Switch-Off Lifting Magnets
Also known as permanent lifting magnets, these magnets have an on/off handle to engage and release the magnet. They have a lifting eye for attaching a hook or sling. Style B magnet includes a detachable vertical lifting eye that mounts to the side of the magnet to lift plates vertically. Style C magnet has a pivoting lifting eye for both horizontal and vertical lifting.
Style A and B handles lock in both the on and off positions to prevent accidental release. Style C handle locks in the on position only.
Note: Capacities listed are based on lifting flat, rigid metal that has a clean, smooth surface. If used on dirty, oily, thin, or curved surfaces, the capacities will be reduced. Do not use on metal that flexes.
Warning: Never use to lift people or items over people.
For technical drawings and 3-D models, click on a part number.
Magnets | ||||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
Lift Cap. @ Material Thick. | Replacement Handles | |||||||||||||
| Horizontal | Vertical | Cap. @ Dia. | Max. Material Lg. @ Material Thick. | Lg. | Wd. | Ht. | Lifting Eye Ht. | Handle Lg. | Max. Temp., °F | Specifications Met | Each | Each | ||
Style A— with Proof Test Certificate | ||||||||||||||
Steel | ||||||||||||||
| 180 lbs. @ 1/4" 250 lbs. @ 1/2" 250 lbs. @ 1" 250 lbs. @ 2" | __ | 125 lbs. @ 2" | 6 ft. @ 1/4" 8 ft. @ 1/2" 10 ft. @ 1" 10 ft. @ 2" | 4 1/2" | 2 1/2" | 5" | 1 3/8" | 4" | 180° | ASME B30.20 | 0000000 | 0000000 | 0000000 | 000000 |
| 270 lbs. @ 1/4" 600 lbs. @ 1/2" 800 lbs. @ 1" 800 lbs. @ 2" | __ | 400 lbs. @ 3" | 6 ft. @ 1/4" 8 ft. @ 1/2" 10 ft. @ 1" 10 ft. @ 2" | 7 3/4" | 3 1/2" | 8 3/4" | 2 3/8" | 8" | 180° | ASME B30.20 | 0000000 | 000000 | 0000000 | 000000 |
| 800 lbs. @ 1/2" 1,600 lbs. @ 1" 1,600 lbs. @ 2" | __ | 800 lbs. @ 4" | 8 ft. @ 1/2" 10 ft. @ 1" 10 ft. @ 2" | 10 3/4" | 4 3/4" | 8 3/4" | 3 1/2" | 9" | 180° | ASME B30.20 | 0000000 | 000000 | 0000000 | 000000 |
| 1,450 lbs. @ 1" 2,500 lbs. @ 2" | __ | 1,250 lbs. @ 5" | 10 ft. @ 1" 10 ft. @ 2" | 12 1/2" | 7" | 8 3/4" | 4 3/4" | 10 3/4" | 180° | ASME B30.20 | 0000000 | 00000000 | 0000000 | 000000 |
| 2,620 lbs. @ 2” 5,000 lbs. @ 3” | __ | 2,500 lbs. @ 14" | 10 ft. @ 2" 10 ft. @ 3” | 16 3/4" | 9 1/4" | 16 3/4" | 6" | 14 3/4" | 180° | ASME B30.20 | 0000000 | 00000000 | 0000000 | 000000 |
Style B— with Proof Test Certificate | ||||||||||||||
Steel | ||||||||||||||
| 670 lbs. @ 1/2" 1,000 lbs. @ 1" 1,000 lbs. @ 2" | 250 lbs. @ 1" | 1,000 lbs. @ 2" | 8 ft. @ 1/2" 10 ft. @ 1" 10 ft. @ 2" | 16 9/16" | 5 7/16" | 8" | 1 13/16" | 10 1/8" | 180° | ASME B30.20 | 0000000 | 00000000 | 0000000 | 000000 |
Style C— with Proof Test Certificate | ||||||||||||||
Steel | ||||||||||||||
| 150 lbs. @ 1/4" 150 lbs. @ 1/2" 150 lbs. @ 1" 150 lbs. @ 2" | 40 lbs. @ 1/4" | 75 lbs. @ 2" | 6 ft. @ 1/4" 8 ft. @ 1/2" 10 ft. @ 1" 10 ft. @ 2" | 5" | 2 1/2" | 10" | 2 1/4" | 2 1/2" | 180° | ASME B30.20 | 0000000 | 000000 | 0000000 | 00000 |
| 270 lbs. @ 1/4" 334 lbs. @ 1/2" 334 lbs. @ 1" 334 lbs. @ 2" | 75 lbs. @ 3/8" | 165 lbs. @ 4" | 6 ft. @ 1/4" 8 ft. @ 1/2" 10 ft. @ 1" 10 ft. @ 2" | 6 1/2" | 4" | 9 1/4" | 2 1/4" | 2 1/2" | 180° | ASME B30.20 | 0000000 | 000000 | 0000000 | 00000 |
| Each | ||
| 0000000 | 0000000 |
Pry-Off Lifting Magnets
Also known as permanent lifting magnets, these magnets hold a load until you pull the handle and pry the magnet off. They have a lifting eye for attaching a hook or sling.
Style B magnets have a nonmarring roller release that prevents scraping and gouging the load as it is released.
Note: Capacities listed are based on lifting flat metal that has a clean, smooth surface. If used on dirty, oily, thin, or curved surfaces, the capacities will be reduced.
Warning: Never use to lift people or items over people.
For technical drawings and 3-D models, click on a part number.
| Style | Horizontal Lift Cap. @ Material Thick. | Max. Material Lg. @ Material Thick. | Lg. | Wd. | Ht. | Lifting Eye Ht. | Handle Lg. | Material | Max. Temp., °F | Includes | Specifications Met | Each | |
| A | 100 lbs. @ 1/16" 500 lbs. @ 1/4" 1,000 lbs. @ 1" | 3 ft. @ 1/16" 4 ft. @ 1/4" 6 ft. @ 1" | 9 1/2" | 6 1/2" | 3 1/4" | 1 3/4" | 9" | Stainless Steel | 260° | Proof Test Certificate | __ | 0000000 | 0000000 |
| A | 150 lbs. @ 1/16" 750 lbs. @ 1/4" 1,500 lbs. @ 1" | 4 ft. @ 1/16" 6 ft. @ 1/4" 8 ft. @ 1" | 13 3/4" | 6 1/4" | 5" | 3 3/8" | 12" | Stainless Steel | 260° | Proof Test Certificate | __ | 0000000 | 000000 |
| A | 250 lbs. @ 1/16" 1,250 lbs. @ 1/4" 2,500 lbs. @ 1" | 5 ft. @ 1/16" 8 ft. @ 1/4" 12 ft. @ 1" | 16 1/4" | 6 1/4" | 6 1/4" | 3 3/4" | 14 1/2" | Stainless Steel | 260° | Proof Test Certificate | __ | 0000000 | 00000000 |
| B | 400 lbs. @ 1/4" 400 lbs. @ 1" 400 lbs. @ 2" | 6 ft. @ 1/4" 10 ft. @ 1" 10 ft. @ 2" | 7 3/4" | 7 1/4" | 6 3/4" | 2 7/8" | 16" | Stainless Steel | 300° | Proof Test Certificate | ASME B30.20 | 0000000 | 000000 |
| B | 900 lbs. @ 1/4" 1,000 lbs. @ 1" 1,000 lbs. @ 2" | 6 ft. @ 1/4" 10 ft. @ 1" 10 ft. @ 2" | 10 3/4" | 7 1/4" | 6 3/4" | 2 7/8" | 16" | Stainless Steel | 300° | Proof Test Certificate | ASME B30.20 | 0000000 | 000000 |
| B | 1,000 lbs. @ 1/4" 1,500 lbs. @ 1" 1,500 lbs. @ 2" | 6 ft. @ 1/4" 10 ft. @ 1" 10 ft. @ 2" | 14 3/4" | 7 1/4" | 6 3/4" | 2 7/8" | 16" | Stainless Steel | 300° | Proof Test Certificate | ASME B30.20 | 0000000 | 000000 |
| B | 1,100 lbs. @ 1/4" 3,000 lbs. @ 1" 3,000 lbs. @ 2" | 6 ft. @ 1/4" 10 ft. @ 1" 10 ft. @ 2" | 19 1/4" | 10 1/2" | 7" | 2 7/8" | 16" | Stainless Steel | 300° | Proof Test Certificate | ASME B30.20 | 0000000 | 00000000 |
Hand-Held Magnetic Lifters
Easily grab iron and steel fasteners, small sheets, and other parts from work areas, bins, and hard-to-reach places.
Style J has an easy-grip handle. Slide-on shields let you cover the magnet when not in use.
Styles K and L have a lifting eye for attaching a hook, rope, or chain to lower magnets into hard-to-reach spaces.
Styles M and N are also known as blueprint holders.
Warning: Never use to lift people or items over people.
Overall | |||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|
| Style | Capacity, lbs. | Dia. | Lg. | Wd. | Ht. | Eye Dia. | Material | Material Orientation | Includes | Each | |
Pull Lever | |||||||||||
| A | 4 | 3 1/2" | __ | __ | 8" | __ | Plastic | Horizontal, Vertical | __ | 0000000 | 000000 |
| A | 4 | 3 1/2" | __ | __ | 28" | __ | Plastic | Horizontal, Vertical | __ | 0000000 | 00000 |
| B | 2 | __ | 4 3/4" | 1 3/4" | 9 1/4" | __ | Plastic | Horizontal, Vertical | __ | 0000000 | 00000 |
| B | 2 | __ | 4 3/4" | 1 3/4" | 9 1/4" | __ | Stainless Steel | Horizontal, Vertical | __ | 0000000 | 000000 |
| B | 2 | __ | 4 3/4" | 1 3/4" | 32 1/2" | __ | Plastic | Horizontal, Vertical | __ | 0000000 | 00000 |
| B | 4 | __ | 4 3/4" | 3 1/4" | 9 1/4" | __ | Plastic | Horizontal, Vertical | __ | 0000000 | 00000 |
| B | 6 | __ | 6 1/4" | 4 3/4" | 9 1/4" | __ | Plastic | Horizontal, Vertical | __ | 0000000 | 000000 |
| C | 9 | 4 1/2" | __ | __ | 9" | __ | Plastic | Horizontal, Vertical | __ | 00000000 | 00000 |
| C | 9 | 4 1/2" | __ | __ | 19 3/4" | __ | Plastic | Horizontal, Vertical | __ | 00000000 | 000000 |
| D | 16 | 3 1/2" | __ | __ | 8 1/2" | __ | __ | Horizontal, Vertical | __ | 0000000 | 00000 |
| D | 25 | 5" | __ | __ | 9 1/4" | __ | __ | Horizontal, Vertical | __ | 0000000 | 00000 |
| E | 35 | __ | 4 1/8" | 2 3/4" | 6" | __ | Plastic | Horizontal | __ | 00000000 | 000000 |
Pull Bar | |||||||||||
| F | 8 | 1" | 15" | __ | __ | __ | Steel | Horizontal, Vertical | __ | 0000000 | 00000 |
| F | 8 | 1" | 36" | __ | __ | __ | Steel | Horizontal, Vertical | __ | 0000000 | 000000 |
On/Off Switch | |||||||||||
| G | 60 | __ | 6" | 2" | 5" | __ | Steel | Horizontal | __ | 0000000 | 000000 |
| G | 100 | __ | 7 1/2" | 3 3/8" | 7 3/4" | __ | Steel | Horizontal | __ | 0000000 | 000000 |
Manual Pry | |||||||||||
| H | 80 | __ | 4 1/2" | 1 1/4" | 3 3/4" | __ | Steel | Horizontal | __ | 0000000 | 00000 |
| J | 100 | __ | 5 1/4" | 1" | 3 1/2" | __ | Plastic | Horizontal, Vertical | Slide-On Shields | 00000000 | 00000 |
| K | 100 | __ | 2" | 2" | 2 1/2" | 5/8" | Steel | Horizontal, Vertical | __ | 00000000 | 00000 |
| K | 150 | __ | 5" | 2" | 2 1/2" | 5/8" | Steel | Horizontal, Vertical | __ | 00000000 | 00000 |
| K | 225 | __ | 5" | 2" | 3 1/2" | 5/8" | Steel | Horizontal, Vertical | __ | 00000000 | 00000 |
| L | 100 | __ | 6" | 3/4" | 2 1/4" | 1/2" | Steel | Horizontal, Vertical | __ | 00000000 | 00000 |
| M | 20 | __ | 2 1/2" | 1 1/2" | 1 1/4" | __ | Steel | Horizontal, Vertical | __ | 00000000 | 00000 |
| M | 35 | __ | 2" | 1 3/4" | 1 1/2" | __ | Steel | Horizontal, Vertical | __ | 00000000 | 0000 |
| M | 40 | __ | 2 1/2" | 1 3/4" | 1 1/2" | __ | Steel | Horizontal, Vertical | __ | 00000000 | 0000 |
| M | 45 | __ | 3" | 2 1/2" | 1 1/2" | __ | Steel | Horizontal, Vertical | __ | 00000000 | 0000 |
| N | 16 | 1 1/2" | __ | __ | 1" | __ | Steel | Horizontal, Vertical | __ | 00000000 | 0000 |
| N | 65 | 2 3/4" | __ | __ | 1 1/2" | __ | Steel | Horizontal, Vertical | __ | 00000000 | 0000 |
