One-Time-Use Multiple-Point Temperature-Indicating Labels
Four-Point Horizontal
Six-Point Horizontal
Five-Point Vertical
Eight-Point Vertical
Five-Point Circular
Record incremental surface-temperature changes. The windows on these labels permanently turn black when the temperature reaches each temperature point. Labels are self-adhesive.
Store in a cool, dry place below 64° F with less than 50% humidity.
| Temperature Points, °F | Temperature Points, °C | Accuracy | Dia. | Ht. | Wd. | Pkg. Qty. | Pkg. | |
Horizontal Orientation | ||||||||
|---|---|---|---|---|---|---|---|---|
4 Points | ||||||||
| 100°, 125°, 150°, 175° | 38°, 52°, 66°, 79° | ±3%/±3% | __ | 7/8" | 1 3/4" | 5 | 0000000 | 000000 |
| 100°, 150°, 200°, 250° | 38°, 66°, 93°, 121° | ±3%/±3% | __ | 7/8" | 1 3/4" | 5 | 0000000 | 00000 |
| 125°, 150°, 170°, 200° | 52°, 66°, 79°, 93° | ±3%/±3% | __ | 7/8" | 1 3/4" | 5 | 0000000 | 00000 |
| 140°, 150°, 160°, 170° | 60°, 66°, 71°, 77° | ±3%/±3% | __ | 7/8" | 1 3/4" | 5 | 0000000 | 00000 |
| 150°, 200°, 250°, 300° | 66°, 93°, 121°, 149° | ±3%/±3% | __ | 7/8" | 1 3/4" | 5 | 0000000 | 00000 |
| 150°, 175°, 200°, 225° | 66°, 79°, 93°, 107° | ±3%/±3% | __ | 7/8" | 1 3/4" | 5 | 0000000 | 00000 |
| 150°, 160°, 170°, 180° | 66°, 71°, 77°, 82° | ±3%/±3% | __ | 7/8" | 1 3/4" | 5 | 0000000 | 00000 |
| 160°, 170°, 180°, 190° | 71°, 77°, 82°, 88° | ±3%/±3% | __ | 7/8" | 1 3/4" | 5 | 0000000 | 00000 |
| 170°, 180°, 190°, 200° | 77°, 82°, 88°, 93° | ±3%/±3% | __ | 7/8" | 1 3/4" | 5 | 0000000 | 00000 |
| 175°, 200°, 225°, 250° | 79°, 93°, 107°, 121° | ±3%/±3% | __ | 7/8" | 1 3/4" | 5 | 0000000 | 00000 |
| 180°, 190°, 200°, 210° | 82°, 88°, 93°, 99° | ±3%/±3% | __ | 7/8" | 1 3/4" | 5 | 0000000 | 00000 |
| 190°, 200°, 210°, 220° | 88°, 93°, 99°, 104° | ±3%/±3% | __ | 7/8" | 1 3/4" | 5 | 0000000 | 00000 |
| 200°, 210°, 220°, 230° | 93°, 99°, 104°, 110° | ±3%/±3% | __ | 7/8" | 1 3/4" | 5 | 0000000 | 00000 |
| 200°, 225°, 250°, 275° | 93°, 107°, 121°, 135° | ±3%/±3% | __ | 7/8" | 1 3/4" | 5 | 0000000 | 00000 |
| 200°, 250°, 300°, 350° | 93°, 121°, 149°, 177° | ±3%/±3% | __ | 15/16" | 1 3/4" | 10 | 0000000 | 00000 |
| 220°, 230°, 240°, 250° | 104°, 110°, 116°, 121° | ±3%/±3% | __ | 7/8" | 1 3/4" | 5 | 0000000 | 00000 |
| 225°, 250°, 275°, 300° | 107°, 121°, 135°, 149° | ±3%/±3% | __ | 7/8" | 1 3/4" | 5 | 0000000 | 00000 |
| 261°, 270°, 280°, 289° | 127°, 132°, 138°, 143° | ±3%/±3% | __ | 7/8" | 1 3/4" | 10 | 0000000 | 00000 |
| 270°, 280°, 290°, 300° | 132°, 138°, 143°, 149° | ±3%/±3% | __ | 7/8" | 1 3/4" | 5 | 0000000 | 00000 |
| 300°, 309°, 320°, 331° | 149°, 154°, 160°, 166° | ±3%/±3% | __ | 7/8" | 1 3/4" | 10 | 0000000 | 00000 |
| 330°, 340°, 350°, 360° | 166°, 171°, 177°, 182° | ±3%/±3% | __ | 15/16" | 1 3/4" | 10 | 0000000 | 00000 |
6 Points | ||||||||
| 111°, 115°, 120°, 129°, 140°, 144° | 44°, 46°, 49°, 54°, 60°, 62° | ±3%/±3% | __ | 7/16" | 1 1/4" | 10 | 0000000 | 0000 |
Vertical Orientation | ||||||||
5 Points | ||||||||
| 99°, 104°, 109°, 115°, 120° | 37°, 40°, 43°, 46°, 49° | ±3%/±3% | __ | 1 1/2" | 11/16" | 10 | 0000000 | 00000 |
| 120°, 129°, 140°, 149°, 160° | 49°, 54°, 60°, 65°, 71° | ±3%/±3% | __ | 1 1/2" | 11/16" | 10 | 0000000 | 00000 |
| 480°, 489°, 500°, 536°, 554° | 249°, 254°, 260°, 285°, 290° | ±3%/±3% | __ | 1 1/2" | 11/16" | 10 | 0000000 | 00000 |
8 Points | ||||||||
| 99°, 104°, 109°, 115°, 120°, 129°, 140°, 149° | 37°, 40°, 43°, 46°, 49°, 54°, 60°, 65° | ±3%/±3% | __ | 2" | 11/16" | 10 | 0000000 | 00000 |
Circular Orientation | ||||||||
5 Points | ||||||||
| 105°, 110°, 115°, 120°, 130° | 40°, 43°, 46°, 49°, 54° | ±3%/±3% | 9/16" | __ | __ | 5 | 0000000 | 0000 |
| 140°, 150°, 160°, 170°, 180° | 60°, 65°, 71°, 77°, 82° | ±3%/±3% | 9/16" | __ | __ | 5 | 0000000 | 0000 |
| 190°, 200°, 210°, 220°, 230° | 88°, 93°, 99°, 104°, 110° | ±3%/±3% | 9/16" | __ | __ | 5 | 0000000 | 0000 |
| 240°, 250°, 260°, 270°, 280° | 116°, 121°, 127°, 132°, 138° | ±3%/±3% | 9/16" | __ | __ | 5 | 0000000 | 0000 |
| 290°, 300°, 310°, 320°, 330° | 143°, 149°, 154°, 160°, 166° | ±3%/±3% | 9/16" | __ | __ | 5 | 0000000 | 0000 |
| 340°, 350°, 360°, 370°, 380° | 171°, 177°, 182°, 188°, 193° | ±3%/±3% | 9/16" | __ | __ | 5 | 0000000 | 0000 |
| 390°, 400°, 410°, 420°, 435° | 199°, 204°, 210°, 216°, 224° | ±3%/±3% | 9/16" | __ | __ | 5 | 0000000 | 0000 |
| 450°, 465°, 480°, 490°, 500° | 232°, 241°, 249°, 254°, 260° | ±3%/±3% | 9/16" | __ | __ | 5 | 0000000 | 0000 |
One-Time-Use Single-Point Temperature-Indicating Labels
Temperature-Indicating Label
Temperature-Indicating Label with
Multiple-Exposure-Duration
Thresholds
Multiple-Exposure-Duration
Thresholds
See at a glance whether inventory has been exposed to high temperatures during shipping and storage. These labels are self-adhesive.
Labels without multiple exposure-duration thresholds have one window that turns black permanently when your surface heats to the temperature point. Store in a cool, dry place below 64° F with less than 50% humidity.
Labels with multiple exposure-duration thresholds have three windows that turn red permanently when your surface heats to the temperature point for brief, moderate, and prolonged periods of time. They won’t begin to monitor temperature changes until you pull their activation tab. Before activating, place them in an environment at least 9° F (5° C) below their temperature point for 30 minutes.
Exposure Time | ||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Temperature Point, °F | Temperature Point, °C | Accuracy | Ht. | Wd. | No. of Labels on Sheet | Brief | Moderate | Prolonged | Activation Method | Pkg. Qty. | Each | |
Vertical Orientation | ||||||||||||
| 100° | 38° | ±2% | 1/2" | 1/2" | 21 | __ | __ | __ | __ | __ | 00000000 | 000000 |
| 110° | 43° | ±2% | 1/2" | 1/2" | 21 | __ | __ | __ | __ | __ | 00000000 | 00000 |
| 120° | 48° | ±2% | 1/2" | 1/2" | 21 | __ | __ | __ | __ | __ | 00000000 | 00000 |
| 130° | 54° | ±2% | 1/2" | 1/2" | 21 | __ | __ | __ | __ | __ | 00000000 | 00000 |
| 140° | 60° | ±2% | 1/2" | 1/2" | 21 | __ | __ | __ | __ | __ | 00000000 | 00000 |
| 160° | 71° | ±2% | 1/2" | 1/2" | 21 | __ | __ | __ | __ | __ | 00000000 | 00000 |
| 180° | 82° | ±2% | 1/2" | 1/2" | 21 | __ | __ | __ | __ | __ | 00000000 | 00000 |
| 190° | 88° | ±2% | 1/2" | 1/2" | 21 | __ | __ | __ | __ | __ | 00000000 | 00000 |
| 200° | 93° | ±2% | 1/2" | 1/2" | 21 | __ | __ | __ | __ | __ | 00000000 | 00000 |
| 210° | 99° | ±2% | 1/2" | 1/2" | 21 | __ | __ | __ | __ | __ | 00000000 | 00000 |
| 220° | 104° | ±2% | 1/2" | 1/2" | 21 | __ | __ | __ | __ | __ | 00000000 | 00000 |
| 230° | 110° | ±2% | 1/2" | 1/2" | 21 | __ | __ | __ | __ | __ | 00000000 | 00000 |
| 240° | 116° | ±2% | 1/2" | 1/2" | 21 | __ | __ | __ | __ | __ | 00000000 | 00000 |
| 250° | 121° | ±2% | 1/2" | 1/2" | 21 | __ | __ | __ | __ | __ | 00000000 | 00000 |
| 260° | 127° | ±2% | 1/2" | 1/2" | 21 | __ | __ | __ | __ | __ | 00000000 | 00000 |
| 270° | 132° | ±2% | 1/2" | 1/2" | 21 | __ | __ | __ | __ | __ | 00000000 | 00000 |
| 280° | 138° | ±2% | 1/2" | 1/2" | 21 | __ | __ | __ | __ | __ | 00000000 | 00000 |
| 290° | 143° | ±2% | 1/2" | 1/2" | 21 | __ | __ | __ | __ | __ | 00000000 | 00000 |
| 300° | 149° | ±2% | 1/2" | 1/2" | 21 | __ | __ | __ | __ | __ | 00000000 | 00000 |
| 400° | 204° | ±2% | 1/2" | 1/2" | 21 | __ | __ | __ | __ | __ | 00000000 | 00000 |
| 500° | 260° | ±2% | 1/2" | 1/2" | 21 | __ | __ | __ | __ | __ | 00000000 | 00000 |
| Pkg. | ||||||||||||
Vertical Orientation with Multiple Exposure-Duration Thresholds | ||||||||||||
| 0° | -18° | ±1° C, ±2° F | 1 3/4" | 3/4" | 1 | 1hrs. | 3hrs. | 12hrs. | Pull-Tab, Temperature | 10 | 0000000 | 00000 |
| 32° | 0° | ±1° C, ±2° F | 1 3/4" | 3/4" | 1 | 2hrs. | 12hrs. | 48hrs. | Pull-Tab, Temperature | 10 | 0000000 | 00000 |
| 41° | 5° | ±1° C, ±2° F | 1 3/4" | 3/4" | 1 | 30min. | 2hrs. | 8hrs. | Pull-Tab, Temperature | 10 | 0000000 | 00000 |
| 46° | 8° | ±1° C, ±2° F | 1 3/4" | 3/4" | 1 | 2hrs. | 12hrs. | 48hrs. | Pull-Tab, Temperature | 10 | 0000000 | 00000 |
| 50° | 10° | ±1° C, ±2° F | 1 3/4" | 3/4" | 1 | 2hrs. | 12hrs. | 48hrs. | Pull-Tab, Temperature | 10 | 0000000 | 00000 |
| 68° | 20° | ±1° C, ±2° F | 1 3/4" | 3/4" | 1 | 2hrs. | 12hrs. | 48hrs. | Pull-Tab, Temperature | 10 | 0000000 | 00000 |
| 77° | 25° | ±1° C, ±2° F | 1 3/4" | 3/4" | 1 | 30min. | 2hrs. | 8hrs. | Pull-Tab, Temperature | 10 | 0000000 | 00000 |
| 86° | 30° | ±1° C, ±2° F | 1 3/4" | 3/4" | 1 | 30min. | 2hrs. | 8hrs. | Pull-Tab, Temperature | 10 | 0000000 | 00000 |
Temperature-Indicating "Hot" Labels
Avoid injury with these self-adhesive labels that indicate when pipes, ovens, and other machinery are too hot to touch. When your surface heats to the temperature point, these black labels display a red graphic with a red message “hot.” When the surface cools, the graphic and message disappear. Store at in a dry place at 70° F with less than 50% humidity. Shelf life is one year from date of shipment.
| Temperature Point, ° F | Temperature Point, ° C | Accuracy | Dia. | Pkg. Qty. | Pkg. | |
Horizontal Orientation | ||||||
|---|---|---|---|---|---|---|
1 Point | ||||||
| 122° | 50° | ±2° F/±1° C | 1 1/2" | 10 | 00000000 | 000000 |
