|---|---|---|---|---|---|---|---|
| Extended | Retracted | Travel | Material | Material Thick. | Max. Temp., °F | Mounting Fasteners Included | Each | |
Protects Against Abrasive Grit, Acid, Coolant, Cutting Fluid, Dust, Hydraulic Fluid, Metal Chips, Solvents, Sparks, Synthetic Oil, Welding Spatter, Wood Chips | ||||||||
9/16" Outside Ht. × 12" Outside Wd. | ||||||||
| 1 ft. | 1" | 11 3/8" | PTFE-Coated Fiberglass Fabric | 0.01" | 500° | No | 0000000 | 0000000 |
| 2 ft. | 1 15/16" | 22 1/16" | PTFE-Coated Fiberglass Fabric | 0.01" | 500° | No | 0000000 | 000000 |
Three-Sided Flat Bellows
Slide these bellows over flat moving surfaces on machinery, such as guideways. They have a notched opening with four perforated tabs on each side that can be removed to widen the opening. The edges of the folds are reinforced with PVC. These bellows have sealed seams to keep contaminants out. Air venting may be necessary in fast-cycling applications. Add a mounting flange (sold separately) for stability.
Bellows | ||||||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
Inside | Outside | Tab | Mounting Flanges | |||||||||||||
| Wd. | Ht. | Wd. | Ht. | Notch Wd. | Wd. | Ht. | Material | Material Thick. | Temp. Range, °F | Mounting Fasteners Included | Retracted Lg. per ft. | Choose an Extended Lg., ft. | Per Ft. | Each | ||
Protects Against Coolant, Cutting Fluid, Dust, Metal Chips, Salt Water, Solvents, Synthetic Oil, Water | ||||||||||||||||
| 8 1/8" | 2" | 10 1/2" | 4" | 4 1/8" | 1/2" | 5/8" | Neoprene-Coated Nylon Fabric | 0.02" | -40° to 220° | No | 1 5/8" | 0000000 | 000000 | 0000000 | 000000 | |
| 12 1/8" | 2" | 14 1/2" | 4" | 8 1/8" | 1/2" | 5/8" | Neoprene-Coated Nylon Fabric | 0.02" | -40° to 220° | No | 1 5/8" | 0000000 | 000000 | 0000000 | 00000 | |
| 16 1/8" | 2" | 18 1/2" | 4" | 12 1/8" | 1/2" | 5/8" | Neoprene-Coated Nylon Fabric | 0.02" | -40° to 220° | No | 1 5/8" | 0000000 | 000000 | 0000000 | 00000 | |
| 20 1/8" | 2" | 22 1/2" | 4" | 16 1/8" | 1/2" | 5/8" | Neoprene-Coated Nylon Fabric | 0.02" | -40° to 220° | No | 1 5/8" | 0000000 | 000000 | 0000000 | 00000 | |
| 24 1/8" | 2" | 26 1/2" | 4" | 20 1/8" | 1/2" | 5/8" | Neoprene-Coated Nylon Fabric | 0.02" | -40° to 220° | No | 1 5/8" | 0000000 | 000000 | 0000000 | 00000 | |
| 28 1/8" | 2" | 30 1/2" | 4" | 24 1/8" | 1/2" | 5/8" | Neoprene-Coated Nylon Fabric | 0.02" | -40° to 220° | No | 1 5/8" | 0000000 | 000000 | 0000000 | 00000 | |
Die Set Bellows
Secure these bellows to punch presses to prolong the life of their die sets. These molded bellows are airtight to keep contaminants out. Air venting may be necessary in fast-cycling applications. Slide these bellows over die sets, then attach the cuff end with the included hose clamp, and screw mount the flange end. Each die set bellows comes with two bellows, two hose clamps, and two mounting flanges to cover two die set pins.
Length | |||||||||
|---|---|---|---|---|---|---|---|---|---|
| For Die Set Shield Style | For Pin Dia. | Extended | Retracted | Travel | Material | Material Thick. | Temp. Range, °F | Each | |
Protects Against Abrasive Grit, Coolant, Cutting Fluid, Dust, Hydraulic Fluid, Metal Chips, Oil, Solvents, Synthetic Oil, Wood Chips | |||||||||
| DSA | 3/4", 7/8" | 11" | 1 1/2" | 9 1/2" | Neoprene/Nylon-Coated Rubber | 0.033" | -30° to 260° | 0000000 | 0000000 |
| DSB | 1", 1 1/8" | 11" | 1 1/2" | 9 1/2" | Neoprene/Nylon-Coated Rubber | 0.033" | -30° to 260° | 0000000 | 000000 |
| DSC | 1 1/4" | 11" | 1 1/2" | 9 1/2" | Neoprene/Nylon-Coated Rubber | 0.033" | -30° to 260° | 0000000 | 000000 |
| DSD | 1 1/2" | 11" | 1 1/2" | 9 1/2" | Neoprene/Nylon-Coated Rubber | 0.033" | -30° to 260° | 0000000 | 000000 |
| DSE | 1 3/4" | 11" | 1 1/2" | 9 1/2" | Neoprene/Nylon-Coated Rubber | 0.033" | -30° to 260° | 0000000 | 000000 |
| DSF | 2" | 11" | 1 1/2" | 9 1/2" | Neoprene/Nylon-Coated Rubber | 0.033" | -30° to 260° | 0000000 | 000000 |
