About Roller Chain and Sprockets
More
Corrosion-Resistant ANSI Roller Chain and Links
This 304 stainless steel roller chain is more corrosion resistant than treated steel roller chain.
Connecting links are also known as master links. They're used to join the ends of a chain length. The side plate is easy to remove for attaching to a chain. Adding links are also known as roller links. They require two connecting links to join chain. Adding-and-connecting links are also known as half links and offset links. A combination of connecting and adding links, they can join chain that requires an odd number of links. For trade number 35 and up, the side plate is easy to remove for attaching them to chain.
For technical drawings and 3-D models, click on a part number.
 Chain |  Connecting Link |  Adding Link |
 Adding-and-Connecting Link |  |
| Roller Chain Trade No. | Pitch | Roller Dia. | Roller Wd. | Working Load, lbs. | Lengths, ft. | Per Ft. | |
304 Stainless Steel  | |||||||
|---|---|---|---|---|---|---|---|
| 50-SS | 5/8" | 0.400" | 3/8" | 150 | 1-20, 50, 100 | 0000000 | 000000 |
| Roller Chain Trade No. | Pitch | Roller Dia. | Roller Wd. | Working Load, lbs. | Each | |
304 Stainless Steel | ||||||
|---|---|---|---|---|---|---|
| 50-SS | 5/8" | 0.400" | 3/8" | 150 | 0000000 | 00000 |
| Roller Chain Trade No. | Pitch | Roller Dia. | Roller Wd. | Working Load, lbs. | Each | |
304 Stainless Steel | ||||||
|---|---|---|---|---|---|---|
| 50-SS | 5/8" | 0.400" | 3/8" | 150 | 0000000 | 00000 |
| Roller Chain Trade No. | Pitch | Roller Dia. | Roller Wd. | Working Load, lbs. | Each | |
304 Stainless Steel | ||||||
|---|---|---|---|---|---|---|
| 50-SS | 5/8" | 0.400" | 3/8" | 150 | 0000000 | 000000 |
Ultra-Corrosion-Resistant ANSI Roller Chain and Links
Made of 316 stainless steel, this is our most corrosion-resistant chain.
Connecting links are also known as master links. They're used to join the ends of a chain length. The side plate is easy to remove for attaching to a chain. Adding-and-connecting links are also known as half links and offset links. They can join chain that requires an odd number of links. The side plate is easy to remove for attaching to chain.
For technical drawings and 3-D models, click on a part number.
Extended-Life Lightweight ANSI Roller Chain and Links
Plastic bushings as well as stainless steel pins and outer side plates give this chain a longer service life than other lightweight chain. Suitable for sound-sensitive and sanitary applications as well as wet conditions, it is also quiet-running and corrosion resistant.
Connecting links are also known as master links. They're used to join the ends of a chain length. The side plate is easy to remove for attaching to a chain.
For technical drawings and 3-D models, click on a part number.
Corrosion-Resistant Hollow-Pin ANSI Roller Chain and Links
Made of stainless steel, this chain has excellent corrosion resistance. Hollow-pin-style bushings let you add attachments without disassembling the chain.
Connecting links are also known as master links. They're used to join the ends of a chain length. The side plate is easy to remove for attaching to a chain. Adding-and-connecting links are also known as half links and offset links. They can join chain that requires an odd number of links. The side plate is easy to remove for attaching to chain.
For technical drawings and 3-D models, click on a part number.
