Starrett High-Accuracy Combination Squares
Replace your try square, miter square, depth gauge, height gauge, center-point finder, and level. The blade on these squares meets Fed. Spec. GGG-R-791H, which establishes uniform standards for accuracy, graduations, and size. Blades are labeled with numeric increments that are less than 1" for quick reading. All have wear-resistant etched markings.
Square head checks 90° angles. Center head identifies the center on pipes, rods, and shafts. Protractor head measures angles.
Satin-chrome blade finish is corrosion resistant and reduces glare. Hardened-steel heads are more durable and last longer than cast iron heads.
Blade with Square Head
Inch
Blade | Graduation | |||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Blade Lg. | Front Grad. Marks (Increments) | Back Grad. Marks (Increments) | Accuracy | Wd. | Thick. | Material | Color | Color | Mark Style | Head Lg. | Each | |
Cast Iron Head | ||||||||||||
Inch | ||||||||||||
| 4" | 32nds (4/32"), 64ths (8/64") | 8ths (1"), 16ths (1") | -0.002" to +0.004" | 5/8" | 1/16" | Satin-Chrome Steel | Silver | Black | Etched | 2 1/4" | 0000000 | 000000 |
Hardened Steel Head | ||||||||||||
Inch | ||||||||||||
| 4" | 32nds (4/32"), 64ths (8/64") | 8ths (1"), 16ths (1") | -0.002" to +0.004" | 5/8" | 1/16" | Satin-Chrome Steel | Silver | Black | Etched | 2 1/4" | 0000000 | 000000 |
| Replacement Lockbolt for Square and Center Heads | 0000000 | Each | 000000 |
Blade with Square Head and Center Head
Inch
Blade | Graduation | |||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Blade Lg. | Front Grad. Marks (Increments) | Back Grad. Marks (Increments) | Accuracy | Wd. | Thick. | Material | Color | Color | Mark Style | Head Lg. | Each | |
Cast Iron Heads | ||||||||||||
Inch | ||||||||||||
| 4" | 32nds (4/32"), 64ths (8/64") | 8ths (1"), 16ths (1") | -0.002" to +0.004" | 5/8" | 1/16" | Satin-Chrome Steel | Silver | Black | Etched | 2 1/4" | 0000000 | 0000000 |
Hardened Steel Heads | ||||||||||||
Inch | ||||||||||||
| 4" | 32nds (4/32"), 64ths (8/64") | 8ths (1"), 16ths (1") | -0.002" to +0.004" | 5/8" | 1/16" | Satin-Chrome Steel | Silver | Black | Etched | 2 1/4" | 0000000 | 000000 |
| Replacement Lockbolt for Square and Center Heads | 0000000 | Each | 000000 |
Blade with Square Head with Built-in Level and Scriber
Inch
Inch/Metric
Blade | Graduation | |||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Blade Lg. | Front Grad. Marks (Increments) | Back Grad. Marks (Increments) | Accuracy | Wd. | Thick. | Material | Color | Color | Mark Style | Head Lg. | Each | |
Cast Iron Head | ||||||||||||
Inch | ||||||||||||
| 6" | 32nds (4/32"), 64ths (8/64") | 8ths (1"), 16ths (1") | -0.002" to +0.004" | 3/4" | 5/64" | Steel | Silver | Black | Etched | 2 13/32" | 0000000 | 000000 |
| 6" | 32nds (4/32"), 64ths (8/64") | 8ths (1"), 16ths (1") | -0.002" to +0.004" | 3/4" | 5/64" | Satin-Chrome Steel | Silver | Black | Etched | 2 13/32" | 0000000 | 000000 |
| 6" | 32nds (4/32"), 64ths (8/64") | 50ths (1/10"), 100ths (1/10") | -0.002" to +0.004" | 3/4" | 5/64" | Satin-Chrome Steel | Silver | Black | Etched | 2 13/32" | 0000000 | 000000 |
| 12" | 32nds (4/32"), 64ths (8/64") | 8ths (1"), 16ths (1") | -0.0035" to +0.005" | 1" | 3/32" | Steel | Silver | Black | Etched | 4 1/2" | 0000000 | 00000 |
| 12" | 32nds (4/32"), 64ths (8/64") | 8ths (1"), 16ths (1") | -0.0035" to +0.005" | 1" | 3/32" | Satin-Chrome Steel | Silver | Black | Etched | 4 1/2" | 0000000 | 000000 |
| 12" | 32nds (4/32"), 64ths (8/64") | 50ths (1/10"), 100ths (1/10") | -0.0035" to +0.005" | 1" | 3/32" | Satin-Chrome Steel | Silver | Black | Etched | 4 1/2" | 0000000 | 000000 |
| 18" | 32nds (4/32"), 64ths (8/64") | 8ths (1"), 16ths (1") | -0.0035" to +0.006" | 1" | 3/32" | Satin-Chrome Steel | Silver | Black | Etched | 4 1/2" | 0000000 | 000000 |
| 24" | 32nds (4/32"), 64ths (8/64") | 8ths (1"), 16ths (1") | -0.0035" to +0.007" | 1" | 3/32" | Satin-Chrome Steel | Silver | Black | Etched | 4 1/2" | 0000000 | 000000 |
Inch/Metric | ||||||||||||
| 11 3/4"/300mm | 1/2 mm (10 mm), 32nds (4/32") | Millimeters (10 mm), 64ths (8/64") | -0.0035" to +0.005"/ -0.09 mm to +0.15 mm | 1" | 3/32" | Satin-Chrome Steel | Silver | Black | Etched | 4 1/2" | 0000000 | 000000 |
| 23 1/2"/600mm | 1/2 mm (10 mm), 32nds (4/32") | Millimeters (10 mm), 64ths (8/64") | -0.0035" to +0.007"/ -0.11 mm to +0.25 mm | 1" | 3/32" | Satin-Chrome Steel | Silver | Black | Etched | 4 1/2" | 0000000 | 000000 |
Hardened Steel Head | ||||||||||||
Inch | ||||||||||||
| 6" | 32nds (4/32"), 64ths (8/64") | 8ths (1"), 16ths (1") | -0.002" to +0.004" | 3/4" | 5/64" | Satin-Chrome Steel | Silver | Black | Etched | 2 13/32" | 0000000 | 000000 |
| 6" | 32nds (4/32"), 64ths (8/64") | 50ths (1/10"), 100ths (1/10") | -0.002" to +0.004" | 3/4" | 5/64" | Satin-Chrome Steel | Silver | Black | Etched | 2 13/32" | 0000000 | 000000 |
| 12" | 32nds (4/32"), 64ths (8/64") | 8ths (1"), 16ths (1") | -0.0035" to +0.005" | 1" | 3/32" | Satin-Chrome Steel | Silver | Black | Etched | 3 5/8" | 0000000 | 000000 |
| 12" | 32nds (4/32"), 64ths (8/64") | 50ths (1/10"), 100ths (1/10") | -0.0035" to +0.005" | 1" | 3/32" | Satin-Chrome Steel | Silver | Black | Etched | 3 5/8" | 0000000 | 000000 |
| 18" | 32nds (4/32"), 64ths (8/64") | 8ths (1"), 16ths (1") | -0.0035" to +0.006" | 1" | 3/32" | Satin-Chrome Steel | Silver | Black | Etched | 3 5/8" | 0000000 | 000000 |
| 24" | 32nds (4/32"), 64ths (8/64") | 8ths (1"), 16ths (1") | -0.0035" to +0.007" | 1" | 3/32" | Satin-Chrome Steel | Silver | Black | Etched | 3 5/8" | 0000000 | 000000 |
| 24" | 32nds (4/32"), 64ths (8/64") | 50ths (1/10"), 100ths (1/10") | -0.0035" to +0.007" | 1" | 3/32" | Satin-Chrome Steel | Silver | Black | Etched | 3 5/8" | 0000000 | 000000 |
Inch/Metric | ||||||||||||
| 11 3/4"/300mm | 1/2 mm (10 mm), 32nds (4/32") | Millimeters (10 mm), 64ths (8/64") | -0.0035" to +0.005"/ -0.09 mm to +0.15 mm | 1" | 3/32" | Satin-Chrome Steel | Silver | Black | Etched | 3 5/8" | 0000000 | 000000 |
| 23 1/2"/600mm | 1/2 mm (10 mm), 32nds (4/32") | Millimeters (10 mm), 64ths (8/64") | -0.0035" to +0.007"/ -0.11 mm to +0.25 mm | 1" | 3/32" | Satin-Chrome Steel | Silver | Black | Etched | 3 5/8" | 0000000 | 000000 |
Blade with Square Head with Built-in Level, Center Head, and Scriber
Inch
Blade | Graduation | |||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Blade Lg. | Front Grad. Marks (Increments) | Back Grad. Marks (Increments) | Accuracy | Wd. | Thick. | Material | Color | Color | Mark Style | Head Lg. | Each | |
Cast Iron Heads | ||||||||||||
Inch | ||||||||||||
| 6" | 32nds (4/32"), 64ths (8/64") | 8ths (1"), 16ths (1") | -0.002" to +0.004" | 3/4" | 5/64" | Satin-Chrome Steel | Silver | Black | Etched | 2 13/32" | 0000000 | 0000000 |
| 12" | 32nds (4/32"), 64ths (8/64") | 8ths (1"), 16ths (1") | -0.0035" to +0.005" | 1" | 3/32" | Satin-Chrome Steel | Silver | Black | Etched | 4 1/2" | 0000000 | 000000 |
| 12" | 32nds (4/32"), 64ths (8/64") | 50ths (1/10"), 100ths (1/10") | -0.0035" to +0.005" | 1" | 3/32" | Satin-Chrome Steel | Silver | Black | Etched | 4 1/2" | 0000000 | 000000 |
| 18" | 32nds (4/32"), 64ths (8/64") | 8ths (1"), 16ths (1") | -0.0035" to +0.006" | 1" | 3/32" | Satin-Chrome Steel | Silver | Black | Etched | 4 1/2" | 0000000 | 000000 |
| 24" | 32nds (4/32"), 64ths (8/64") | 8ths (1"), 16ths (1") | -0.0035" to +0.007" | 1" | 3/32" | Satin-Chrome Steel | Silver | Black | Etched | 4 1/2" | 0000000 | 000000 |
Hardened Steel Heads | ||||||||||||
Inch | ||||||||||||
| 6" | 32nds (4/32"), 64ths (8/64") | 8ths (1"), 16ths (1") | -0.002" to +0.004" | 3/4" | 5/64" | Satin-Chrome Steel | Silver | Black | Etched | 2 13/32" | 0000000 | 000000 |
| 12" | 32nds (4/32"), 64ths (8/64") | 8ths (1"), 16ths (1") | -0.0035" to +0.005" | 1" | 3/32" | Satin-Chrome Steel | Silver | Black | Etched | 3 5/8" | 0000000 | 000000 |
| 12" | 32nds (4/32"), 64ths (8/64") | 50ths (1/10"), 100ths (1/10") | -0.0035" to +0.005" | 1" | 3/32" | Satin-Chrome Steel | Silver | Black | Etched | 3 5/8" | 0000000 | 000000 |
| 18" | 32nds (4/32"), 64ths (8/64") | 8ths (1"), 16ths (1") | -0.0035" to +0.006" | 1" | 3/32" | Satin-Chrome Steel | Silver | Black | Etched | 3 5/8" | 0000000 | 000000 |
| 24" | 32nds (4/32"), 64ths (8/64") | 8ths (1"), 16ths (1") | -0.0035" to +0.007" | 1" | 3/32" | Satin-Chrome Steel | Silver | Black | Etched | 3 5/8" | 0000000 | 000000 |
Blade with Square Head with Built-in Level, Center Head, Protractor Head, and Scriber
Inch
Blade | Graduation | Cast Iron Heads | ||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Blade Lg. | Front Grad. Marks (Increments) | Back Grad. Marks (Increments) | Accuracy | Wd. | Thick. | Material | Color | Color | Mark Style | Head Lg. | Each | |
Inch | ||||||||||||
| 12" | 32nds (4/32"), 64ths (8/64") | 8ths (1"), 16ths (1") | -0.0035" to +0.005" | 1" | 3/32" | Steel | Silver | Black | Etched | 4 1/2" | 0000000 | 0000000 |
| 18" | 32nds (4/32"), 64ths (8/64") | 8ths (1"), 16ths (1") | -0.0035" to +0.006" | 1" | 3/32" | Steel | Silver | Black | Etched | 4 1/2" | 0000000 | 000000 |
| 24" | 32nds (4/32"), 64ths (8/64") | 8ths (1"), 16ths (1") | -0.0035" to +0.007" | 1" | 3/32" | Steel | Silver | Black | Etched | 4 1/2" | 0000000 | 000000 |
| Replacement Lockbolt for Square, Center, and Protractor Heads | 0000000 | Each | 00000 |
Blade with Square Head with Built-in Level, Center Head, Reversible Protractor Head, and Scriber
Inch
Inch/Metric
Blade | Graduation | |||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Blade Lg. | Front Grad. Marks (Increments) | Back Grad. Marks (Increments) | Accuracy | Wd. | Thick. | Material | Color | Color | Mark Style | Head Lg. | Each | |
Cast Iron Heads | ||||||||||||
Inch | ||||||||||||
| 12" | 32nds (4/32"), 64ths (8/64") | 8ths (1"), 16ths (1") | -0.0035" to +0.005" | 1" | 3/32" | Steel | Silver | Black | Etched | 4 1/2" | 0000000 | 0000000 |
| 12" | 32nds (4/32"), 64ths (8/64") | 50ths (1/10"), 100ths (1/10") | -0.0035" to +0.005" | 1" | 3/32" | Steel | Silver | Black | Etched | 4 1/2" | 0000000 | 000000 |
| 18" | 32nds (4/32"), 64ths (8/64") | 8ths (1"), 16ths (1") | -0.0035" to +0.006" | 1" | 3/32" | Steel | Silver | Black | Etched | 4 1/2" | 0000000 | 000000 |
| 24" | 32nds (4/32"), 64ths (8/64") | 8ths (1"), 16ths (1") | -0.0035" to +0.007" | 1" | 3/32" | Steel | Silver | Black | Etched | 4 1/2" | 0000000 | 000000 |
Inch/Metric | ||||||||||||
| 11 3/4"/300mm | 1/2 mm (10 mm), 32nds (4/32") | Millimeters (10 mm), 64ths (8/64") | -0.0035" to +0.005"/-0.09 mm to +0.15 mm | 1" | 3/32" | Steel | Silver | Black | Etched | 4 1/2" | 0000000 | 000000 |
| 23 1/2"/600mm | 1/2 mm (10 mm), 32nds (4/32") | Millimeters (10 mm), 64ths (8/64") | -0.0035" to +0.007"/-0.11 mm to +0.25 mm | 1" | 3/32" | Steel | Silver | Black | Etched | 4 1/2" | 0000000 | 000000 |
Hardened Steel Heads | ||||||||||||
Inch | ||||||||||||
| 12" | 32nds (4/32"), 64ths (8/64") | 8ths (1"), 16ths (1") | -0.0035" to +0.005" | 1" | 3/32" | Satin-Chrome Steel | Silver | Black | Etched | 3 5/8" | 0000000 | 000000 |
| 12" | 32nds (4/32"), 64ths (8/64") | 50ths (1/10"), 100ths (1/10") | -0.0035" to +0.005" | 1" | 3/32" | Satin-Chrome Steel | Silver | Black | Etched | 3 5/8" | 0000000 | 000000 |
| 18" | 32nds (4/32"), 64ths (8/64") | 8ths (1"), 16ths (1") | -0.0035" to +0.006" | 1" | 3/32" | Satin-Chrome Steel | Silver | Black | Etched | 3 5/8" | 0000000 | 000000 |
| 18" | 32nds (4/32"), 64ths (8/64") | 50ths (1/10"), 100ths (1/10") | -0.0035" to +0.006" | 1" | 3/32" | Satin-Chrome Steel | Silver | Black | Etched | 3 5/8" | 0000000 | 000000 |
| 24" | 32nds (4/32"), 64ths (8/64") | 8ths (1"), 16ths (1") | -0.0035" to +0.007" | 1" | 3/32" | Satin-Chrome Steel | Silver | Black | Etched | 3 5/8" | 0000000 | 000000 |
| 24" | 32nds (4/32"), 64ths (8/64") | 50ths (1/10"), 100ths (1/10") | -0.0035" to +0.007" | 1" | 3/32" | Satin-Chrome Steel | Silver | Black | Etched | 3 5/8" | 0000000 | 000000 |
Inch/Metric | ||||||||||||
| 11 3/4"/300mm | 1/2 mm (10 mm), 32nds (4/32") | Millimeters (10 mm), 64ths (8/64") | -0.0035" to +0.005"/-0.09 mm to +0.15 mm | 1" | 3/32" | Satin-Chrome Steel | Silver | Black | Etched | 3 5/8" | 0000000 | 000000 |
| 23 1/2"/600mm | 1/2 mm (10 mm), 32nds (4/32") | Millimeters (10 mm), 64ths (8/64") | -0.0035" to +0.007"/-0.11 mm to +0.25 mm | 1" | 3/32" | Satin-Chrome Steel | Silver | Black | Etched | 3 5/8" | 0000000 | 000000 |
| Replacement Lockbolt for Square, Center, and Protractor Heads | 0000000 | Each | 00000 |
Starrett High-Accuracy Combination Square Blades
Inch
Inch/Metric
Use these blades with Starrett High-Accuracy Combination Square Heads. They meet Fed. Spec. GGG-R-791H, which establishes uniform standards for accuracy, graduations, and size. Blades are labeled with numeric increments that are less than 1" for quick reading. All have wear-resistant etched markings.
Satin-chrome finish is corrosion resistant and reduces glare.
Graduation | ||||||||||
|---|---|---|---|---|---|---|---|---|---|---|
| Lg. | Front Graduation Marks (Numeric Increments) | Back Graduation Marks (Numeric Increments) | Accuracy | Wd. | Thick. | Color | Color | Mark Style | Each | |
Inch | ||||||||||
Satin-Chrome Steel | ||||||||||
| 4" | 32nds (4/32"), 64ths (8/64") | 8ths (1"), 16ths (1") | -0.002" to +0.004" | 5/8" | 1/16" | Silver | Black | Etched | 0000000 | 000000 |
| 4" | 32nds (4/32"), 64ths (8/64") | 50ths (1/10"), 100ths (1/10") | -0.002" to +0.004" | 5/8" | 1/16" | Silver | Black | Etched | 0000000 | 00000 |
| 6" | 32nds (4/32"), 64ths (8/64") | 8ths (1"), 16ths (1") | -0.002" to +0.004" | 3/4" | 5/64" | Silver | Black | Etched | 0000000 | 00000 |
| 6" | 32nds (4/32"), 64ths (8/64") | 50ths (1/10"), 100ths (1/10") | -0.002" to +0.004" | 3/4" | 5/64" | Silver | Black | Etched | 0000000 | 00000 |
| 12" | 32nds (4/32"), 64ths (8/64") | 8ths (1"), 16ths (1") | -0.0035" to +0.005" | 1" | 3/32" | Silver | Black | Etched | 0000000 | 00000 |
| 12" | 32nds (4/32"), 64ths (8/64") | 50ths (1/10"), 100ths (1/10") | -0.0035" to +0.005" | 1" | 3/32" | Silver | Black | Etched | 0000000 | 00000 |
| 24" | 32nds (4/32"), 64ths (8/64") | 8ths (1"), 16ths (1") | -0.0035" to +0.007" | 1" | 3/32" | Silver | Black | Etched | 0000000 | 000000 |
| 24" | 32nds (4/32"), 64ths (8/64") | 50ths (1/10"), 100ths (1/10") | -0.0035" to +0.007" | 1" | 3/32" | Silver | Black | Etched | 0000000 | 000000 |
| 36" | 32nds (4/32"), 64ths (8/64") | 8ths (1"), 16ths (1") | -0.0035" to +0.007" | 1" | 3/32" | Silver | Black | Etched | 0000000 | 000000 |
| 36" | 32nds (4/32"), 64ths (8/64") | 50ths (1/10"), 100ths (1/10") | -0.0035" to +0.007" | 1" | 3/32" | Silver | Black | Etched | 0000000 | 000000 |
Inch/Metric | ||||||||||
Satin-Chrome Steel | ||||||||||
| 11 3/4"/300mm | 1/2 mm (10 mm), 32nds (4/32") | Millimeters (10 mm), 64ths (8/64") | -0.0035" to +0.005"/-0.09 mm to +0.15 mm | 1" | 3/32" | Silver | Black | Etched | 0000000 | 00000 |
| 23 1/2"/600mm | 1/2 mm (10 mm), 32nds (4/32") | Millimeters (10 mm), 64ths (8/64") | -0.0035" to +0.007"/-0.11 mm to +0.25 mm | 1" | 3/32" | Silver | Black | Etched | 0000000 | 000000 |
Starrett High-Accuracy Combination Square Heads
Attach to Starrett High-Accuracy Combination Square Blades with the included lockbolts.
Square head checks 90° angles. Center head identifies the center on pipes, rods, and shafts. Protractor head measures angles.
Hardened-steel heads are more durable and last longer than cast iron heads.
Square Head
Center Head
Protractor Head
Protractor | |||||
|---|---|---|---|---|---|
| Component | For Blade Lgs. | Angle Measuring Range | Graduation Marks (Numeric Increments) | Each | |
Cast Iron | |||||
| Square Head | 4" | __ | __ | 0000000 | 000000 |
| Square Head with Built-in Level | 6" | __ | __ | 0000000 | 00000 |
| Square Head with Built-in Level | 12"-48" | __ | __ | 0000000 | 00000 |
| Center Head | 4" | __ | __ | 0000000 | 00000 |
| Center Head | 6" | __ | __ | 0000000 | 00000 |
| Center Head | 12"-48" | __ | __ | 0000000 | 00000 |
| Nonreversible Protractor Head with Built-in Level | 12"-48" | 0°-180° | 1° (10°) | 0000000 | 000000 |
| Reversible Protractor Head with Built-in Level | 12"-48" | 0°-180° | 1° (10°) | 0000000 | 000000 |
Hardened Steel | |||||
| Square Head | 4" | __ | __ | 0000000 | 00000 |
| Square Head with Built-in Level | 6" | __ | __ | 0000000 | 00000 |
| Square Head with Built-in Level | 12"-48" | __ | __ | 0000000 | 00000 |
| Center Head | 4" | __ | __ | 0000000 | 00000 |
| Center Head | 6" | __ | __ | 0000000 | 000000 |
| Center Head | 12"-48" | __ | __ | 0000000 | 00000 |
Starrett High-Accuracy Squares
These squares meet Fed. Spec. GGG-S-656-E, which establishes uniform standards for square accuracy to ensure reliable, repeatable angles.
Blade | ||||||||
|---|---|---|---|---|---|---|---|---|
| Lg. | Wd. | Thick. | Accuracy | Color | Container | Container Material | Each | |
Inch | ||||||||
Steel | ||||||||
| 1 1/2" × 1 1/2" | 1/2" × 17/32" | 3/64" × 1/4" | +0.0001" | Silver | Case | Wood | 0000000 | 0000000 |
| 3" × 2 3/8" | 47/64" × 7/8" | 1/16" × 13/32" | +0.0001" | Silver | Case | Wood | 0000000 | 000000 |
| 4 1/2" × 3 1/2" | 1 1/8" × 15/16" | 23/32" × 1/2" | +0.0001" | Silver | Case | Wood | 0000000 | 000000 |
| 6" × 4 5/16" | 1 5/16" × 1 1/16" | 5/64" × 1/2" | +0.0001" | Silver | Case | Wood | 0000000 | 000000 |
| 12" × 7" | 2" × 1 31/64" | 5/64" × 3/4" | +0.0002" | Silver | Case | Wood | 0000000 | 000000 |
