Push-Button Slant-Top Oil-Resistant Enclosures

Make your push buttons, switches, and indicating lights more visible and ergonomic to use. Enclosures mount on either of two sides, creating a 30° or 60° slanted surface. They are rated NEMA 13 for indoor protection from dirt and oil/coolant spraying when used with equivalently rated components.
Add a pedestal and a pedestal base to enclosures to make them freestanding.
For technical drawings and 3-D models, click on a part number.

Mounting | ||||||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| No. of Holes | No. of Columns | No. of Rows | Ht. | Front Ht. | Wd. | Dp. | Slant Lg. | Environment | Environmental Rating | Closure Screw Type | No. of Holes | Hole Dia. | Specifications Met | Color | Each | |
Powder-Coated Steel with Lift-Off Cover and Screw Closure | ||||||||||||||||
For 22 mm | ||||||||||||||||
| 1 | 1 | 1 | 4 3/4" | 2 1/2" | 3 1/2" | 4 1/2" | 3 1/2" | Oily | IP65, NEMA 13 | Captive | 4 | 0.22" | UL Listed, CSA Certified, ANSI 61, UL 508A | Gray | 0000000 | 0000000 |
| 2 | 2 | 1 | 4 3/4" | 2 1/2" | 5 3/4" | 4 1/2" | 3 1/2" | Oily | IP65, NEMA 13 | Captive | 4 | 0.22" | UL Listed, CSA Certified, ANSI 61, UL 508A | Gray | 0000000 | 000000 |
| 3 | 3 | 1 | 4 3/4" | 2 1/2" | 8" | 4 1/2" | 3 1/2" | Oily | IP65, NEMA 13 | Captive | 4 | 0.22" | UL Listed, CSA Certified, ANSI 61, UL 508A | Gray | 0000000 | 000000 |
| 4 | 2 | 2 | 6 3/4" | 2 1/2" | 6 1/2" | 7 3/4" | 7 1/4" | Oily | IP65, NEMA 13 | Captive | 4 | 0.22" | UL Listed, CSA Certified, ANSI 61, UL 508A | Gray | 0000000 | 000000 |
| 4 | 4 | 1 | 4 3/4" | 2 1/2" | 10 1/4" | 4 1/2" | 3 1/2" | Oily | IP65, NEMA 13 | Captive | 4 | 0.22" | UL Listed, CSA Certified, ANSI 61, UL 508A | Gray | 0000000 | 000000 |
| 6 | 3 | 2 | 6 3/4" | 2 1/2" | 8 3/4" | 7 3/4" | 7 1/4" | Oily | IP65, NEMA 13 | Captive | 4 | 0.22" | UL Listed, CSA Certified, ANSI 61, UL 508A | Gray | 0000000 | 000000 |
| 8 | 4 | 2 | 6 3/4" | 2 1/2" | 11" | 7 3/4" | 7 1/4" | Oily | IP65, NEMA 13 | Captive | 4 | 0.22" | UL Listed, CSA Certified, ANSI 61, UL 508A | Gray | 0000000 | 000000 |
| 9 | 3 | 3 | 8" | 2 1/2" | 8 3/4" | 9 3/4" | 9 1/2" | Oily | IP65, NEMA 13 | Captive | 4 | 0.22" | UL Listed, CSA Certified, ANSI 61, UL 508A | Gray | 0000000 | 000000 |
| 10 | 5 | 2 | 6 3/4" | 2 1/2" | 13 1/4" | 7 3/4" | 7 1/4" | Oily | IP65, NEMA 13 | Captive | 4 | 0.22" | UL Listed, CSA Certified, ANSI 61, UL 508A | Gray | 0000000 | 000000 |
| 12 | 6 | 2 | 6 3/4" | 2 1/2" | 15 1/2" | 7 3/4" | 7 1/4" | Oily | IP65, NEMA 13 | Captive | 4 | 0.22" | UL Listed, CSA Certified, ANSI 61, UL 508A | Gray | 0000000 | 000000 |
For 30 mm | ||||||||||||||||
| 1 | 1 | 1 | 4 3/4" | 2 1/2" | 3 1/2" | 4 1/2" | 3 1/2" | Oily | IP65, NEMA 13 | Captive | 4 | 0.22" | UL Listed, CSA Certified, ANSI 61, UL 508A | Gray | 0000000 | 000000 |
| 2 | 2 | 1 | 4 3/4" | 2 1/2" | 5 3/4" | 4 1/2" | 3 1/2" | Oily | IP65, NEMA 13 | Captive | 4 | 0.22" | UL Listed, CSA Certified, ANSI 61, UL 508A | Gray | 0000000 | 000000 |
| 3 | 3 | 1 | 4 3/4" | 2 1/2" | 8" | 4 1/2" | 3 1/2" | Oily | IP65, NEMA 13 | Captive | 4 | 0.22" | UL Listed, CSA Certified, ANSI 61, UL 508A | Gray | 0000000 | 000000 |
| 4 | 2 | 2 | 6 3/4" | 2 1/2" | 6 1/2" | 7 3/4" | 7 1/4" | Oily | IP65, NEMA 13 | Captive | 4 | 0.22" | UL Listed, CSA Certified, ANSI 61, UL 508A | Gray | 0000000 | 000000 |
| 4 | 4 | 1 | 4 3/4" | 2 1/2" | 10 1/4" | 4 1/2" | 3 1/2" | Oily | IP65, NEMA 13 | Captive | 4 | 0.22" | UL Listed, CSA Certified, ANSI 61, UL 508A | Gray | 0000000 | 000000 |
| 6 | 3 | 2 | 6 3/4" | 2 1/2" | 8 3/4" | 7 3/4" | 7 1/4" | Oily | IP65, NEMA 13 | Captive | 4 | 0.22" | UL Listed, CSA Certified, ANSI 61, UL 508A | Gray | 0000000 | 000000 |
| 8 | 4 | 2 | 6 3/4" | 2 1/2" | 11" | 7 3/4" | 7 1/4" | Oily | IP65, NEMA 13 | Captive | 4 | 0.22" | UL Listed, CSA Certified, ANSI 61, UL 508A | Gray | 0000000 | 000000 |
| 9 | 3 | 3 | 8" | 2 1/2" | 8 3/4" | 9 3/4" | 9 1/2" | Oily | IP65, NEMA 13 | Captive | 4 | 0.22" | UL Listed, CSA Certified, ANSI 61, UL 508A | Gray | 0000000 | 000000 |
| 10 | 5 | 2 | 6 3/4" | 2 1/2" | 13 1/4" | 7 3/4" | 7 1/4" | Oily | IP65, NEMA 13 | Captive | 4 | 0.22" | UL Listed, CSA Certified, ANSI 61, UL 508A | Gray | 0000000 | 000000 |
| 12 | 6 | 2 | 6 3/4" | 2 1/2" | 15 1/2" | 7 3/4" | 7 1/4" | Oily | IP65, NEMA 13 | Captive | 4 | 0.22" | UL Listed, CSA Certified, ANSI 61, UL 508A | Gray | 0000000 | 000000 |

Pedestal | Enclosure Mounting | Base Mounting | |||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Height | Width | Depth | Shape | Plate Width | Plate Depth | Hardware Included | Plate Width | Plate Depth | Hardware Included | Includes | Color | Each | |
Powder-Coated Steel | |||||||||||||
| 35" | 4" | 4" | Straight | 5 3/4" | 5 3/4" | Yes | 7 5/8" | 7 5/8" | Yes | Gasketed Access Plate, Two Gaskets | Gray | 00000000 | 0000000 |

Pedestal Mounting | Floor Mounting | ||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|
| Height | Width | Depth | Fasteners Included | Hole Thread Size | No.of Holes | Fasteners Included | Hole Diameter | No. of Holes | Color | Each | |
Powder-Coated Steel | |||||||||||
| 1" | 18" | 18" | No | 1/4"-20 | 8 | No | 7/16" | 4 | Gray | 00000000 | 0000000 |
Slant-Top Oil-Resistant Enclosures

Mount these enclosures on either of two sides, creating a 30° or 60° slanted surface for displays, touch screens, and other interactive devices. They are rated NEMA 13 and IP65 for indoor protection from dirt, dust, spraying and splashing oil/coolant, and low-pressure jets of water.
Add a pedestal and a pedestal base to enclosures to make them freestanding.
For technical drawings and 3-D models, click on a part number.

| Ht. | Front Ht. | Wd. | Dp. | Slant Lg. | Closure Screw Type | Environment | Environmental Rating | Specifications Met | Color | Each | |
Powder-Coated Steel with Hinged Cover and Screw Closure | |||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|
| 7" | 2 1/2" | 8 1/4" | 7 1/2" | 8 1/4" | Captive | Oily, Washdown | IP65; NEMA 13 | CSA Certified, UL Listed, C-UL Listed, UL 508A | Gray | 00000000 | 0000000 |
| 7" | 2 1/2" | 12 1/4" | 7 1/2" | 8 1/4" | Captive | Oily, Washdown | IP65; NEMA 13 | CSA Certified, UL Listed, C-UL Listed, UL 508A | Gray | 00000000 | 000000 |
| 7" | 2 1/2" | 16 1/4" | 7 1/2" | 8 1/4" | Captive | Oily, Washdown | IP65; NEMA 13 | CSA Certified, UL Listed, C-UL Listed, UL 508A | Gray | 00000000 | 000000 |
| 9" | 2 1/2" | 12 1/4" | 11" | 12 1/4" | Captive | Oily, Washdown | IP65; NEMA 13 | CSA Certified, UL Listed, C-UL Listed, UL 508A | Gray | 00000000 | 000000 |
| 9" | 2 1/2" | 16 1/4" | 11" | 12 1/4" | Captive | Oily, Washdown | IP65; NEMA 13 | CSA Certified, UL Listed, C-UL Listed, UL 508A | Gray | 00000000 | 000000 |
| 9" | 2 1/2" | 24 1/4" | 11" | 12 1/4" | Captive | Oily, Washdown | IP65; NEMA 13 | CSA Certified, UL Listed, C-UL Listed, UL 508A | Gray | 00000000 | 000000 |
| 11" | 2 1/2" | 20 1/4" | 14 1/2" | 16 1/4" | Captive | Oily, Washdown | IP65; NEMA 13 | CSA Certified, UL Listed, C-UL Listed, UL 508A | Gray | 00000000 | 000000 |

Pedestal | Enclosure Mounting | Base Mounting | |||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Height | Width | Depth | Shape | Plate Width | Plate Depth | Hardware Included | Plate Width | Plate Depth | Hardware Included | Includes | Color | Each | |
Powder-Coated Steel | |||||||||||||
| 35" | 4" | 4" | Straight | 5 3/4" | 5 3/4" | Yes | 7 5/8" | 7 5/8" | Yes | Gasketed Access Plate, Two Gaskets | Gray | 00000000 | 0000000 |

Pedestal Mounting | Floor Mounting | ||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|
| Height | Width | Depth | Fasteners Included | Hole Thread Size | No.of Holes | Fasteners Included | Hole Diameter | No. of Holes | Color | Each | |
Powder-Coated Steel | |||||||||||
| 1" | 18" | 18" | No | 1/4"-20 | 8 | No | 7/16" | 4 | Gray | 00000000 | 0000000 |
Pedestals for Enclosures


Raise your enclosure to access switches, gauges, screens, and other parts at a comfortable working height. These pedestals are hollow and have a gasketed access plate, so you can route and manage wires within the column to organize and protect them. All require a base (sold separately). Bases need to be anchored to the floor for stability.
Combine straight pedestals with slant-top enclosures or angled pedestals with standard enclosures. Both combinations position buttons and other components at a comfortable angle.
Powder-coated steel pedestals resist rusting from water. 304 stainless steel pedestals resist corrosion better than steel pedestals. They stand up to salt water and cleaners.
For technical drawings and 3-D models, click on a part number.


Pedestal | Enclosure Mounting | Base Mounting | ||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Height | Width | Depth | Plate Width | Plate Depth | Hardware Included | Plate Width | Plate Depth | Hardware Included | Includes | Color | Each | |
Straight | ||||||||||||
| 35" | 4" | 4" | 5 3/4" | 5 3/4" | Yes | 7 5/8" | 7 5/8" | Yes | Gasketed Access Plate, Two Gaskets | Gray | 00000000 | 0000000 |
Angled | ||||||||||||
| 41" | 4" | 4" | 5 3/4" | 5 3/4" | Yes | 7 5/8" | 7 5/8" | Yes | Gasketed Access Plate, Two Gaskets | Gray | 00000000 | 000000 |
Pedestal | Enclosure Mounting | Base Mounting | |||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|
| Height | Width | Depth | Plate Width | Plate Depth | Hardware Included | Plate Width | Plate Depth | Hardware Included | Includes | Each | |
Straight | |||||||||||
| 35" | 4" | 4" | 5 3/4" | 5 3/4" | Yes | 7 5/8" | 7 5/8" | Yes | Gasketed Access Plate, Two Gaskets | 00000000 | 0000000 |
Angled | |||||||||||
| 41" | 4" | 4" | 5 3/4" | 5 3/4" | Yes | 7 5/8" | 7 5/8" | Yes | Gasketed Access Plate, Two Gaskets | 00000000 | 000000 |

Pedestal Mounting | Floor Mounting | |||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Height | Width | Depth | Fasteners Included | Hole Thread Size | No. of Holes | Fasteners Included | Hole Diameter | No. of Holes | Material | Color | Each | |
For Powder-Coated Steel Pedestals | ||||||||||||
| 1" | 18" | 18" | No | 1/4"-20 | 8 | No | 7/16" | 4 | Powder-Coated Steel | Gray | 00000000 | 0000000 |
For 304 Stainless Steel Pedestals | ||||||||||||
| 1" | 18" | 18" | No | 1/4"-20 | 8 | No | 7/16" | 4 | 304 Stainless Steel | __ | 00000000 | 000000 |
