Electric Welding Positioners
Mount a workpiece on these motorized turntables for smooth and continuous 360° rotary motion useful for creating circular welds. Turntables tilt and lock in place at angles up to 90° in 15° increments. Once the workpiece is attached to the turntable or chuck, press the foot pedal to start the motor. As the part rotates, your hands are free to focus on the weld.
Load capacity is reduced as the table is tilted.
Positioners with a remote control box let you control the turntable cordlessly.
Use the optional three-jaw chuck to grip the outside of round items or the inside of pipe.
Base | Table Slots | ||||||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Speed Range, rpm | Max. Ground Current | Lg. | Wd. | O'all Ht. | Wt., lbs. | Tilt Increments | Rotation Range of Motion | No. of | Lg. | Wd. | Voltage | Frequency, Hz | Plug Type | Cord Lg., ft. | Features | Each | |
| 0.4-6 | 400A | 7" | 5" | 9" | 14 | 15° | 360° | 3 | 1 3/8" | 3/8" | 120V AC | 50, 60 | Three Prong | 8 | Grounding Stud | 00000000 | 000000000 |
| Optional Three-Jaw Chuck | 0000000 | Each | 0000000 |
Base | Table Holes | |||||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Speed Range, rpm | Max. Ground Current | Lg. | Wd. | O'all Ht. | Wt., lbs. | Tilt Increments | Rotation Range of Motion | No. of | Thread Size | Voltage | Frequency, Hz | Plug Type | Cord Lg., ft. | Features | Each | |
| 0-10 | 300A | 12" | 12" | 12" | 55 | 15° | 360° | 3, 9 | 5/16"-18, 1/2"-13 | 120V AC | 60 | Three Prong | 6 | Grounding Stud, Remote Control Box | 0000000 | 000000000 |
| Optional Three-Jaw Chuck | 0000000 | Each | 0000000 |
Base | Table Slots | ||||||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Speed Range Max., rpm | Max. Ground Current | Lg. | Wd. | O'all Ht. | Wt., lbs. | Tilt Increments | Rotation Range of Motion | No. of | Lg. | Wd. | Voltage | Frequency, Hz | Plug Type | Cord Lg., ft. | Features | Each | |
| 6 | 400A | 12 1/2" | 10 3/4" | 9 7/8" | 38 | 15° | 360° | 4 | 3 1/4" | 7/16" | 120V AC | 50, 60 | Three Prong | 8 | Grounding Stud | 00000000 | 000000000 |
| Optional Three-Jaw Chuck | 0000000 | Each | 0000000 |
Chuck | Base | ||||||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Speed Range, rpm | OD | Cap. | Max. Ground Current | Lg. | Wd. | O'all Ht. | Wt., lbs. | Tilt Increments | Rotation Range of Motion | Through Hole Dia. | Voltage | Frequency, Hz | Plug Type | Cord Lg., ft. | Features | Each | |
| 0-10 | 6" | 1/4"-3 1/2" | 300A | 14" | 12" | 12" | 60 | 15° | 360° | 1.5" | 120V AC | 60 | Three Prong | 6 | Grounding Stud, Remote Control Box | 0000000 | 000000000 |
| Optional Turntable | 0000000 | Each | 0000000 |
Fixturing Tables
Add components such as clamps, brackets, stops, rests, mounting plates, fixturing squares, risers, and V-blocks to build fixtures for welding and assembly.
For technical drawings and 3-D models, click on a part number.
Tables have removable plates that are precision ground to a tight tolerance for accurate positioning. Holes in a grid pattern and slots between the plates support a variety of clamps or workholding setups.
Overall | Slots | Plates | Holes | |||||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Lg. | Wd. | Ht. | Load Capacity, lbs. | No. of | Wd. | Ctr.-to-Ctr. | No. of | Wd. | Thick. | No. per Plate | Dia. | Ctr.-to-Ctr. | Flatness Tolerance | Material | Plate Material | Features | Each | |
| 38" | 22" | 36" | 2,000 | 2 | 1 3/4" | 8" | 3 | 6 1/4" | 5/8" | 57 | 5/8" | 2" | 0.012" per 3 ft. | Steel | Nitride-Coated Steel | Leveling Feet | 0000000 | 000000000 |
| 47" | 38" | 36" | 5,000 | 5 | 1 3/4" | 8" | 6 | 6 1/4" | 5/8" | 57 | 5/8" | 2" | 0.012" per 3 ft. | Steel | Nitride-Coated Steel | Leveling Feet | 0000000 | 00000000 |
| 78" | 38" | 36" | 5,500 | 9 | 1 3/4" | 8" | 10 | 6 1/4" | 5/8" | 57 | 5/8" | 2" | 0.012" per 3 ft. | Steel | Nitride-Coated Steel | Leveling Feet | 0000000 | 00000000 |
| Replacement Plate | 0000000 | Each | 0000000 |
Hold-down clamps secure work anywhere on table's surface. The arm slides up and down freely so the clamp can be quickly moved into position. Once in place, use the handle for final tightening.
Clamping Surface | Material | |||||||||
|---|---|---|---|---|---|---|---|---|---|---|
| Max. Clamping Clearance | Reach | Holding Capacity, lbs. | For Hole Size | Type | Material | Texture | Body | Handle | Each | |
| 8 1/2" | 4" | 400 | 5/8" | Swivel Pad | Steel | Smooth | Steel | Steel | 0000000 | 000000 |
Right-angle brackets hold work at a precise 90° angle.
Slots | Holes | ||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|
| Lg. | Wd. | Ht. | No. of | Lg. | Wd. | No. of | Dia. | Ctr.-to-Ctr. | Material | Each | |
| 3 5/8" | 1 3/16" | 1 5/8" | 1 | 2" | 5/8" | 1 | 5/8" | __ | Black-Oxide Steel | 0000000 | 000000 |
| 3 5/8" | 1 3/16" | 3 5/8" | 1 | 2" | 5/8" | 3 | 5/8" | 1" | Black-Oxide Steel | 0000000 | 00000 |
| 6" | 1 3/16" | 3 5/8" | 1 | 5" | 5/8" | 3 | 5/8" | 1" | Black-Oxide Steel | 0000000 | 00000 |
| 6" | 1 3/16" | 7 5/8" | 1 | 5" | 5/8" | 7 | 5/8" | 1" | Black-Oxide Steel | 0000000 | 00000 |
| 6" | 2" | 12" | 1 | 5" | 5/8" | 11 | 5/8" | 1" | Black-Oxide Steel | 0000000 | 000000 |
Straightedge stops mount to the table to create a reliable straightedge for alignment.
Toggle clamp mounting plates let you position a toggle clamp anywhere on the table.
Plate | Mounting Holes | |||||||
|---|---|---|---|---|---|---|---|---|
| Lg. | Wd. | Ht. | No. of | Thread Size | Stud Dia. | Material | Each | |
| 2 3/4" | 2 3/8" | 5/8" | 4, 4 | M5, M6 | 5/8" | Steel | 0000000 | 000000 |
 2" Lg.×2" Wd.×10" Ht. Fixturing Square |  4" Lg.×4" Wd.×4" Ht. Fixturing Square | |
 6" Lg.×2" Wd.×12" Ht. Fixturing Square | ||
 6" Lg.×2" Wd.×12" Ht. Fixturing Square |  6" Lg.×2" Wd.×12" Ht. Fixturing Square | |
Fixturing squares elevate workpieces or position clamps and other fixture components. Use them individually or stack multiple.
Slots | Holes | Tolerance | |||||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Lg. | Wd. | Ht. | No. of | Lg. | Wd. | Ctr.-to-Ctr. | Plate Thick. | No. of | Dia. | Ctr.-to-Ctr. (A) | Ctr.-to-Ctr. (B) | Wt., lbs. | Squareness per 4" | Parallel | Material | Each | |
| 2" | 2" | 10" | __ | __ | __ | __ | 1/2" | 20 | 5/8" | 1" | __ | 5 | 0.001" | 0.002" | Steel | 0000000 | 0000000 |
| 4" | 4" | 4" | 2 | 2" | 5/8" | 2" | 1/2" | 21 | 5/8" | 2" | 1 7/16" | 8 | 0.001" | 0.002" | Steel | 0000000 | 000000 |
| 4" | 4" | 8" | 2 | 2" | 5/8" | 2" | 1/2" | 39 | 5/8" | 2" | 1 7/16" | 13 | 0.001" | 0.002" | Steel | 0000000 | 000000 |
| 4" | 4" | 12" | 2 | 2" | 5/8" | 2" | 1/2" | 57 | 5/8" | 2" | 1 7/16" | 18 | 0.001" | 0.002" | Steel | 0000000 | 000000 |
| 6" | 2" | 12" | 2 | 4" | 5/8" | __ | 1/2" | 26 | 5/8" | 1" | 1" | 6.4 | 0.002" | 0.006" | Iron | 0000000 | 000000 |
Side clamps apply pressure to hold work from the side.
| Lg. | Ht. | Stud Dia. | Material | Spindle Material | Each | |
| 3 1/2" | 2" | 5/8" | Black-Oxide Steel | Aluminum | 0000000 | 000000 |
Risers hold components above the surface of the table. A 5/8” hole at the top lets you attach a component, such as a V-block, to the riser.
V-blocks support round material and raise it off the table. Pivoting V-blocks conform to the shape of your workpiece, so they're good for holding round workpieces of different diameters.
Fasteners connect components to each other or to the table.
Thread | Head | Drive | ||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Shoulder Lg. | Size | Lg. | Dia. | Ht. | Lg. | Size | Style | Material | Includes | Pkg. Qty. | Each | |
Shoulder Screw—5/8” Shoulder Dia. (-0.001” to 0”) | ||||||||||||
| 1/2" | 1/2"-13 | 3/4" | 7/8" | 3/8" | __ | 5/16" | Hex | Black-Oxide Steel | Nut, Washer | __ | 0000000 | 00000 |
| 3/4" | 1/2"-13 | 3/4" | 7/8" | 3/8" | __ | 5/16" | Hex | Black-Oxide Steel | Nut, Washer | __ | 0000000 | 0000 |
| 7/8" | 1/2"-13 | 3/4" | 7/8" | 3/8" | __ | 5/16" | Hex | Black-Oxide Steel | Nut, Washer | __ | 0000000 | 0000 |
| 1" | 1/2"-13 | 3/4" | 7/8" | 3/8" | __ | 5/16" | Hex | Black-Oxide Steel | Nut, Washer | __ | 0000000 | 0000 |
| 1 1/4" | 1/2"-13 | 3/4" | 7/8" | 3/8" | __ | 5/16" | Hex | Black-Oxide Steel | Nut, Washer | __ | 0000000 | 0000 |
Ball-Lock Screw—5/8” Stud Dia. | ||||||||||||
| __ | __ | __ | 7/8" | __ | 7/8"-1 1/8" | 1/4" | Hex | Steel | __ | __ | 0000000 | 00000 |
| Pkg. | ||||||||||||
| __ | __ | __ | 7/8" | __ | 7/8"-1 1/8" | 1/4" | Hex | Steel | __ | 12 | 0000000 | 000000 |
Portable Fixturing Tables
Foldable for transport and storage, use these tables as a sturdy work surface for welding, assembly, cutting, and other tasks around your facility. They have center slots for holding workpieces using C- and bar clamps, a tilting top, and rails on two sides that can be used as guides, stops, and clamping edges.
Use a connector plate (sold separately) to join two tables together for a larger work surface.
Drop-In Bar-Style Hold-Down Clamps for Workholding Tables
The base fits into holes on most workholding and welding tables for clamping anywhere on the work surface. The clamping arm slides freely along the bar for quick positioning. Use the handle for final tightening.
For technical drawings and 3-D models, click on a part number.
For Hole | |||||||
|---|---|---|---|---|---|---|---|
| Max. Clamping Clearance | Reach | Holding Capacity, lbs. | Size | Shape | Body Material | Each | |
| 8" | 4" | 650 | 16mm | Round | Steel | 0000000 | 000000 |
