About Selecting Pipe Markers
More
Made-to-Order Adhesive-Back Pipe Markers
![](/prerenderstable/mvPRE/contents/gfx/imagecache/949/9498t151p2-i02c-master1577465684@halfx_637130408906977474.png?ver=imagenotfound)
Specify the message you need to label the contents of a pipe (two lines maximum, up to 28 characters per line, including spaces). Apply these markers directly onto clean, dry pipes.
For technical drawings and 3-D models, click on a part number.
For Pipe OD | Character Ht. | Ht. | Wd. | Thick. | Flow-Direction Arrow | Material | Temp. Range, °F | Pkg. Qty. | Pkg. | |
Made to Order (English, English/Spanish, Spanish) | ||||||||||
---|---|---|---|---|---|---|---|---|---|---|
Blue with White Message | ||||||||||
3/4"-2" | 3/4" | 2" | 8" | 0.004" | No | Vinyl Plastic | -40° to 170° | 10 | 00000000 | 000000 |
2 1/4"-7 7/8" | 1 3/4" | 2 1/4" | 13" | 0.004" | No | Vinyl Plastic | -40° to 170° | 5 | 00000000 | 00000 |
8"-10" | 2 1/2" | 4" | 24" | 0.004" | No | Vinyl Plastic | -40° to 170° | 1 | 00000000 | 0000 |
Green with White Message | ||||||||||
3/4"-2" | 3/4" | 2" | 8" | 0.004" | No | Vinyl Plastic | -40° to 170° | 10 | 00000000 | 00000 |
2 1/4"-7 7/8" | 1 3/4" | 2 1/4" | 13" | 0.004" | No | Vinyl Plastic | -40° to 170° | 5 | 00000000 | 00000 |
8"-10" | 2 1/2" | 4" | 24" | 0.004" | No | Vinyl Plastic | -40° to 170° | 1 | 00000000 | 0000 |
Orange with Black Message | ||||||||||
3/4"-2" | 3/4" | 2" | 8" | 0.004" | No | Vinyl Plastic | -40° to 170° | 10 | 00000000 | 00000 |
2 1/4"-7 7/8" | 1 3/4" | 2 1/4" | 13" | 0.004" | No | Vinyl Plastic | -40° to 170° | 5 | 00000000 | 00000 |
8"-10" | 2 1/2" | 4" | 24" | 0.004" | No | Vinyl Plastic | -40° to 170° | 1 | 00000000 | 0000 |
Red with White Message | ||||||||||
3/4"-2" | 3/4" | 2" | 8" | 0.004" | No | Vinyl Plastic | -40° to 170° | 10 | 00000000 | 00000 |
2 1/4"-7 7/8" | 1 3/4" | 2 1/4" | 13" | 0.004" | No | Vinyl Plastic | -40° to 170° | 5 | 00000000 | 00000 |
8"-10" | 2 1/2" | 4" | 24" | 0.004" | No | Vinyl Plastic | -40° to 170° | 1 | 00000000 | 0000 |
Yellow with Black Message | ||||||||||
3/4"-2" | 3/4" | 2" | 8" | 0.004" | No | Vinyl Plastic | -40° to 170° | 10 | 00000000 | 00000 |
2 1/4"-7 7/8" | 1 3/4" | 2 1/4" | 13" | 0.004" | No | Vinyl Plastic | -40° to 170° | 5 | 00000000 | 00000 |
8"-10" | 2 1/2" | 4" | 24" | 0.004" | No | Vinyl Plastic | -40° to 170° | 1 | 00000000 | 0000 |
Made-to-Order Snap-On Pipe Markers
![](/prerenderstable/mvPRE/contents/gfx/imagecache/577/5774t34p1-i02c-master1577983628@halfx_637135588475950297.png?ver=imagenotfound)
Specify the message you need to label the contents of a pipe (two lines maximum, up to 50 characters per line, including spaces). These markers coil around pipes so they stay in place without adhesive. Markers for pipe OD 6" and larger secure with included nylon cable ties.
For technical drawings and 3-D models, click on a part number.
For Pipe OD | Character Ht. | Ht. | Wd. | Thick. | Flow-Direction Arrow | Material | Temp. Range, °F | Each | |
Made-to-Order Message (English, English/Spanish, Spanish) | |||||||||
---|---|---|---|---|---|---|---|---|---|
Blue with White Message | |||||||||
1/2"-1" | 1/2" | 6" | 8" | 0.02" | Yes | Vinyl Plastic | -40° to 160° | 00000000 | 00000 |
1 1/8"-2 1/4" | 3/4" | 8 1/2" | 8" | 0.02" | Yes | Vinyl Plastic | -40° to 160° | 00000000 | 0000 |
2 3/8"-3 1/4" | 1 1/4" | 12" | 12" | 0.02" | Yes | Vinyl Plastic | -40° to 160° | 00000000 | 00000 |
3 3/8"-4 1/2" | 1 1/4" | 17" | 12" | 0.02" | Yes | Vinyl Plastic | -40° to 160° | 00000000 | 00000 |
4 5/8"-5 7/8" | 1 1/4" | 21" | 12" | 0.02" | Yes | Vinyl Plastic | -40° to 160° | 00000000 | 00000 |
6"-7 7/8" | 1 1/4" | 8" | 12" | 0.02" | Yes | Vinyl Plastic | -40° to 160° | 00000000 | 00000 |
8"-10" | 2 1/2" | 10" | 24" | 0.02" | Yes | Vinyl Plastic | -40° to 160° | 00000000 | 00000 |
10 1/8"-15" | 3 1/2" | 10" | 32" | 0.02" | Yes | Vinyl Plastic | -40° to 160° | 00000000 | 00000 |
Green with White Message | |||||||||
1/2"-1" | 1/2" | 6" | 8" | 0.02" | Yes | Vinyl Plastic | -40° to 160° | 00000000 | 0000 |
1 1/8"-2 1/4" | 3/4" | 8 1/2" | 8" | 0.02" | Yes | Vinyl Plastic | -40° to 160° | 00000000 | 0000 |
2 3/8"-3 1/4" | 1 1/4" | 12" | 12" | 0.02" | Yes | Vinyl Plastic | -40° to 160° | 00000000 | 00000 |
3 3/8"-4 1/2" | 1 1/4" | 17" | 12" | 0.02" | Yes | Vinyl Plastic | -40° to 160° | 00000000 | 00000 |
4 5/8"-5 7/8" | 1 1/4" | 21" | 12" | 0.02" | Yes | Vinyl Plastic | -40° to 160° | 00000000 | 00000 |
6"-7 7/8" | 1 1/4" | 8" | 12" | 0.02" | Yes | Vinyl Plastic | -40° to 160° | 00000000 | 00000 |
8"-10" | 2 1/2" | 10" | 24" | 0.02" | Yes | Vinyl Plastic | -40° to 160° | 00000000 | 00000 |
10 1/8"-15" | 3 1/2" | 10" | 32" | 0.02" | Yes | Vinyl Plastic | -40° to 160° | 00000000 | 00000 |
Orange with Black Message | |||||||||
1/2"-1" | 1/2" | 6" | 8" | 0.02" | Yes | Vinyl Plastic | -40° to 160° | 00000000 | 0000 |
1 1/8"-2 1/4" | 3/4" | 8 1/2" | 8" | 0.02" | Yes | Vinyl Plastic | -40° to 160° | 00000000 | 0000 |
2 3/8"-3 1/4" | 1 1/4" | 12" | 12" | 0.02" | Yes | Vinyl Plastic | -40° to 160° | 00000000 | 00000 |
3 3/8"-4 1/2" | 1 1/4" | 17" | 12" | 0.02" | Yes | Vinyl Plastic | -40° to 160° | 00000000 | 00000 |
4 5/8"-5 7/8" | 1 1/4" | 21" | 12" | 0.02" | Yes | Vinyl Plastic | -40° to 160° | 00000000 | 00000 |
6"-7 7/8" | 1 1/4" | 8" | 12" | 0.02" | Yes | Vinyl Plastic | -40° to 160° | 00000000 | 00000 |
8"-10" | 2 1/2" | 10" | 24" | 0.02" | Yes | Vinyl Plastic | -40° to 160° | 00000000 | 00000 |
10 1/8"-15" | 3 1/2" | 10" | 32" | 0.02" | Yes | Vinyl Plastic | -40° to 160° | 00000000 | 00000 |
Red with White Message | |||||||||
1/2"-1" | 1/2" | 6" | 8" | 0.02" | Yes | Vinyl Plastic | -40° to 160° | 00000000 | 0000 |
1 1/8"-2 1/4" | 3/4" | 8 1/2" | 8" | 0.02" | Yes | Vinyl Plastic | -40° to 160° | 00000000 | 0000 |
2 3/8"-3 1/4" | 1 1/4" | 12" | 12" | 0.02" | Yes | Vinyl Plastic | -40° to 160° | 00000000 | 00000 |
3 3/8"-4 1/2" | 1 1/4" | 17" | 12" | 0.02" | Yes | Vinyl Plastic | -40° to 160° | 00000000 | 00000 |
4 5/8"-5 7/8" | 1 1/4" | 21" | 12" | 0.02" | Yes | Vinyl Plastic | -40° to 160° | 00000000 | 00000 |
6"-7 7/8" | 1 1/4" | 8" | 12" | 0.02" | Yes | Vinyl Plastic | -40° to 160° | 00000000 | 00000 |
8"-10" | 2 1/2" | 10" | 24" | 0.02" | Yes | Vinyl Plastic | -40° to 160° | 00000000 | 00000 |
10 1/8"-15" | 3 1/2" | 10" | 32" | 0.02" | Yes | Vinyl Plastic | -40° to 160° | 00000000 | 00000 |
Yellow with Black Message | |||||||||
1/2"-1" | 1/2" | 6" | 8" | 0.02" | Yes | Vinyl Plastic | -40° to 160° | 00000000 | 0000 |
1 1/8"-2 1/4" | 3/4" | 8 1/2" | 8" | 0.02" | Yes | Vinyl Plastic | -40° to 160° | 00000000 | 0000 |
2 3/8"-3 1/4" | 1 1/4" | 12" | 12" | 0.02" | Yes | Vinyl Plastic | -40° to 160° | 00000000 | 00000 |
3 3/8"-4 1/2" | 1 1/4" | 17" | 12" | 0.02" | Yes | Vinyl Plastic | -40° to 160° | 00000000 | 00000 |
4 5/8"-5 7/8" | 1 1/4" | 21" | 12" | 0.02" | Yes | Vinyl Plastic | -40° to 160° | 00000000 | 00000 |
6"-7 7/8" | 1 1/4" | 8" | 12" | 0.02" | Yes | Vinyl Plastic | -40° to 160° | 00000000 | 00000 |
8"-10" | 2 1/2" | 10" | 24" | 0.02" | Yes | Vinyl Plastic | -40° to 160° | 00000000 | 00000 |
10 1/8"-15" | 3 1/2" | 10" | 32" | 0.02" | Yes | Vinyl Plastic | -40° to 160° | 00000000 | 00000 |
Made-to-Order Washdown Pipe Markers
![](/prerenderstable/mvPRE/contents/gfx/imagecache/669/6698t13p1-i02cl1578000816@halfx_637135760172464167.png?ver=imagenotfound)
Specify the message you need to label a pipe (two lines maximum, up to 50 characters per line, including spaces). These fade-resistant pipe markers withstand detergents used in high-pressure cleaning. Wrap them around a pipe and seal in place with the adhesive strip.
For technical drawings and 3-D models, click on a part number.
For Pipe OD | Character Ht. | Ht. | Wd. | Thick. | Flow-Direction Arrow | Material | Temp. Range, °F | Each | |
Made to Order (English, English/Spanish, Spanish) | |||||||||
---|---|---|---|---|---|---|---|---|---|
Blue with White Message | |||||||||
5/8"-1" | 1/2" | 5" | 8" | 0.007" | Yes | Polyester Plastic | -40° to 250° | 0000000 | 00000 |
1 1/8"-2 1/2" | 3/4" | 9" | 8" | 0.007" | Yes | Polyester Plastic | -40° to 250° | 0000000 | 00000 |
2 1/2"-4 3/4" | 1 1/4" | 17" | 12" | 0.007" | Yes | Polyester Plastic | -40° to 250° | 0000000 | 00000 |
5"-7 7/8" | 1 1/4" | 26" | 12" | 0.007" | Yes | Polyester Plastic | -40° to 250° | 0000000 | 00000 |
8"-10" | 1 1/4" | 36" | 12" | 0.007" | Yes | Polyester Plastic | -40° to 250° | 0000000 | 00000 |
11"-12" | 1 1/4" | 43" | 12" | 0.007" | Yes | Polyester Plastic | -40° to 250° | 0000000 | 00000 |
13"-15" | 1 1/4" | 52" | 12" | 0.007" | Yes | Polyester Plastic | -40° to 250° | 0000000 | 00000 |
16"-18" | 1 1/4" | 62" | 12" | 0.007" | Yes | Polyester Plastic | -40° to 250° | 0000000 | 00000 |
Green with White Message | |||||||||
5/8"-1" | 1/2" | 5" | 8" | 0.007" | Yes | Polyester Plastic | -40° to 250° | 0000000 | 0000 |
1 1/8"-2 1/2" | 3/4" | 9" | 8" | 0.007" | Yes | Polyester Plastic | -40° to 250° | 0000000 | 00000 |
2 1/2"-4 3/4" | 1 1/4" | 17" | 12" | 0.007" | Yes | Polyester Plastic | -40° to 250° | 0000000 | 00000 |
5"-7 7/8" | 1 1/4" | 26" | 12" | 0.007" | Yes | Polyester Plastic | -40° to 250° | 0000000 | 00000 |
8"-10" | 1 1/4" | 36" | 12" | 0.007" | Yes | Polyester Plastic | -40° to 250° | 0000000 | 00000 |
11"-12" | 1 1/4" | 43" | 12" | 0.007" | Yes | Polyester Plastic | -40° to 250° | 0000000 | 00000 |
13"-15" | 1 1/4" | 52" | 12" | 0.007" | Yes | Polyester Plastic | -40° to 250° | 0000000 | 00000 |
16"-18" | 1 1/4" | 62" | 12" | 0.007" | Yes | Polyester Plastic | -40° to 250° | 0000000 | 00000 |
Orange with Black Message | |||||||||
5/8"-1" | 1/2" | 5" | 8" | 0.007" | Yes | Polyester Plastic | -40° to 250° | 0000000 | 0000 |
1 1/8"-2 1/2" | 3/4" | 9" | 8" | 0.007" | Yes | Polyester Plastic | -40° to 250° | 0000000 | 00000 |
2 1/2"-4 3/4" | 1 1/4" | 17" | 12" | 0.007" | Yes | Polyester Plastic | -40° to 250° | 0000000 | 00000 |
5"-7 7/8" | 1 1/4" | 26" | 12" | 0.007" | Yes | Polyester Plastic | -40° to 250° | 0000000 | 00000 |
8"-10" | 1 1/4" | 36" | 12" | 0.007" | Yes | Polyester Plastic | -40° to 250° | 0000000 | 00000 |
11"-12" | 1 1/4" | 43" | 12" | 0.007" | Yes | Polyester Plastic | -40° to 250° | 0000000 | 00000 |
13"-15" | 1 1/4" | 52" | 12" | 0.007" | Yes | Polyester Plastic | -40° to 250° | 0000000 | 00000 |
16"-18" | 1 1/4" | 62" | 12" | 0.007" | Yes | Polyester Plastic | -40° to 250° | 0000000 | 00000 |
Red with White Message | |||||||||
5/8"-1" | 1/2" | 5" | 8" | 0.007" | Yes | Polyester Plastic | -40° to 250° | 0000000 | 0000 |
1 1/8"-2 1/2" | 3/4" | 9" | 8" | 0.007" | Yes | Polyester Plastic | -40° to 250° | 0000000 | 00000 |
2 1/2"-4 3/4" | 1 1/4" | 17" | 12" | 0.007" | Yes | Polyester Plastic | -40° to 250° | 0000000 | 00000 |
5"-7 7/8" | 1 1/4" | 26" | 12" | 0.007" | Yes | Polyester Plastic | -40° to 250° | 0000000 | 00000 |
8"-10" | 1 1/4" | 36" | 12" | 0.007" | Yes | Polyester Plastic | -40° to 250° | 0000000 | 00000 |
11"-12" | 1 1/4" | 43" | 12" | 0.007" | Yes | Polyester Plastic | -40° to 250° | 0000000 | 00000 |
13"-15" | 1 1/4" | 52" | 12" | 0.007" | Yes | Polyester Plastic | -40° to 250° | 0000000 | 00000 |
16"-18" | 1 1/4" | 62" | 12" | 0.007" | Yes | Polyester Plastic | -40° to 250° | 0000000 | 00000 |
Yellow with Black Message | |||||||||
5/8"-1" | 1/2" | 5" | 8" | 0.007" | Yes | Polyester Plastic | -40° to 250° | 0000000 | 0000 |
1 1/8"-2 1/2" | 3/4" | 9" | 8" | 0.007" | Yes | Polyester Plastic | -40° to 250° | 0000000 | 00000 |
2 1/2"-4 3/4" | 1 1/4" | 17" | 12" | 0.007" | Yes | Polyester Plastic | -40° to 250° | 0000000 | 00000 |
5"-7 7/8" | 1 1/4" | 26" | 12" | 0.007" | Yes | Polyester Plastic | -40° to 250° | 0000000 | 00000 |
8"-10" | 1 1/4" | 36" | 12" | 0.007" | Yes | Polyester Plastic | -40° to 250° | 0000000 | 00000 |
11"-12" | 1 1/4" | 43" | 12" | 0.007" | Yes | Polyester Plastic | -40° to 250° | 0000000 | 00000 |
13"-15" | 1 1/4" | 52" | 12" | 0.007" | Yes | Polyester Plastic | -40° to 250° | 0000000 | 00000 |
16"-18" | 1 1/4" | 62" | 12" | 0.007" | Yes | Polyester Plastic | -40° to 250° | 0000000 | 00000 |
Made-to-Order Reflective Pipe Markers
![](/prerenderstable/mvPRE/contents/gfx/imagecache/209/2094n15p1-i02c-master1563234023@halfx_636988287135174127.png?ver=imagenotfound)
Specify the message you need to label the contents of a pipe in low-light conditions (two lines maximum, up to 50 characters per line, including spaces). Apply these markers directly onto clean, dry pipes.
For technical drawings and 3-D models, click on a part number.
For Pipe OD | Character Ht. | Ht. | Wd. | Thick. | Flow-Direction Arrow | Material | Temp. Range, °F | Pkg. Qty. | Pkg. | |
Made to Order (English, English/Spanish, Spanish) | ||||||||||
---|---|---|---|---|---|---|---|---|---|---|
Blue with White Message | ||||||||||
3/4"-2 1/4" | 3/4" | 1" | 8" | 0.003" | No | Vinyl Plastic | -40° to 170° | 10 | 0000000 | 000000 |
2 1/2"-7 7/8" | 1 3/4" | 2 1/4" | 13" | 0.003" | No | Vinyl Plastic | -40° to 170° | 10 | 0000000 | 00000 |
Green with White Message | ||||||||||
3/4"-2 1/4" | 3/4" | 1" | 8" | 0.003" | No | Vinyl Plastic | -40° to 170° | 10 | 0000000 | 00000 |
2 1/2"-7 7/8" | 1 3/4" | 2 1/4" | 13" | 0.003" | No | Vinyl Plastic | -40° to 170° | 10 | 0000000 | 00000 |
Orange with Black Message | ||||||||||
3/4"-2 1/4" | 3/4" | 1" | 8" | 0.003" | No | Vinyl Plastic | -40° to 170° | 10 | 0000000 | 00000 |
2 1/2"-7 7/8" | 1 3/4" | 2 1/4" | 13" | 0.003" | No | Vinyl Plastic | -40° to 170° | 10 | 0000000 | 00000 |
Red with White Message | ||||||||||
3/4"-2 1/4" | 3/4" | 1" | 8" | 0.003" | No | Vinyl Plastic | -40° to 170° | 10 | 0000000 | 00000 |
2 1/2"-7 7/8" | 1 3/4" | 2 1/4" | 13" | 0.003" | No | Vinyl Plastic | -40° to 170° | 10 | 0000000 | 00000 |
Yellow with Black Message | ||||||||||
3/4"-2 1/4" | 3/4" | 1" | 8" | 0.003" | No | Vinyl Plastic | -40° to 170° | 10 | 0000000 | 00000 |
2 1/2"-7 7/8" | 1 3/4" | 2 1/4" | 13" | 0.003" | No | Vinyl Plastic | -40° to 170° | 10 | 0000000 | 00000 |
