Steel Oversized Washer
for 1/2" Screw Size, 0.531" ID, 1.000" OD
2-D PDF
000000 per pack of 10
91201A033
In stock
91201A033
000000 per pack of 10
Pack of 10
Select a compatible file type: Parasolid
Available for Solidworks 2017 or newer.
Washer Designation | Oversized |
Material | Steel |
For Screw Size | 1/2" |
ID | 0.531" |
OD | 1.000" |
Thickness | 0.183" to 0.193" |
Certificate Form | Digital |
Certificate Type | Material Certificate with Traceable Lot Number |
Hardness | Rockwell B84 |
System of Measurement | Inch |
Washer Type | Flat |
Country of Origin | United States |
DFARS Compliance | Specialty Metals COTS-Exempt |
Export Control Classification Number (ECCN) | EAR99 |
REACH Compliance | REACH (EC 1907/2006) (02/04/2026, 253 SVHC) Compliant |
RoHS Compliance | RoHS 3 (2015/863/EU) Compliant with Exemptions |
RoHS Exemptions | 6(a) |
Schedule B Number | 731822.0000 |
U.S.–Mexico–Canada Agreement (USMCA) Qualifying | Yes |
Cover oversized holes or use these washers as spacers and levelers. Compared to general purpose washers, these have a larger diameter or thickness.
Steel—Best for dry environments since moisture will cause these washers to rust.
Material Certificate—Washers include a report with a traceable lot number.
Compatible Products for This Washer
The information in this 3-D model is provided for reference only.
