Cleated Belting for Slider-Bed Conveyors
Cleats keep material on the belt when traveling along inclines and declines. A low-friction bottom surface allows belting to glide along slider-bed conveyors.
Note: The cleats of the belt should be removed with a conveyor belt shaver or skiver before installing lacing.
White belting is appropriate for food applications when used with stainless steel lacing. It resists animal fats and oils.
Black belting is also known as MOR belting due to its mild oil resistance.
For technical drawings and 3-D models, click on a part number.
Cleat | For Lace No. | ||||||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Thick. | For Min. Pulley Dia. | Max. Incline | Max. Belt Tension, PIW | Ht. | Spacing | Construction | Max. Temp., °F | Quick-Install Hook-Style | Hammer-On Hook-Style | 4" Wd. Per Ft. | 6" Wd. Per Ft. | 8" Wd. Per Ft. | 10" Wd. Per Ft. | 12" Wd. Per Ft. | 18" Wd. Per Ft. | 24" Wd. Per Ft. | |
| 0.250" | 2" | 30° | 150 | 1/8" | 1" | 3 Ply | 250° | 2 | 15S | 000000 | |||||||
Rough-Top Belting for Slider-Bed Conveyors
The textured surface grips packages and cartons to prevent material from slipping when traveling on inclines and declines. A low-friction bottom surface allows belting to glide along the bed of the conveyor. Use belting with hammer-on hook-style lacing or quick-install hook-style lacing.
Note: The top surface of the belt ends should be removed with a conveyor belt shaver or skiver before installing lacing. Recommended lacing is based on the thickness of the belt after removing the top surface.
PVC resists impact and tears.
Neoprene has a good grip along with superior oil resistance.
Buna-N has a hard textured surface that resists punctures and abrasion.
SBR has good impact resistance and an excellent grip.
For technical drawings and 3-D models, click on a part number.
For Lace No. | ||||||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Thick. | For Min. Pulley Dia. | Max. Belt Tension, PIW | Construction | Max. Temp., °F | Quick-Install Hook-Style | Hammer-On Hook-Style | 2" Wd. Per Ft. | 3" Wd. Per Ft. | 4" Wd. Per Ft. | 6" Wd. Per Ft. | 8" Wd. Per Ft. | 10" Wd. Per Ft. | 12" Wd. Per Ft. | 18" Wd. Per Ft. | 24" Wd. Per Ft. | |
Green PVC Plastic | ||||||||||||||||
| 0.210" | 2 1/2" | 46 | 2 Ply | 155° | UCM36LL | 7 | 000000 | |||||||||
Black Neoprene Rubber | ||||||||||||||||
| 0.300" | 3" | 225 | 3 Ply | 250° | 1 | 7 | 000000 | |||||||||
Blue Buna-N Rubber | ||||||||||||||||
| 0.310" | 2 1/2" | 150 | 3 Ply | 250° | 2 | 15 | 000000 | |||||||||
Black SBR Rubber | ||||||||||||||||
| 0.250" | 2" | 150 | 2 Ply | 250° | 1 | 7 | 000000 | |||||||||
Beige SBR Rubber | ||||||||||||||||
| 0.265" | 3" | 200 | 3 Ply | 250° | 2 | 7 | 000000 | |||||||||
Cleats for Conveyor Belts
Use these cleats to convert any smooth conveyor belt into a belt for inclines. Cut cleats to the length you need with a utility knife.
EPDM is more durable than Buna-N, and has better resistance to acids and weather. Attach cleats to the belt with the included fasteners.
Buna-N has a smooth surface that is easy to clean and prevents build up of debris. It resists acids, abrasion, and weather. Cleats have integral threaded inserts for a secure connection.
| Ht. | Lg. | For Max. Belt Thick. | For Min. Pulley Dia. | Max. Temp., °F | Mount Type | Includes | Specifications Met | Each | ||
Black EPDM Rubber | ||||||||||
|---|---|---|---|---|---|---|---|---|---|---|
| A | 1 1/4" | 48" | 0.430" | 3" | 300° | Bolt On | Mounting Fasteners | __ | 0000000 | 000000 |
| A | 2" | 48" | 0.430" | 3" | 300° | Bolt On | Mounting Fasteners | __ | 0000000 | 00000 |
| A | 3" | 48" | 0.430" | 3" | 300° | Bolt On | Mounting Fasteners | __ | 0000000 | 000000 |
| A | 4" | 48" | 0.550" | 4" | 300° | Bolt On | Mounting Fasteners | __ | 0000000 | 000000 |
Black Buna-N Rubber | ||||||||||
| B | 5/8" | 24" | 0.310" | 2" | 240° | Bolt On | Integral Threaded Inserts, Stainless Steel Mounting Fasteners | FDA Compliant 21 CFR 177.2600 | 0000000 | 00000 |
| B | 1" | 24" | 0.310" | 2" | 240° | Bolt On | Integral Threaded Inserts, Stainless Steel Mounting Fasteners | FDA Compliant 21 CFR 177.2600 | 0000000 | 00000 |
| B | 1 1/2" | 24" | 0.310" | 2" | 240° | Bolt On | Integral Threaded Inserts, Stainless Steel Mounting Fasteners | FDA Compliant 21 CFR 177.2600 | 0000000 | 00000 |
| B | 2" | 24" | 0.310" | 2" | 240° | Bolt On | Integral Threaded Inserts, Stainless Steel Mounting Fasteners | FDA Compliant 21 CFR 177.2600 | 0000000 | 000000 |
White Buna-N Rubber | ||||||||||
| C | 5/8" | 24" | 0.310" | 2" | 240° | Bolt On | Integral Threaded Inserts, Stainless Steel Mounting Fasteners | FDA Compliant 21 CFR 177.2600 | 0000000 | 00000 |
| C | 1" | 24" | 0.310" | 2" | 240° | Bolt On | Integral Threaded Inserts, Stainless Steel Mounting Fasteners | FDA Compliant 21 CFR 177.2600 | 0000000 | 00000 |
| C | 1 1/2" | 24" | 0.310" | 2" | 240° | Bolt On | Integral Threaded Inserts, Stainless Steel Mounting Fasteners | FDA Compliant 21 CFR 177.2600 | 0000000 | 00000 |
| C | 2" | 24" | 0.310" | 2" | 240° | Bolt On | Integral Threaded Inserts, Stainless Steel Mounting Fasteners | FDA Compliant 21 CFR 177.2600 | 0000000 | 000000 |
Cleated Belting for Roller-Bed Conveyors
Cleats keep material on the belt when traveling along inclines and declines. A tough cover on the bottom grips rollers.
Note: The cleats of the belt should be removed with a conveyor belt shaver or skiver before installing lacing.
White belting is appropriate for food applications when used with stainless steel lacing. It resists animal fats and oils.
Black belting is also known as MOR belting due to its mild oil resistance.
For technical drawings and 3-D models, click on a part number.
Cleat | |||||||||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Thick. | For Min. Pulley Dia. | Max. Incline | Max. Belt Tension, PIW | Ht. | Spacing | Construction | Max. Temp., °F | For Lacing Type | 4" Wd. Per Ft. | 6" Wd. Per Ft. | 8" Wd. Per Ft. | 10" Wd. Per Ft. | 12" Wd. Per Ft. | 18" Wd. Per Ft. | 24" Wd. Per Ft. | 30" Wd. Per Ft. | 36" Wd. Per Ft. | 48" Wd. Per Ft. | |
| 0.225" | 10" | 60° | 220 | 1/4" | 3" | 2 Ply | 200° | Bolt On | 000000 | ||||||||||
Conveyor Belt Shavers
Also known as skivers, these shavers remove the rough top surface of a conveyor belt for secure lacing connections.
Material | ||||
|---|---|---|---|---|
| Overall Lg. | Blade | Handle | Each | |
| 6 1/2" | Steel | Wood | 0000000 | 000000 |
Battery-Powered Conveyor Belt Shavers
Quickly and accurately remove material from the surface of conveyor belts to prepare them for fastening. These shavers come with rechargeable batteries, so you can take them wherever they’re needed. They’re powered with an attached cordless drill, giving you more control over cuts than manual skivers. Run the drill at low speed for the most control.
Overall | Material | |||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| For Belt Thick. | Ht. | Wd. | Dp. | Max. Cutting Wd. | Cutting Dp. | Blade | Body | Battery Charging Time, hrs. | Battery Cap., amp-hrs. | No. of Batteries Included | Battery Charger Included | Includes | Each | |
| 1/4"-1 1/4" | 10" | 10" | 12 1/2" | 2 1/2" | 1/16" to 3/8" | Steel | Steel | 2 | 5 | 2 | Yes | Plastic Carrying Case | 0000000 | 000000000 |
| 7/8"-1 3/4" | 10 1/2" | 10" | 12 1/2" | 2 1/2" | 1/16" to 3/8" | Steel | Steel | 2 | 5 | 2 | Yes | Plastic Carrying Case | 0000000 | 00000000 |
