Aluminum Corrosion-Resistant Washdown Enclosures
With Screw Closure
With Screw-Down Clamps
With Slotted Latch
Aluminum enclosures are a lightweight yet durable alternative to stainless steel. These withstand corrosive, wet, and oily environments. They are rated NEMA 4X and 13 for protection from dirt, washdowns, corrosion, and oil/coolant spraying.
Enclosures with a slotted latch open with a quarter turn for easy access—there are no clamps or screws to unfasten.
Panels are for mounting components inside enclosures.
For technical drawings and 3-D models, click on a part number.
Enclosures | |||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
Mounting | Panels | ||||||||||||
| Ht. | Wd. | Dp. | Environment | Environmental Rating | Fasteners Included | No. of Holes | Hole Dia. | Specifications Met | Appearance | Each | Each | ||
With Lift-Off Cover and Screw Closure | |||||||||||||
| 2" | 1 3/4" | 1 1/4" | Corrosive, Damp, Dusty, Oily, Outdoor, Washdown | IP66, NEMA 4X, NEMA 13 | No | 2 | 0.15" | UL Listed, C-UL Listed | Brushed | 00000000 | 00000 | 000000 | 00 |
| 3 1/2" | 1 3/8" | 1 1/4" | Corrosive, Damp, Dusty, Oily, Outdoor, Washdown | IP66, NEMA 4X, NEMA 13 | No | 2 | 0.124" | UL Listed, C-UL Listed | Brushed | 00000000 | 0000 | 000000 | 00 |
| 3 7/8" | 2 1/2" | 1 3/8" | Corrosive, Damp, Dusty, Oily, Outdoor, Washdown | IP66, NEMA 4X, NEMA 13 | No | 2 | 0.156" | UL Listed, C-UL Listed | Brushed | 00000000 | 00000 | 000000 | 00 |
| 4 1/2" | 2 5/8" | 1 1/4" | Corrosive, Damp, Dusty, Oily, Outdoor, Washdown | IP66, NEMA 4X, NEMA 13 | No | 2 | 0.163" | UL Listed, C-UL Listed | Brushed | 00000000 | 00000 | 000000 | 00 |
| 4 1/2" | 2 5/8" | 2 1/8" | Corrosive, Damp, Dusty, Oily, Outdoor, Washdown | IP66, NEMA 4X, NEMA 13 | No | 2 | 0.156" | UL Listed, C-UL Listed | Brushed | 00000000 | 00000 | 000000 | 00 |
| 4 1/2" | 3 5/8" | 2 1/4" | Corrosive, Damp, Dusty, Oily, Outdoor, Washdown | IP66, NEMA 4X, NEMA 13 | No | 2 | 0.163" | UL Listed, C-UL Listed | Brushed | 00000000 | 00000 | 000000 | 00 |
| 4 3/4" | 4 3/4" | 4" | Corrosive, Damp, Dusty, Oily, Outdoor, Washdown | IP66, NEMA 4X, NEMA 13 | No | 4 | 0.163" | UL Listed, C-UL Listed | Brushed | 00000000 | 00000 | 000000 | 00 |
| 5" | 3 1/8" | 2 1/4" | Corrosive, Damp, Dusty, Oily, Outdoor, Washdown | IP66, NEMA 4X, NEMA 13 | No | 2 | 0.16" | UL Listed, C-UL Listed | Brushed | 00000000 | 00000 | 000000 | 00 |
| 6" | 2 1/2" | 1 3/8" | Corrosive, Damp, Dusty, Oily, Outdoor, Washdown | IP66, NEMA 4X, NEMA 13 | No | 2 | 0.139" | UL Listed, C-UL Listed | Brushed | 00000000 | 00000 | 000000 | 00 |
| 6 1/4" | 4" | 2 3/8" | Corrosive, Damp, Dusty, Oily, Outdoor, Washdown | IP66, NEMA 4X, NEMA 13 | No | 4 | 0.165" | UL Listed, C-UL Listed | Brushed | 00000000 | 00000 | 000000 | 00 |
| 6 3/4" | 4 3/4" | 2 1/8" | Corrosive, Damp, Dusty, Oily, Outdoor, Washdown | IP66, NEMA 4X, NEMA 13 | No | 6 | 0.18" | UL Listed, C-UL Listed | Brushed | 00000000 | 00000 | 000000 | 00 |
| 8 3/4" | 5 3/4" | 2 1/8" | Corrosive, Damp, Dusty, Oily, Outdoor, Washdown | IP66, NEMA 4X, NEMA 13 | No | 2 | 0.18" | UL Listed, C-UL Listed | Brushed | 00000000 | 00000 | 000000 | 00 |
With Lift-Off Cover and Screw-Down Clamps | |||||||||||||
| 6" | 4" | 3" | Corrosive, Damp, Dusty, Oily, Outdoor, Washdown | IP66, NEMA 4X, NEMA 13 | No | 4 | 0.31" | UL Listed, CSA Certified, UL 508A | Brushed | 00000000 | 000000 | 0000000 | 000000 |
| 6" | 6" | 4" | Corrosive, Damp, Dusty, Oily, Outdoor, Washdown | IP66, NEMA 4X, NEMA 13 | No | 4 | 5/16" | UL Listed, CSA Certified, UL 508A | Brushed | 00000000 | 000000 | 0000000 | 00000 |
| 8" | 6" | 3 1/2" | Corrosive, Damp, Dusty, Oily, Outdoor, Washdown | IP66, NEMA 4X, NEMA 13 | No | 4 | 5/16" | UL Listed, CSA Certified, UL 508A | Brushed | 00000000 | 000000 | 0000000 | 00000 |
| 10" | 8" | 4" | Corrosive, Damp, Dusty, Oily, Outdoor, Washdown | IP66, NEMA 4X, NEMA 13 | No | 4 | 5/16" | UL Listed, CSA Certified, UL 508A | Brushed | 00000000 | 000000 | 0000000 | 00000 |
| 12" | 10" | 5" | Corrosive, Damp, Dusty, Oily, Outdoor, Washdown | IP66, NEMA 4X, NEMA 13 | No | 4 | 5/16" | UL Listed, CSA Certified, UL 508A | Brushed | 00000000 | 000000 | 0000000 | 00000 |
| 14" | 12" | 6" | Corrosive, Damp, Dusty, Oily, Outdoor, Washdown | IP66, NEMA 4X, NEMA 13 | No | 4 | 5/16" | UL Listed, CSA Certified, UL 508A | Brushed | 00000000 | 000000 | 0000000 | 00000 |
| 16" | 14" | 6" | Corrosive, Damp, Dusty, Oily, Outdoor, Washdown | IP66, NEMA 4X, NEMA 13 | No | 4 | 5/16" | UL Listed, CSA Certified, UL 508A | Brushed | 00000000 | 000000 | 0000000 | 00000 |
With Hinged Cover and Slotted Latch | |||||||||||||
| 4" | 4" | 3" | Corrosive, Damp, Dusty, Oily, Outdoor, Washdown | IP66, NEMA 4X, NEMA 13 | No | 4 | 0.31" | UL Listed, CSA Certified, UL 508A | Brushed | 00000000 | 000000 | 000000 | 00 |
| 6" | 4" | 4" | Corrosive, Damp, Dusty, Oily, Outdoor, Washdown | IP66, NEMA 4X, NEMA 13 | No | 4 | 0.31" | UL Listed, CSA Certified, UL 508A | Brushed | 00000000 | 000000 | 000000 | 00 |
| 6" | 6" | 4" | Corrosive, Damp, Dusty, Oily, Outdoor, Washdown | IP66, NEMA 4X, NEMA 13 | No | 4 | 0.31" | UL Listed, CSA Certified, UL 508A | Brushed | 00000000 | 000000 | 000000 | 00 |
| 8" | 6" | 3 1/2" | Corrosive, Damp, Dusty, Oily, Outdoor, Washdown | IP66, NEMA 4X, NEMA 13 | No | 4 | 0.31" | UL Listed, CSA Certified, UL 508A | Brushed | 00000000 | 000000 | 000000 | 00 |
| 8" | 6" | 6" | Corrosive, Damp, Dusty, Oily, Outdoor, Washdown | IP66, NEMA 4X, NEMA 13 | No | 4 | 0.31" | UL Listed, CSA Certified, UL 508A | Brushed | 00000000 | 000000 | 000000 | 00 |
| 8" | 8" | 4" | Corrosive, Damp, Dusty, Oily, Outdoor, Washdown | IP66, NEMA 4X, NEMA 13 | No | 4 | 0.31" | UL Listed, CSA Certified, UL 508A | Brushed | 00000000 | 000000 | 000000 | 00 |
| 10" | 8" | 6" | Corrosive, Damp, Dusty, Oily, Outdoor, Washdown | IP66, NEMA 4X, NEMA 13 | No | 4 | 0.31" | UL Listed, CSA Certified, UL 508A | Brushed | 00000000 | 000000 | 000000 | 00 |
| 10" | 10" | 6" | Corrosive, Damp, Dusty, Oily, Outdoor, Washdown | IP66, NEMA 4X, NEMA 13 | No | 4 | 0.31" | UL Listed, CSA Certified, UL 508A | Brushed | 00000000 | 000000 | 000000 | 00 |
| 12" | 6" | 4" | Corrosive, Damp, Dusty, Oily, Outdoor, Washdown | IP66, NEMA 4X, NEMA 13 | No | 4 | 0.31" | UL Listed, CSA Certified, UL 508A | Brushed | 00000000 | 000000 | 000000 | 00 |
| 12" | 10" | 5" | Corrosive, Damp, Dusty, Oily, Outdoor, Washdown | IP66, NEMA 4X, NEMA 13 | No | 4 | 0.31" | UL Listed, CSA Certified, UL 508A | Brushed | 00000000 | 000000 | 000000 | 00 |
| 12" | 10" | 6" | Corrosive, Damp, Dusty, Oily, Outdoor, Washdown | IP66, NEMA 4X, NEMA 13 | No | 4 | 0.31" | UL Listed, CSA Certified, UL 508A | Brushed | 00000000 | 000000 | 000000 | 00 |
| 12" | 10" | 8" | Corrosive, Damp, Dusty, Oily, Outdoor, Washdown | IP66, NEMA 4X, NEMA 13 | No | 4 | 0.31" | UL Listed, CSA Certified, UL 508A | Brushed | 00000000 | 000000 | 000000 | 00 |
| 12" | 12" | 4" | Corrosive, Damp, Dusty, Oily, Outdoor, Washdown | IP66, NEMA 4X, NEMA 13 | No | 4 | 0.31" | UL Listed, CSA Certified, UL 508A | Brushed | 00000000 | 000000 | 000000 | 00 |
| 12" | 12" | 6" | Corrosive, Damp, Dusty, Oily, Outdoor, Washdown | IP66, NEMA 4X, NEMA 13 | No | 4 | 0.31" | UL Listed, CSA Certified, UL 508A | Brushed | 00000000 | 000000 | 000000 | 00 |
| 14" | 12" | 6" | Corrosive, Damp, Dusty, Oily, Outdoor, Washdown | IP66, NEMA 4X, NEMA 13 | No | 4 | 0.31" | UL Listed, CSA Certified, UL 508A | Brushed | 00000000 | 000000 | 000000 | 00 |
| 14" | 12" | 8" | Corrosive, Damp, Dusty, Oily, Outdoor, Washdown | IP66, NEMA 4X, NEMA 13 | No | 4 | 0.31" | UL Listed, CSA Certified, UL 508A | Brushed | 00000000 | 000000 | 000000 | 00 |
| 16" | 14" | 6" | Corrosive, Damp, Dusty, Oily, Outdoor, Washdown | IP66, NEMA 4X, NEMA 13 | No | 4 | 0.31" | UL Listed, CSA Certified, UL 508A | Brushed | 00000000 | 000000 | 000000 | 00 |
| 16" | 14" | 8" | Corrosive, Damp, Dusty, Oily, Outdoor, Washdown | IP66, NEMA 4X, NEMA 13 | No | 4 | 0.31" | UL Listed, CSA Certified, UL 508A | Brushed | 00000000 | 000000 | 000000 | 00 |
| 16" | 14" | 10" | Corrosive, Damp, Dusty, Oily, Outdoor, Washdown | IP66, NEMA 4X, NEMA 13 | No | 4 | 0.31" | UL Listed, CSA Certified, UL 508A | Brushed | 00000000 | 000000 | 000000 | 00 |
Heavy Duty Aluminum Corrosion-Resistant Washdown Enclosures
Washdown Enclosure
These enclosures have thicker walls than standard aluminum enclosures, but they are still a lightweight yet durable alternative to stainless steel. They’ll stand up to washdowns, corrosion, dust, oil, and the weather.
Mount components on optional panels inside enclosures without drilling holes. Drilling holes in enclosures could cause leaks and compromise the NEMA and IP ratings.
For technical drawings and 3-D models, click on a part number.
Enclosures | |||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
Mounting | Panels | ||||||||||||
| Ht. | Wd. | Dp. | Environment | Environmental Rating | Fasteners Included | No. of Holes | Hole Dia. | Specifications Met | Color | Each | Each | ||
With Lift-Off Cover and Screw Closure | |||||||||||||
| 2" | 2 1/2" | 1 5/8" | Corrosive, Damp, Dusty, Oily, Outdoor, Washdown | IP66, NEMA 4X, NEMA 13 | No | 4 | 3/16" | CSA Certified, C-UL Listed, UL Listed | Gray | 00000000 | 000000 | 000000 | 00 |
| 2 1/2" | 2 1/2" | 1 5/8" | Corrosive, Damp, Dusty, Oily, Outdoor, Washdown | IP66, NEMA 4X, NEMA 13 | No | 4 | 3/16" | CSA Certified, C-UL Listed, UL Listed | Gray | 00000000 | 00000 | 00000000 | 00000 |
| 3 1/8" | 3 1/8" | 2 3/8" | Corrosive, Damp, Dusty, Oily, Outdoor, Washdown | IP66, NEMA 4X, NEMA 13 | No | 4 | 3/16" | CSA Certified, C-UL Listed, UL Listed | Gray | 00000000 | 00000 | 00000000 | 0000 |
| 4" | 2 1/2" | 1 5/8" | Corrosive, Damp, Dusty, Oily, Outdoor, Washdown | IP66, NEMA 4X, NEMA 13 | No | 4 | 3/16" | CSA Certified, C-UL Listed, UL Listed | Gray | 00000000 | 00000 | 00000000 | 0000 |
| 4" | 4" | 3 1/8" | Corrosive, Damp, Dusty, Oily, Outdoor, Washdown | IP66, NEMA 4X, NEMA 13 | No | 4 | 3/16" | CSA Certified, C-UL Listed, UL Listed | Gray | 00000000 | 000000 | 00000000 | 00000 |
| 4 3/4" | 3 1/8" | 2 3/8" | Corrosive, Damp, Dusty, Oily, Outdoor, Washdown | IP66, NEMA 4X, NEMA 13 | No | 4 | 3/16" | CSA Certified, C-UL Listed, UL Listed | Gray | 00000000 | 00000 | 00000000 | 0000 |
| 4 3/4" | 4 3/4" | 4" | Corrosive, Damp, Dusty, Oily, Outdoor, Washdown | IP66, NEMA 4X, NEMA 13 | No | 4 | 1/4" | CSA Certified, C-UL Listed, UL Listed | Gray | 00000000 | 000000 | 00000000 | 00000 |
| 6" | 2 1/2" | 1 5/8" | Corrosive, Damp, Dusty, Oily, Outdoor, Washdown | IP66, NEMA 4X, NEMA 13 | No | 4 | 3/16" | CSA Certified, C-UL Listed, UL Listed | Gray | 00000000 | 00000 | 00000000 | 0000 |
| 6" | 4" | 3 1/8" | Corrosive, Damp, Dusty, Oily, Outdoor, Washdown | IP66, NEMA 4X, NEMA 13 | No | 4 | 3/16" | CSA Certified, C-UL Listed, UL Listed | Gray | 00000000 | 000000 | 00000000 | 00000 |
| 6 1/4" | 6 1/4" | 4" | Corrosive, Damp, Dusty, Oily, Outdoor, Washdown | IP66, NEMA 4X, NEMA 13 | No | 4 | 1/4" | CSA Certified, C-UL Listed, UL Listed | Gray | 00000000 | 000000 | 00000000 | 00000 |
| 6 5/16" | 3 1/8" | 2 3/8" | Corrosive, Damp, Dusty, Oily, Outdoor, Washdown | IP66, NEMA 4X, NEMA 13 | No | 4 | 3/16" | CSA Certified, C-UL Listed, UL Listed | Gray | 00000000 | 000000 | 00000000 | 0000 |
| 7 1/8" | 4 3/4" | 4" | Corrosive, Damp, Dusty, Oily, Outdoor, Washdown | IP66, NEMA 4X, NEMA 13 | No | 6 | 1/4" | CSA Certified, C-UL Listed, UL Listed | Gray | 00000000 | 000000 | 00000000 | 00000 |
| 7 7/8" | 4" | 3 1/8" | Corrosive, Damp, Dusty, Oily, Outdoor, Washdown | IP66, NEMA 4X, NEMA 13 | No | 6 | 3/16" | CSA Certified, C-UL Listed, UL Listed | Gray | 00000000 | 000000 | 00000000 | 00000 |
| 7 7/8" | 7 7/8" | 4 3/4" | Corrosive, Damp, Dusty, Oily, Outdoor, Washdown | IP66, NEMA 4X, NEMA 13 | No | 4 | 1/4" | CSA Certified, C-UL Listed, UL Listed | Gray | 00000000 | 000000 | 00000000 | 00000 |
| 9 3/8" | 6 1/4" | 4" | Corrosive, Damp, Dusty, Oily, Outdoor, Washdown | IP66, NEMA 4X, NEMA 13 | No | 6 | 1/4" | CSA Certified, C-UL Listed, UL Listed | Gray | 00000000 | 000000 | 00000000 | 00000 |
| 9 1/2" | 4 3/4" | 4" | Corrosive, Damp, Dusty, Oily, Outdoor, Washdown | IP66, NEMA 4X, NEMA 13 | No | 4 | 1/4" | CSA Certified, C-UL Listed, UL Listed | Gray | 00000000 | 000000 | 00000000 | 00000 |
| 9 1/2" | 9 1/2" | 4 3/4" | Corrosive, Damp, Dusty, Oily, Outdoor, Washdown | IP66, NEMA 4X, NEMA 13 | No | 4 | 1/4" | CSA Certified, C-UL Listed, UL Listed | Gray | 00000000 | 000000 | 00000000 | 00000 |
| 11 3/4" | 7 7/8" | 4 3/4" | Corrosive, Damp, Dusty, Oily, Outdoor, Washdown | IP66, NEMA 4X, NEMA 13 | No | 6 | 1/4" | CSA Certified, C-UL Listed, UL Listed | Gray | 00000000 | 000000 | 00000000 | 00000 |
| 12 5/8" | 6 1/4" | 4" | Corrosive, Damp, Dusty, Oily, Outdoor, Washdown | IP66, NEMA 4X, NEMA 13 | No | 6 | 1/4" | CSA Certified, C-UL Listed, UL Listed | Gray | 00000000 | 000000 | 00000000 | 00000 |
| 12 5/8" | 12 5/8" | 4 3/4" | Corrosive, Damp, Dusty, Oily, Outdoor, Washdown | IP66, NEMA 4X, NEMA 13 | No | 6 | 1/4" | CSA Certified, C-UL Listed, UL Listed | Gray | 00000000 | 000000 | 00000000 | 00000 |
| 14 1/8" | 9 1/2" | 4 3/4" | Corrosive, Damp, Dusty, Oily, Outdoor, Washdown | IP66, NEMA 4X, NEMA 13 | No | 6 | 1/4" | CSA Certified, C-UL Listed, UL Listed | Gray | 00000000 | 000000 | 000000000 | 00000 |
| 15 3/4" | 7 7/8" | 4 3/4" | Corrosive, Damp, Dusty, Oily, Outdoor, Washdown | IP66, NEMA 4X, NEMA 13 | No | 6 | 1/4" | CSA Certified, C-UL Listed, UL Listed | Gray | 00000000 | 000000 | 000000000 | 00000 |
| 19" | 6 1/4" | 4" | Corrosive, Damp, Dusty, Oily, Outdoor, Washdown | IP66, NEMA 4X, NEMA 13 | No | 6 | 1/4" | CSA Certified, C-UL Listed, UL Listed | Gray | 00000000 | 000000 | 000000000 | 00000 |
| 19" | 9 1/2" | 4 3/4" | Corrosive, Damp, Dusty, Oily, Outdoor, Washdown | IP66, NEMA 4X, NEMA 13 | No | 6 | 1/4" | CSA Certified, C-UL Listed, UL Listed | Gray | 00000000 | 000000 | 000000000 | 00000 |
| 19" | 12 5/8" | 4 3/4" | Corrosive, Damp, Dusty, Oily, Outdoor, Washdown | IP66, NEMA 4X, NEMA 13 | No | 6 | 1/4" | CSA Certified, C-UL Listed, UL Listed | Gray | 00000000 | 000000 | 000000000 | 000000 |
| 25 1/4" | 12 5/8" | 4 3/4" | Corrosive, Damp, Dusty, Oily, Outdoor, Washdown | IP66, NEMA 4X, NEMA 13 | No | 6 | 1/4" | CSA Certified, C-UL Listed, UL Listed | Gray | 00000000 | 00000000 | 000000000 | 000000 |
Aluminum Submersible Enclosures
Lighter than stainless steel yet durable, these aluminum enclosures protect electronics from frequent washdowns and withstand periodic submersion in water. They won’t rust in outdoor environments and are easy to machine.
Install an optional panel inside these enclosures to mount components and DIN rail without drilling holes.
For technical drawings and 3-D models, click on a part number.
Enclosures | ||||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
Inside | Mounting | Optional Panels | ||||||||||||
| Height | Width | Depth | Height | Width | Depth | Environment | Environmental Rating | Number of Holes | Hole Diameter | Specifications Met | Each | Each | ||
With Lift Off Cover and Screws Closure | ||||||||||||||
| 2" | 1 3/4" | 1 1/4" | 1 3/4" | 1 1/2" | 1" | Corrosive, Damp, Dusty, Outdoor, Submersible, Washdown | IP68; NEMA 6P | 2 | 0.15" | UL Listed, C-UL Listed | 00000000 | 000000 | 000000 | 00 |
| 2 1/2" | 2 1/4" | 1 3/8" | 2 1/4" | 2" | 1 1/8" | Corrosive, Damp, Dusty, Outdoor, Submersible, Washdown | IP68; NEMA 6P | 2 | 0.16" | UL Listed, C-UL Listed | 00000000 | 00000 | 000000 | 00 |
| 3" | 3 1/8" | 2" | 2 3/4" | 2 5/8" | 1 3/4" | Corrosive, Damp, Dusty, Outdoor, Submersible, Washdown | IP68; NEMA 6P | 2 | 0.18" | UL Listed, C-UL Listed | 00000000 | 00000 | 00000000 | 00000 |
| 3 3/4" | 3 3/4" | 1 3/4" | 2 3/4" | 2 5/8" | 1 1/2" | Corrosive, Damp, Dusty, Oily, Outdoor, Submersible, Washdown | IP67; NEMA 4X; NEMA 13 | 2 | 0.175" | __ | 00000000 | 00000 | 000000 | 00 |
| 3 3/4" | 3 3/4" | 2 5/8" | 2 3/4" | 2 5/8" | 2 3/8" | Corrosive, Damp, Dusty, Oily, Outdoor, Submersible, Washdown | IP67; NEMA 4X; NEMA 13 | 2 | 0.176" | __ | 00000000 | 00000 | 000000 | 00 |
| 3 7/8" | 2 1/2" | 1 3/8" | 3 5/8" | 2 1/4" | 1 1/8" | Corrosive, Damp, Dusty, Outdoor, Submersible, Washdown | IP68; NEMA 6P | 2 | 0.16" | UL Listed, C-UL Listed | 00000000 | 00000 | 000000 | 00 |
| 4 3/4" | 4 3/4" | 3 1/4" | 4 1/4" | 4 3/8" | 2 7/8" | Corrosive, Damp, Dusty, Outdoor, Submersible, Washdown | IP68; NEMA 6P | 4 | 1/4" | UL Listed, C-UL Listed | 00000000 | 00000 | 00000000 | 00000 |
| 4 7/8" | 3 1/8" | 2 1/4" | 4 5/8" | 2 3/4" | 2" | Corrosive, Damp, Dusty, Outdoor, Submersible, Washdown | IP68; NEMA 6P | 2 | 0.16" | UL Listed, C-UL Listed | 00000000 | 00000 | 00000000 | 0000 |
| 5 7/8" | 2 1/2" | 1 3/8" | 5 5/8" | 2 1/4" | 1 1/4" | Corrosive, Damp, Dusty, Outdoor, Submersible, Washdown | IP68; NEMA 6P | 2 | 0.16" | UL Listed, C-UL Listed | 00000000 | 00000 | 000000 | 00 |
| 5 7/8" | 4" | 3" | 5" | 3" | 2 5/8" | Corrosive, Damp, Dusty, Oily, Outdoor, Submersible, Washdown | IP67; NEMA 4X; NEMA 13 | 4 | 0.175" | __ | 00000000 | 00000 | 000000 | 00 |
| 6" | 4 3/8" | 1 1/8" | 5 1/8" | 3 1/2" | 7/8" | Corrosive, Damp, Dusty, Oily, Outdoor, Submersible, Washdown | IP67; NEMA 4X; NEMA 13 | 4 | 0.177" | __ | 00000000 | 00000 | 000000 | 00 |
| 6 1/4" | 6 1/4" | 3 1/2" | 5 7/8" | 5 7/8" | 3 1/4" | Corrosive, Damp, Dusty, Outdoor, Submersible, Washdown | IP68; NEMA 6P | 4 | 0.28" | UL Listed, C-UL Listed | 00000000 | 00000 | 00000000 | 00000 |
| 6 7/8" | 3 1/8" | 2 3/8" | 6 1/2" | 2 3/4" | 2 1/8" | Corrosive, Damp, Dusty, Outdoor, Submersible, Washdown | IP68; NEMA 6P | 2 | 0.17" | UL Listed, C-UL Listed | 00000000 | 00000 | 000000 | 00 |
| 7 1/2" | 3 3/4" | 1 3/4" | 6 5/8" | 2 7/8" | 1 1/2" | Corrosive, Damp, Dusty, Oily, Outdoor, Submersible, Washdown | IP67; NEMA 4X; NEMA 13 | 2 | 0.176" | __ | 00000000 | 00000 | 000000 | 00 |
| 7 1/2" | 3 3/4" | 2 5/8" | 6 5/8" | 2 7/8" | 2 3/8" | Corrosive, Damp, Dusty, Oily, Outdoor, Submersible, Washdown | IP67; NEMA 4X; NEMA 13 | 2 | 0.176" | __ | 00000000 | 00000 | 000000 | 00 |
| 7 7/8" | 5 7/8" | 1 1/8" | 6 1/4" | 5" | 7/8" | Corrosive, Damp, Dusty, Oily, Outdoor, Submersible, Washdown | IP67; NEMA 4X; NEMA 13 | 4 | 0.177" | __ | 00000000 | 00000 | 000000 | 00 |
| 7 7/8" | 5 7/8" | 2" | 7" | 5" | 1 5/8" | Corrosive, Damp, Dusty, Oily, Outdoor, Submersible, Washdown | IP67; NEMA 4X; NEMA 13 | 4 | 0.175" | __ | 00000000 | 00000 | 000000 | 00 |
| 7 7/8" | 5 7/8" | 3" | 7" | 5" | 2 5/8" | Corrosive, Damp, Dusty, Oily, Outdoor, Submersible, Washdown | IP67; NEMA 4X; NEMA 13 | 4 | 0.175" | __ | 00000000 | 00000 | 000000 | 00 |
| 8 3/4" | 4 3/4" | 3 1/8" | 8 1/4" | 4 1/4" | 2 7/8" | Corrosive, Damp, Dusty, Outdoor, Submersible, Washdown | IP68; NEMA 6P | 4 | 0.31" | UL Listed, C-UL Listed | 00000000 | 00000 | 00000000 | 00000 |
| 9" | 7 7/8" | 4 3/8" | 7 3/8" | 8 5/8" | 4" | Corrosive, Damp, Dusty, Outdoor, Submersible, Washdown | IP68; NEMA 6P | 4 | 0.28" | UL Listed, C-UL Listed | 00000000 | 000000 | 00000000 | 00000 |
| 9 7/8" | 3 1/8" | 2 1/4" | 9 1/2" | 2 3/4" | 2" | Corrosive, Damp, Dusty, Outdoor, Submersible, Washdown | IP68; NEMA 6P | 2 | 0.17" | UL Listed, C-UL Listed | 00000000 | 00000 | 00000000 | 00000 |
| 10 1/4" | 6 1/4" | 3 1/2" | 9 3/4" | 5 7/8" | 3 1/4" | Corrosive, Damp, Dusty, Outdoor, Submersible, Washdown | IP68; NEMA 6P | 4 | 0.28" | UL Listed, C-UL Listed | 00000000 | 00000 | 00000000 | 00000 |
| 10 3/8" | 7 1/8" | 2 1/8" | 9 3/8" | 6 1/4" | 1 7/8" | Corrosive, Damp, Dusty, Oily, Outdoor, Submersible, Washdown | IP67; NEMA 4X; NEMA 13 | 4 | 0.177" | __ | 00000000 | 00000 | 000000 | 00 |
| 10 3/8" | 7 1/4" | 3 1/2" | 9 3/8" | 6 1/4" | 3 1/4" | Corrosive, Damp, Dusty, Oily, Outdoor, Submersible, Washdown | IP67; NEMA 4X; NEMA 13 | 4 | 0.177" | __ | 00000000 | 00000 | 000000 | 00 |
| 10 3/4" | 6 3/4" | 2 5/8" | 9 7/8" | 5 7/8" | 2 1/4" | Corrosive, Damp, Dusty, Oily, Outdoor, Submersible, Washdown | IP67; NEMA 4X; NEMA 13 | 4 | 0.176" | __ | 00000000 | 00000 | 000000 | 00 |
| 10 3/4" | 6 3/4" | 3 7/8" | 9 7/8" | 5 7/8" | 3 5/8" | Corrosive, Damp, Dusty, Oily, Outdoor, Submersible, Washdown | IP67; NEMA 4X; NEMA 13 | 4 | 0.176" | __ | 00000000 | 00000 | 000000 | 00 |
| 13" | 9 1/8" | 4 3/8" | 12 1/2" | 8 5/8" | 4 1/8" | Corrosive, Damp, Dusty, Outdoor, Submersible, Washdown | IP68; NEMA 6P | 4 | 0.26" | UL Listed, C-UL Listed | 00000000 | 000000 | 00000000 | 00000 |
| 14 1/8" | 6 1/4" | 3 1/2" | 13 5/8" | 5 3/4" | 3 1/4" | Corrosive, Damp, Dusty, Outdoor, Submersible, Washdown | IP68; NEMA 6P | 4 | 0.26" | UL Listed, C-UL Listed | 00000000 | 000000 | 00000000 | 00000 |
| 14 1/4" | 4 3/4" | 3 1/8" | 13 3/4" | 4 3/8" | 2 7/8" | Corrosive, Damp, Dusty, Outdoor, Submersible, Washdown | IP68; NEMA 6P | 4 | 0.26" | UL Listed, C-UL Listed | 00000000 | 00000 | 00000000 | 00000 |
Machine-Mount Aluminum Submersible Enclosures
Enclosure
Panel
Attach these enclosures to machine panels and walls by their mounting feet—no need to open the cover and expose sensors, switches, and other electronics in wet locations. Made of aluminum, they’re lighter in weight than stainless steel yet resist rusting from water. They’re also easy to cut and drill for mounting components. All are NEMA and IP rated to protect what’s inside from submersion, spraying water, and rain, as well as dust, oil, and coolant.
Enclosures with circuit board slots let you easily space and store circuit boards.
Install panels inside enclosures to mount electronics and DIN rail without drilling holes.
For technical drawings and 3-D models, click on a part number.
Enclosures | |||||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
Inside | Mounting | Panels | |||||||||||||
| Height | Width | Depth | Height | Width | Depth | Environmental Rating | Component Mount Type | Number of Holes | Hole Diameter | Specifications Met | Each | For Mounting Fastener Screw Size | Each | ||
With Lift Off Cover and Screws Closure | |||||||||||||||
| 2 5/8" | 2 3/8" | 1 3/8" | 2 1/4" | 2" | 1 1/8" | IP66; IP67; NEMA 4X; NEMA 6; NEMA 13 | __ | 4 | 0.22" | UL Listed, C-UL Listed | 0000000 | 00000 | M3.5 | 0000000 | 00000 |
| 3 5/8" | 1 1/2" | 1 1/4" | 3 1/4" | 1" | 7/8" | IP66; IP67; NEMA 4X; NEMA 6; NEMA 13 | Circuit Board Slots | 2 | 0.19" | UL Listed, C-UL Listed | 0000000 | 00000 | M3.5 | 0000000 | 0000 |
| 4 5/8" | 2 5/8" | 1 1/4" | 4 1/4" | 2 1/4" | 7/8" | IP66; IP67; NEMA 4X; NEMA 6; NEMA 13 | Circuit Board Slots | 4 | 0.19" | UL Listed, C-UL Listed | 0000000 | 00000 | M3.5 | 0000000 | 0000 |
| 4 5/8" | 2 5/8" | 2 1/4" | 4 1/8" | 2 1/4" | 1 7/8" | IP66; IP67; NEMA 4X; NEMA 6; NEMA 13 | Circuit Board Slots | 4 | 0.19" | UL Listed, C-UL Listed | 0000000 | 00000 | M3.5 | 0000000 | 0000 |
| 4 5/8" | 3 5/8" | 2 1/4" | 4 1/8" | 3" | 1 7/8" | IP66; IP67; NEMA 4X; NEMA 6; NEMA 13 | Circuit Board Slots | 4 | 0.19" | UL Listed, C-UL Listed | 0000000 | 00000 | M3.5 | 0000000 | 0000 |
| 4 3/4" | 4 3/4" | 4" | 4 1/8" | 4 1/8" | 3 3/4" | IP66; IP67; NEMA 4X; NEMA 6; NEMA 13 | Circuit Board Slots | 4 | 0.19" | UL Listed, C-UL Listed | 0000000 | 00000 | M3.5 | 0000000 | 0000 |
| 5" | 3 1/4" | 1 5/8" | 4 1/2" | 2 3/4" | 1 3/8" | IP66; IP67; NEMA 4X; NEMA 6; NEMA 13 | __ | 4 | 0.22" | UL Listed, C-UL Listed | 0000000 | 00000 | M3.5 | 0000000 | 0000 |
| 5" | 3 1/4" | 2 1/4" | 4 1/2" | 2 3/4" | 2" | IP66; IP67; NEMA 4X; NEMA 6; NEMA 13 | __ | 4 | 0.22" | UL Listed, C-UL Listed | 0000000 | 00000 | M3.5 | 0000000 | 0000 |
| 5 7/8" | 4 1/4" | 3" | 5 3/8" | 3 3/4" | 2 3/4" | IP66; IP67; NEMA 4X; NEMA 6; NEMA 13 | Circuit Board Slots | 4 | 0.19" | UL Listed, C-UL Listed | 0000000 | 00000 | M3.5 | 0000000 | 0000 |
| 6 1/4" | 6 1/4" | 4" | 5 7/8" | 5 7/8" | 3 3/4" | IP66; IP67; NEMA 4X; NEMA 6; NEMA 13 | Circuit Board Slots | 4 | 0.19" | UL Listed, C-UL Listed | 0000000 | 00000 | M3.5 | 0000000 | 00000 |
| 6 3/8" | 4" | 2 3/8" | 5 7/8" | 3 1/2" | 2 1/8" | IP66; IP67; NEMA 4X; NEMA 6; NEMA 13 | __ | 4 | 0.22" | UL Listed, C-UL Listed | 0000000 | 00000 | M3.5 | 0000000 | 0000 |
| 6 3/8" | 4" | 3 1/4" | 5 7/8" | 3 1/2" | 2 7/8" | IP66; IP67; NEMA 4X; NEMA 6; NEMA 13 | __ | 4 | 0.22" | UL Listed, C-UL Listed | 0000000 | 00000 | M3.5 | 0000000 | 0000 |
| 6 3/4" | 4 7/8" | 2 1/4" | 6 1/4" | 4 1/4" | 1 7/8" | IP66; IP67; NEMA 4X; NEMA 6; NEMA 13 | Circuit Board Slots | 4 | 0.19" | UL Listed, C-UL Listed | 0000000 | 00000 | M3.5 | 0000000 | 00000 |
| 7 7/8" | 4 3/4" | 3" | 7 1/2" | 4 3/8" | 2 3/4" | IP66; IP67; NEMA 4X; NEMA 6; NEMA 13 | __ | 4 | 0.22" | UL Listed, C-UL Listed | 0000000 | 00000 | M3.5 | 0000000 | 00000 |
| 8 7/8" | 5 3/4" | 2 1/4" | 8 3/8" | 5 3/8" | 1 7/8" | IP66; IP67; NEMA 4X; NEMA 6; NEMA 13 | Circuit Board Slots | 4 | 0.19" | UL Listed, C-UL Listed | 0000000 | 00000 | M3.5 | 0000000 | 00000 |
| 8 7/8" | 5 3/4" | 3 1/4" | 8 3/8" | 5 3/8" | 3" | IP66; IP67; NEMA 4X; NEMA 6; NEMA 13 | Circuit Board Slots | 4 | 0.19" | UL Listed, C-UL Listed | 0000000 | 00000 | M3.5 | 0000000 | 00000 |
| 10 1/4" | 6 3/8" | 3 5/8" | 9 3/4" | 5 7/8" | 3 3/8" | IP66; IP67; NEMA 4X; NEMA 6; NEMA 13 | __ | 4 | 0.19" | UL Listed, C-UL Listed | 0000000 | 00000 | M3.5 | 0000000 | 00000 |
Aluminum Weather-Resistant Enclosures
Made of aluminum, these enclosures resist corrosion from rain, sleet, and snow. While not as corrosion resistant as stainless steel, aluminum is lighter for better mobility, and also easier to machine for custom mounting. With an overhanging top for coverage from above, these enclosures are rated NEMA 3R for protection from dirt, falling liquids, and light splashing. A bonding stud on the door maintains electric potential for connected equipment and also prevents static sparking that could damage components. To draw away static and protect from fire and shocks caused by short circuiting, connect these enclosures to a grounding path with the included grounding stud.
For technical drawings and 3-D models, click on a part number.
Mounting | |||||||||
|---|---|---|---|---|---|---|---|---|---|
| Height | Width | Depth | Environment | Environmental Rating | Number of Holes | Hole Diameter | Specifications Met | Each | |
With Lift-Off Cover and Screw Closure | |||||||||
| 6" | 6" | 4" | Outdoor | NEMA 3R; IP24 | 4 | 1/4" | UL Listed, CSA Certified | 0000000 | 000000 |
| 8" | 8" | 4" | Outdoor | NEMA 3R; IP24 | 4 | 1/4" | UL Listed, CSA Certified | 0000000 | 00000 |
| 8" | 8" | 6" | Outdoor | NEMA 3R; IP24 | 4 | 1/4" | UL Listed, CSA Certified | 0000000 | 00000 |
| 10" | 10" | 4" | Outdoor | NEMA 3R; IP24 | 4 | 1/4" | UL Listed, CSA Certified | 0000000 | 000000 |
| 10" | 10" | 6" | Outdoor | NEMA 3R; IP24 | 4 | 1/4" | UL Listed, CSA Certified | 0000000 | 000000 |
| 12" | 12" | 4" | Outdoor | NEMA 3R; IP24 | 4 | 1/4" | UL Listed, CSA Certified | 0000000 | 000000 |
| 12" | 12" | 6" | Outdoor | NEMA 3R; IP24 | 4 | 1/4" | UL Listed, CSA Certified | 0000000 | 000000 |
Weather-Resistant Enclosures with Cooling Fans
With One Fan
With Two Fans
Fans built in to these enclosures keep electronics at the temperature you set, and the filtered intake and exhaust let cool air flow through the enclosure without letting water and contaminants in. Rated NEMA 3R and IP32, these enclosures protect the components inside from falling dirt, rain, snow, and sleet. The overhanging top keeps drips out while the door is open. Enclosures are UL and CL-Listed, so they meet American and Canadian safety standards.
For technical drawings and 3-D models, click on a part number.
Enclosures | Panels | Replacement Filters | ||||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Height | Width | Depth | Airflow, cfm | Voltage | Current, A | Temperature Setting, °F | Environmental Rating | Material | Color | Specifications Met | Each | Each | Each | |||
With Hinged Cover and Slotted Latch | ||||||||||||||||
| 56" | 36" | 21 3/4" | 400 | 120V AC | 0.7 | 70° to 140° | NEMA 3R; IP32 | Powder-Coated Aluminum | White | UL Listed C-UL Listed | 0000000 | 000000000 | 00000000 | 0000000 | 0000000 | 000000 |
| 67" | 36" | 21 3/4" | 500 | 120V AC | 1.4 | 70° to 140° | NEMA 3R; IP32 | Powder-Coated Aluminum | White | UL Listed C-UL Listed | 0000000 | 00000000 | 0000000 | 000000 | 0000000 | 00000 |
Push-Button Hazardous Location Enclosures
UL and C-UL classified, these enclosures safely house push-button controls and electronics where there’s explosive dust and gas. They have holes already drilled to standard button sizes and conduit connections that let you route wire through the enclosure, saving you effort and time. NEMA rated, they also protect what’s inside from dust, rain, and spraying water.
For technical drawings and 3-D models, click on a part number.
Inside | Connection | ||||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Number of Columns | Number of Rows | Height | Width | Depth | Height | Width | Depth | Environment | Thread Type | Pipe Size | Features | Specifications Met | Color | Each | |
Aluminum with Lift-Off Cover and Screw Closure | |||||||||||||||
For 19 mm Push Button | |||||||||||||||
| 1 | 1 | 4 1/2" | 4 1/2" | 4 3/8" | 3" | 3" | 3 7/8" | Corrosive, Damp, Dusty, Hazardous Location, Outdoor, Washdown | NPT | 3/4 | Grounding Stud; Mounting Feet | UL Classified, C-UL Classified | Gray | 0000000 | 0000000 |
| 1 | 2 | 7 1/16" | 4 1/2" | 4 3/16" | 6" | 3" | 3 3/4" | Corrosive, Damp, Dusty, Hazardous Location, Outdoor, Washdown | NPT | 3/4 | Grounding Stud; Mounting Feet | UL Classified, C-UL Classified | Gray | 0000000 | 000000 |
| 1 | 3 | 8 1/8" | 4 1/2" | 4 3/16" | 7" | 3" | 3 11/16" | Corrosive, Damp, Dusty, Hazardous Location, Outdoor, Washdown | NPT | 3/4 | Grounding Stud; Mounting Feet | UL Classified, C-UL Classified | Gray | 0000000 | 000000 |
| 1 | 4 | 10 1/16" | 4 1/2" | 4 1/4" | 9" | 3" | 3 3/4" | Corrosive, Damp, Dusty, Hazardous Location, Outdoor, Washdown | NPT | 1 | Grounding Stud; Mounting Feet | UL Classified, C-UL Classified | Gray | 0000000 | 000000 |
| 1 | 5 | 12 1/16" | 4 1/2" | 4 1/4" | 11" | 3" | 3 3/4" | Corrosive, Damp, Dusty, Hazardous Location, Outdoor, Washdown | NPT | 1 1/4 | Grounding Stud; Mounting Feet | UL Classified, C-UL Classified | Gray | 0000000 | 000000 |
| 1 | 6 | 14 1/16" | 4 1/2" | 4 1/8" | 13" | 3" | 3 5/8" | Corrosive, Damp, Dusty, Hazardous Location, Outdoor, Washdown | NPT | 1 1/4 | Grounding Stud; Mounting Feet | UL Classified, C-UL Classified | Gray | 0000000 | 000000 |
| 1 | 7 | 16" | 4 1/2" | 4 1/8" | 15" | 3" | 3 5/8" | Corrosive, Damp, Dusty, Hazardous Location, Outdoor, Washdown | NPT | 1 1/4 | Grounding Stud; Mounting Feet | UL Classified, C-UL Classified | Gray | 0000000 | 000000 |
Hazardous Location Enclosures
With Lift-Off Cover
With Hinged Cover
For use in hazardous locations, these enclosures are rated NEMA 7 and 9 and meet UL Class I, Divisions 1 and 2, Groups B, C, and D; Class II, Divisions 1 and 2, Groups E, F, and G; and Class III, Divisions 1 and 2. They are also rated NEMA 4 for protection from dirt and washdowns.
Panels are for mounting components inside enclosures.
For technical drawings and 3-D models, click on a part number.
Enclosures | Panels | |||||||||
|---|---|---|---|---|---|---|---|---|---|---|
| Ht. | Wd. | Dp. | Wall Thick. | Environment | Environmental Rating | Specifications Met | Each | Each | ||
Aluminum with Lift-Off Cover and Screw Closure | ||||||||||
| 10 1/4" | 10 1/4" | 6" | 1/2" | Hazardous Location, Washdown | NEC Class I Divisions 1, 2 Groups B, C, D NEC Class II Divisions 1, 2 Groups E, F, G NEC Class III Divisions 1, 2 NEC Zone 1 Groups IIB, IIA IP66 NEMA 4 NEMA 7 NEMA 9 | UL Listed, UL 698, UL 886, UL 1203, CSA Certified | 0000000 | 000000000 | 0000000 | 0000000 |
| 12 1/4" | 12 1/4" | 8" | 1/2" | Hazardous Location, Washdown | NEC Class I Divisions 1, 2 Groups B, C, D NEC Class II Divisions 1, 2 Groups E, F, G NEC Class III Divisions 1, 2 NEC Zone 1 Groups IIB, IIA IP66 NEMA 4 NEMA 7 NEMA 9 | UL Listed, UL 698, UL 886, UL 1203, CSA Certified | 0000000 | 00000000 | 0000000 | 000000 |
| 12 1/4" | 14 1/4" | 8 1/4" | 1/2" | Hazardous Location, Washdown | NEC Class I Divisions 1, 2 Groups B, C, D NEC Class II Divisions 1, 2 Groups E, F, G NEC Class III Divisions 1, 2 NEC Zone 1 Groups IIB, IIA IP66 NEMA 4 NEMA 7 NEMA 9 | UL Listed, UL 698, UL 886, UL 1203, CSA Certified | 0000000 | 00000000 | 0000000 | 000000 |
Aluminum with Hinged Cover and Screw Closure | ||||||||||
| 16 1/2" | 16 1/2" | 8 3/4" | 3/4" | Hazardous Location, Washdown | NEC Class I Divisions 1, 2 Groups B, C, D NEC Class II Divisions 1, 2 Groups E, F, G NEC Class III Divisions 1, 2 NEC Zone 1 Groups IIB, IIA IP66 NEMA 4 NEMA 7 NEMA 9 | UL Listed, UL 698, UL 886, UL 1203, CSA Certified | 0000000 | 00000000 | 0000000 | 000000 |
| 16 1/2" | 16 1/2" | 10 3/4" | 3/4" | Hazardous Location, Washdown | NEC Class I Divisions 1, 2 Groups B, C, D NEC Class II Divisions 1, 2 Groups E, F, G NEC Class III Divisions 1, 2 NEC Zone 1 Groups IIB, IIA IP66 NEMA 4 NEMA 7 NEMA 9 | UL Listed, UL 698, UL 886, UL 1203, CSA Certified | 0000000 | 00000000 | 0000000 | 000000 |
EMI/RFI Shielded Enclosures
These enclosures reduce electromagnetic interference (EMI) and radio frequency interference (RFI), which can cause electrical problems like flickering monitors, interrupted data signals, and unwanted radio noise. Use them near motors, generators, and other equipment that produces EMI or RFI. Enclosures protect the parts inside and also keep EMI/RFI generated within the enclosure from getting out.
To install parts inside the enclosure, screw a DIN rail or panel on to the internal mounting bosses, or mount components directly to the bosses using self-tapping screws. Use the outside mounting holes to attach the enclosure to a wall or surface. For more mounting flexibility, screw on wall-mount brackets where you need them.
Aluminum enclosures stop medium-range frequency interference in most applications. They have two gaskets—a woven steel gasket joins the two sides of the enclosure for continuous EMI/RFI shielding, and a silicone rubber gasket seals the enclosure to protect your equipment from wet, oily, and corrosive environments. Enclosures that meet IP65 protect the contents from washdowns, dust, and dirt. Enclosures that meet IP67 are submersible in one meter of water for up to 30 minutes and protect the contents from dust and dirt.
Interference reduction at frequency, also known as attenuation, is how much EMI/RFI the enclosure blocks.
For technical drawings and 3-D models, click on a part number.
Aluminum
Silicone and Woven Steel Gaskets
Aluminum
Aluminum Panel
Wall-Mount Brackets
Enclosures | Wall Mount Brackets | Panels | |||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Height | Width | Depth | Interference Reduction @ Frequency | Environment | Environmental Rating | Each | Pkg. Qty. | Pkg. | For Mounting Fastener Screw Size | Each | |||
With Lift-Off Cover and Screw Closure | |||||||||||||
| 3 3/4" | 3 3/4" | 1 3/4" | 70 dB @ 1 GHz | Corrosive, Damp, Oily, Outdoor, Submersible, Washdown | IP67; NEMA 4X; NEMA 13 | 0000000 | 000000 | 4 | 0000000 | 00000 | M3.5 | 0000000 | 00000 |
| 3 3/4" | 3 3/4" | 2 5/8" | 70 dB @ 1 GHz | Corrosive, Damp, Oily, Outdoor, Submersible, Washdown | IP67; NEMA 4X; NEMA 13 | 0000000 | 00000 | 4 | 0000000 | 0000 | M3.5 | 0000000 | 0000 |
| 5 7/8" | 4" | 2" | 70 dB @ 1 GHz | Corrosive, Damp, Oily, Outdoor, Submersible, Washdown | IP67; NEMA 4X; NEMA 13 | 0000000 | 00000 | 4 | 0000000 | 0000 | M3.5 | 0000000 | 0000 |
| 5 7/8" | 4" | 3" | 70 dB @ 1 GHz | Corrosive, Damp, Oily, Outdoor, Submersible, Washdown | IP67; NEMA 4X; NEMA 13 | 0000000 | 00000 | 4 | 0000000 | 0000 | M3.5 | 0000000 | 0000 |
| 6" | 4 1/2" | 1 1/4" | 70 dB @ 1 GHz | Corrosive, Damp, Oily, Outdoor, Submersible, Washdown | IP67; NEMA 4X; NEMA 13 | 0000000 | 00000 | 4 | 0000000 | 0000 | M3.5 | 0000000 | 0000 |
| 6" | 4 1/2" | 2 1/4" | 70 dB @ 1 GHz | Corrosive, Damp, Oily, Outdoor, Submersible, Washdown | IP67; NEMA 4X; NEMA 13 | 0000000 | 00000 | 4 | 0000000 | 0000 | M3.5 | 0000000 | 0000 |
| 6 3/8" | 6 3/8" | 2 1/4" | 70 dB @ 1 GHz | Corrosive, Damp, Oily, Outdoor, Submersible, Washdown | IP67; NEMA 4X; NEMA 13 | 0000000 | 00000 | 4 | 0000000 | 0000 | M3.5 | 0000000 | 0000 |
| 6 3/8" | 6 3/8" | 3 1/8" | 70 dB @ 1 GHz | Corrosive, Damp, Oily, Outdoor, Submersible, Washdown | IP67; NEMA 4X; NEMA 13 | 0000000 | 00000 | 4 | 0000000 | 0000 | M3.5 | 0000000 | 0000 |
| 7 1/2" | 3 3/4" | 1 3/4" | 70 dB @ 1 GHz | Corrosive, Damp, Oily, Outdoor, Submersible, Washdown | IP67; NEMA 4X; NEMA 13 | 0000000 | 00000 | 4 | 0000000 | 0000 | M3.5 | 0000000 | 0000 |
| 7 1/2" | 3 3/4" | 2 5/8" | 70 dB @ 1 GHz | Corrosive, Damp, Oily, Outdoor, Submersible, Washdown | IP67; NEMA 4X; NEMA 13 | 0000000 | 00000 | 4 | 0000000 | 0000 | M3.5 | 0000000 | 0000 |
| 7 7/8" | 5 7/8" | 1 1/8" | 70 dB @ 1 GHz | Corrosive, Damp, Oily, Outdoor, Submersible, Washdown | IP67; NEMA 4X; NEMA 13 | 0000000 | 00000 | 4 | 0000000 | 0000 | __ | 000000 | 00 |
| 7 7/8" | 6" | 2" | 70 dB @ 1 GHz | Corrosive, Damp, Oily, Outdoor, Submersible, Washdown | IP67; NEMA 4X; NEMA 13 | 0000000 | 00000 | 4 | 0000000 | 0000 | M3.5 | 0000000 | 0000 |
| 7 7/8" | 6" | 3" | 70 dB @ 1 GHz | Corrosive, Damp, Oily, Outdoor, Submersible, Washdown | IP67; NEMA 4X; NEMA 13 | 0000000 | 00000 | 4 | 0000000 | 0000 | M3.5 | 0000000 | 0000 |
| 8" | 5 5/8" | 2 1/4" | 70 dB @ 1 GHz | Corrosive, Damp, Oily, Outdoor, Submersible, Washdown | IP67; NEMA 4X; NEMA 13 | 0000000 | 00000 | 4 | 0000000 | 0000 | M3.5 | 0000000 | 0000 |
| 8" | 5 5/8" | 3 1/8" | 70 dB @ 1 GHz | Corrosive, Damp, Oily, Outdoor, Submersible, Washdown | IP67; NEMA 4X; NEMA 13 | 0000000 | 00000 | 4 | 0000000 | 0000 | M3.5 | 0000000 | 0000 |
| 10 3/8" | 7 1/4" | 2 1/4" | 70 dB @ 1 GHz | Corrosive, Damp, Oily, Outdoor, Submersible, Washdown | IP67; NEMA 4X; NEMA 13 | 0000000 | 00000 | 4 | 0000000 | 0000 | M3.5 | 0000000 | 0000 |
| 10 3/8" | 7 1/4" | 3 5/8" | 70 dB @ 1 GHz | Corrosive, Damp, Oily, Outdoor, Submersible, Washdown | IP67; NEMA 4X; NEMA 13 | 0000000 | 000000 | 4 | 0000000 | 0000 | M3.5 | 0000000 | 0000 |
| 10 3/4" | 6 3/4" | 2 5/8" | 70 dB @ 1 GHz | Corrosive, Damp, Oily, Outdoor, Submersible, Washdown | IP67; NEMA 4X; NEMA 13 | 0000000 | 00000 | 4 | 0000000 | 0000 | M3.5 | 0000000 | 0000 |
| 10 3/4" | 6 3/4" | 4" | 70 dB @ 1 GHz | Corrosive, Damp, Oily, Outdoor, Washdown | IP65; NEMA 4X; NEMA 13 | 0000000 | 00000 | 4 | 0000000 | 0000 | M3.5 | 0000000 | 0000 |
Enclosure-Mounted Terminal Blocks
Save time when wiring connections in a junction box. These blocks come already installed in an enclosure. All enclosures are IP and NEMA rated to seal out dust and protect against corrosion. They meet UL 94 flammability standards.
Aluminum enclosures are more durable than plastic ones, so they’re good for harsh environments where debris would damage plastic enclosures.
IP67 rated enclosures withstand temporary submersion. NEMA 12 rated enclosures withstand lightly splashing water, oil, and coolant.
For technical drawings and 3-D models, click on a part number.
Side-Mounted Screw Terminals
Gray Powder-Coated Aluminum
| No. of Circuits | Voltage | Current Per Circuit, A | For Wire Gauge | Terminal Size | Terminal Ctr.-to-Ctr. | Ht. | Wd. | Dp. | Environmental Rating | Mount. Fasteners Included | Specifications Met | Each | |
Gray Powder-Coated Aluminum | |||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 4 | 120V AC | 15 | 20-14 | No. 6 | 5/16" | 2 3/4" | 2 3/8" | 1 7/8" | IP67, NEMA 12 | No | TUV SUD Certified, C-TUV SUD Certified, CE Marked, UL 94 V-0, UL 508A | 00000000 | 000000 |
| 6 | 120V AC | 15 | 20-14 | No. 6 | 5/16" | 3 11/16" | 2 3/4" | 2 1/16" | IP67, NEMA 12 | No | TUV SUD Certified, C-TUV SUD Certified, CE Marked, UL 94 V-0, UL 508A | 00000000 | 00000 |
| 10 | 120V AC | 15 | 20-14 | No. 6 | 5/16" | 5 1/16" | 2 3/4" | 2 1/16" | IP67, NEMA 12 | No | TUV SUD Certified, C-TUV SUD Certified, CE Marked, UL 94 V-0, UL 508A | 00000000 | 00000 |
| 15 | 120V AC | 15 | 20-14 | No. 6 | 5/16" | 6 3/4" | 2 3/4" | 2 3/16" | IP67, NEMA 12 | No | TUV SUD Certified, C-TUV SUD Certified, CE Marked, UL 94 V-0, UL 508A | 00000000 | 00000 |
| 20 | 120V AC | 15 | 20-14 | No. 6 | 5/16" | 9 1/4" | 3 1/8" | 3 1/8" | IP67, NEMA 12 | No | TUV SUD Certified, C-TUV SUD Certified, CE Marked, UL 94 V-0, UL 508A | 00000000 | 00000 |
Center-Mounted Screw Terminals
Gray Powder-Coated Aluminum
| No. of Circuits | Voltage | Current Per Circuit, A | For Wire Gauge | Terminal Size | Terminal Ctr.-to-Ctr. | Ht. | Wd. | Dp. | Environmental Rating | Mount. Fasteners Included | Specifications Met | Each | |
Gray Powder-Coated Aluminum | |||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 12 | 120V AC | 15 | 20-14 | No. 6 | 5/16" | 4 5/16" | 4 5/16" | 2 1/16" | IP67, NEMA 12 | No | TUV SUD Certified, C-TUV SUD Certified, CE Marked, UL 94 V-0, UL 508A | 00000000 | 000000 |
| 20 | 120V AC | 15 | 20-14 | No. 6 | 5/16" | 5 11/16" | 4 15/16" | 2 7/16" | IP67, NEMA 12 | No | TUV SUD Certified, C-TUV SUD Certified, CE Marked, UL 94 V-0, UL 508A | 00000000 | 00000 |
| 30 | 120V AC | 15 | 20-14 | No. 6 | 5/16" | 7 1/2" | 4 15/16" | 3 1/8" | IP67, NEMA 12 | No | TUV SUD Certified, C-TUV SUD Certified, CE Marked, UL 94 V-0, UL 508A | 00000000 | 00000 |
| 40 | 120V AC | 15 | 20-14 | No. 6 | 5/16" | 10 1/4" | 6 5/16" | 3 9/16" | IP67, NEMA 12 | No | TUV SUD Certified, C-TUV SUD Certified, CE Marked, UL 94 V-0, UL 508A | 00000000 | 000000 |
