Index Base Miniature Light Bulbs
Tubular (front view)
Side View
Tapered (front view)
Offset pins on the base lock these bulbs into sockets. These bulbs are sized to fit tight spaces such as indicators and vehicle lights. Brightness is measured in lumens; the higher the lumens, the brighter the bulb.
Bulbs have two filaments, which operate at two brightness levels. The first filament illuminates a light and the second emits a brighter light similar to a tail light and brake light.
| Trade No. | Voltage | Wattage | Brightness, lumens | Current | Light Technology | Light Setting | Bulb Material | Color | Rated Life, hrs. | Bulb Dia. | O'all Lg. | Bulb Shape No. | Pkg. Qty. | Pkg. | |
Double-Contact Base (0.6" Dia.) | |||||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
Tubular Bulb | |||||||||||||||
| 3496 | 12.8V 14V | 8.26W 25.2W | 38 540 | 0.59A 2.1A | Incand. | 2 Way | Glass | Clear | 5,000 600 | 3/4" | 1.89" | T6 | 1 | 00000000 | 00000 |
Tapered Bulb | |||||||||||||||
| 198 | 12.8V 14V | 9.52W 28.8W | 38 402 | 0.68A 2.25A | Incand. | 2 Way | Glass | Clear | 1,200 5,000 | 1" | 2" | S8 | 10 | 0000000 | 0000 |
| 1016 | 12.8V 14V | 8.26W 17.15W | 264 75 | 0.59A 1.34A | Incand. | 2 Way | Glass | Clear | 1,500 300 | 1" | 2" | S8 | 10 | 0000000 | 0000 |
| 1034 | 12.8V 14V | 8.59W 23W | 38 402 | 0.59A 1.8A | Incand. | 2 Way | Glass | Clear | 200 5,000 | 1" | 2" | S8 | 10 | 0000000 | 0000 |
| 1034A | 12.8V 14V | 8.26W 23W | 28 302 | 0.59A 1.8A | Incand. | 2 Way | Glass | Amber | 200 5,000 | 1" | 2" | S8 | 10 | 0000000 | 0000 |
| 1154 | 6.3V 7V | 5.25W 16.57W | 264 38 | 0.75A 2.63A | Incand. | 2 Way | Glass | Clear | 1,000 200 | 1" | 2" | S8 | 10 | 00000000 | 0000 |
| 1157 | 12.8V 14V | 8.26W 26.9W | 38 402 | 0.59A 2.1A | Incand. | 2 Way | Glass | Clear | 1,200 5,000 | 1" | 2" | S8 | 10 | 0000000 | 0000 |
| 1157A | 12.8V 14V | 8.26W 26.88W | 28 302 | 0.59A 2.1A | Incand. | 2 Way | Glass | Amber | 1,200 5,000 | 1" | 2" | S8 | 10 | 00000000 | 0000 |
| 1157LL | 12.8V 14V | 8.26W 26.88W | 38 402 | 0.59A 2.1A | Incand. | 2 Way | Glass | Clear | 10,000 2,400 | 1" | 2" | S8 | 10 | 00000000 | 00000 |
| 1157NA | 12.8V 14V | 8.26W 26.88W | 28 302 | 0.59A 2.1A | Incand. | 2 Way | Glass | Amber | 1,200 5,000 | 1" | 2" | S8 | 5 | 0000000 | 00000 |
| 1662 | 28V | 9.52W 25.2W | 402 75 | 0.34A 0.9A | Incand. | 2 Way | Glass | Clear | 1,000 400 | 1" | 2" | S8 | 10 | 00000000 | 00000 |
| 2057 | 12.8V 14V | 6.72W 26.9W | 25 402 | 0.48A 2.1A | Incand. | 2 Way | Glass | Clear | 1,200 5,000 | 1" | 2" | S8 | 10 | 0000000 | 0000 |
| 2057A | 12.8V 14V | 6.72W 26.88W | 19 302 | 0.48A 2.1A | Incand. | 2 Way | Glass | Amber | 1,200 5,000 | 1" | 2" | S8 | 10 | 00000000 | 0000 |
| 2057LL | 12.8V 14V | 8.26W 26.8W | 25 402 | 0.48A 2.1A | Incand. | 2 Way | Glass | Clear | 10,000 2,400 | 1" | 2" | S8 | 10 | 00000000 | 00000 |
| 2057NA | 12.8V 14V | 6.72W 26.88W | 19 302 | 0.48A 2.1A | Incand. | 2 Way | Glass | Amber | 1,200 5,000 | 1" | 2" | S8 | 10 | 00000000 | 00000 |
| 2057NALL | 12.8V 14V | 6.72W 26.88W | 19 302 | 0.48A 2.1A | Incand. | 2 Way | Glass | Amber | 10,000 2,000 | 1" | 2" | S8 | 10 | 00000000 | 00000 |
| 2357 | 12.8V 14V | 8.26W 28.16W | 38 503 | 0.59A 2.2A | Incand. | 2 Way | Glass | Clear | 400 5,000 | 1" | 2" | S8 | 10 | 00000000 | 0000 |
| 2357A | 12.8V 14V | 8.26W 28.16W | 28 402 | 0.59A 2.2A | Incand. | 2 Way | Glass | Amber | 400 5,000 | 1" | 2" | S8 | 10 | 00000000 | 00000 |
| 2357LL | 12.8V 14V | 8.26W 28.16W | 38 503 | 0.59A 2.23A | Incand. | 2 Way | Glass | Clear | 10,000 800 | 1" | 2" | S8 | 10 | 00000000 | 00000 |
| 2357NA | 12.8V 14V | 8.26W 28.16W | 28 402 | 0.59A 2.2A | Incand. | 2 Way | Glass | Amber | 400 5,000 | 1" | 2" | S8 | 10 | 00000000 | 00000 |
| 2397 | 12.8V 14V | 8.25W 28.16W | 25 503 | 0.59A 2.23A | Incand. | 2 Way | Glass | Clear | 400 5,000 | 1" | 2" | S8 | 10 | 00000000 | 0000 |
