21 Products

About Wire and Cable

Use For: Welding
600V AC: Bend and Stay
600V AC/DC: Flexible
Temperature Range: -55° to 220° F
Insulation: EPDM Rubber

This cable withstands abrasion, oil, and the rough conditions found in welding applications. It’s flame rated VW-1 to meet requirements for vertical flame testing.

Class K cable is for general purpose welding applications. It bends and stays in the position that you bend it.

Class M cable is more flexible and durable than Class K cable.

								Per Ft.
Wire Ga.	Stranded Wire Class	Strand Count	OD	Specifications Met	Choose an Outer Insulation Color	Length, ft.		1-249	250-Up
Stranded Wire
600V AC
8	K	182/30	0.27"	UL 2556 VW-1	Black, Red	10, 20, 25, 30, 50, 100, 250	0000000	00000	00000
6	K	260/30	0.3"	UL 2556 VW-1	Black, Red	10, 20, 25, 30, 50, 100, 250	0000000	0000	0000
4	K	364/30	0.33"	UL 2556 VW-1	Black, Red	10, 20, 25, 30, 50, 100, 250	0000000	0000	0000
2	K	624/30	0.42"	UL 2556 VW-1	Black, Red	10, 20, 25, 30, 50, 100, 250	0000000	0000	0000
1	K	767/30	0.48"	UL 2556 VW-1	Black, Red	10, 20, 25, 30, 50, 100, 250	0000000	0000	0000
1/0	K	975/30	0.53"	UL 2556 VW-1	Black, Red	10, 20, 25, 30, 50, 100, 250	0000000	0000	0000
2/0	K	1,196/30	0.57"	UL 2556 VW-1	Black, Red	10, 20, 25, 30, 50, 100, 250	0000000	0000	0000
3/0	K	1,547/30	0.62"	UL 2556 VW-1	Black, Red	10, 20, 25, 30, 50, 100, 250	0000000	00000	0000
4/0	K	1,950/30	0.69"	UL 2556 VW-1	Black, Red	10, 20, 25, 30, 50, 100, 250	0000000	00000	0000
600V AC/600V DC
2	M	1,482/34	0.42"	UL 2556 VW-1	Orange	10, 20, 25, 30, 50, 100, 250	0000000	0000	0000
1	M	1,843/34	0.49"	UL 2556 VW-1	Orange	10, 20, 25, 30, 50, 100, 250	0000000	0000	0000
1/0	M	2,337/34	0.53"	UL 2556 VW-1	Orange	10, 20, 25, 30, 50, 100, 250	0000000	0000	0000
2/0	M	2,886/34	0.59"	UL 2556 VW-1	Orange	10, 20, 25, 30, 50, 100, 250	0000000	0000	0000

Flame-Resistant Welding Cable

Use For: Outdoors, Welding
Flexible
Temperature Range: -55° to 190° F
Insulation: Polyethylene Plastic

This cable meets Mine Safety and Health Administration (MSHA) standards for flame resistance. It’s also flame rated VW-1 to meet requirements for preventing the spread of flames, based on a timed test with vertically suspended material. The insulation resists abrasion and chemicals.

								Per Ft.
Wire Ga.	Stranded Wire Class	Strand Count	OD	Outer Insulation Color	Specifications Met	Length, ft.		10-249	250-Up
Stranded Wire
600V AC/600V DC
6	M	660/34	0.37"	Orange	UL Listed, CSA Certified, UL 2556 VW-1	10, 20, 25, 30, 50, 100, 250	0000000	00000	00000
4	M	1,045/34	0.42"	Orange	UL Listed, CSA Certified, UL 2556 VW-1	10, 20, 25, 30, 50, 100, 250	0000000	0000	0000
2	M	1,634/34	0.48"	Orange	UL Listed, CSA Certified, UL 2556 VW-1	10, 20, 25, 30, 50, 100, 250	0000000	00000	0000
1	M	2,090/34	0.53"	Orange	UL Listed, CSA Certified, UL 2556 VW-1	10, 20, 25, 30, 50, 100, 250	0000000	00000	00000
1/0	M	2,597/34	0.58"	Orange	UL Listed, CSA Certified, UL 2556 VW-1	10, 20, 25, 30, 50, 100, 250	0000000	00000	00000
2/0	M	3,300/34	0.63"	Orange	UL Listed, CSA Certified, UL 2556 VW-1	10, 20, 25, 30, 50, 100, 250	0000000	00000	00000
3/0	M	4,214/34	0.7"	Orange	UL Listed, CSA Certified, UL 2556 VW-1	10, 20, 25, 30, 50, 100, 250	0000000	00000	00000
4/0	M	5,225/34	0.8"	Orange	UL Listed, CSA Certified, UL 2556 VW-1	10, 20, 25, 30, 50, 100, 250	0000000	00000	00000
