    11 Products

    Rivet Assortments

    Image of Product. Installed. Front orientation. Contains Annotated, Border, MultipleImages. Rivets. Rivet Assortments.
    Image of Product. Front orientation. Rivets. Rivet Assortments.

    Installed

    Also known as pop and open-end rivets, use these to join materials together when you only have access to one side. Install with a blind rivet tool.
    No. of
    Pieces
    Rivets Included
    Material
    Container
    Type
    Each
    Steel Mandrel
    5851/8" Dia. for 0.063"-0.125" Material Thick. (100 Pieces)
    1/8" Dia. for 0.126"-0.187" Material Thick. (100 Pieces)
    1/8" Dia. for 0.188"-0.250" Material Thick. (100 Pieces)
    3/16" Dia. for 0.126"-0.250" Material Thick. (100 Pieces)
    3/16" Dia. for 0.251"-0.375" Material Thick. (100 Pieces)
    3/16" Dia. for 0.376"-0.500" Material Thick. (85 Pieces)    		AluminumPlastic Box97455A300000000


    Manual Tools for Blind Rivets

    Image of Product. Front orientation. Rivet Tools. Manual Tools for Blind Rivets, Style D.
    Image of Product. Style D with Plastic Case and Rivets. Front orientation. Rivet Tools. Manual Tools for Blind Rivets, Style D, Plastic case.

    Style D

    Style D with Plastic Case and

    Rivets

    Image of Specification. Front orientation. Contains Annotated. Rivet Tools. Manual Tools for Blind Rivets, Style D.

    Style D

    These tools have changeable nosepieces—use the nosepiece that matches your rivet's diameter. To install a rivet, insert the mandrel into the nosepiece of the tool. Place the rivet in the material and squeeze the handles. The tool pulls the mandrel through the rivet's body, creating a secure hold on both sides of the material, and breaks off the excess mandrel.
    Style D
    Image of Product. Front orientation. Rivet Tools. Manual Tools for Blind Rivets, Style D.
    Image of Product. Style D with Plastic Case and Rivets. Front orientation. Rivet Tools. Manual Tools for Blind Rivets, Style D, Plastic case.

    Style D with Plastic Case and

    Rivets

    Image of Specification. Front orientation. Contains Annotated. Rivet Tools. Manual Tools for Blind Rivets, Style D.
    Nose
    Dia.
    Lg.
    Lg.
    Includes
    Each
    3/4"1"9 1/2"25 aluminum with steel mandrel domed rivets for 0.020”-0.125” thickness (3/16” dia.)
    25 steel flush-mount rivets for 0.188”-0.250” thickness (1/8” dia.)
    50 aluminum domed rivets for 0.063”-0.125” thickness (1/8” dia.)
    50 steel domed rivets for 0.063”-0.125” thickness (1/8” dia.)
    50 steel domed rivets for 0.188”-0.250” thickness (1/8” dia.)
    Four nosepieces (3/32", 1/8", 5/32", and 3/16")
    Plastic case    		6659A23000000
    Rivet Tool Accessories and Replacement Parts
    Each
    Opening Spring6659A23300000
    Jaw Pusher6659A2340000
    ⅛" Nosepiece6659A2430000
    ³⁄₁₆" Nosepiece6659A2450000
    Retaining Screw for Jaw Pusher Spring6659A2370000
    Jaw (Two Jaw Parts)6659A2320000
    ⁵⁄₃₂" Nosepiece6659A2440000
    ³⁄₃₂" Nosepiece6659A2420000
    Jaw Pusher Spring6659A2350000
