Search Results
Mounting Location Mounting Location |
|---|
|
Glass Door Windows with Frames
The glass is impact resistant and provides a clear, unobstructed view. UL listed for use in fire-rated doors.
Window Viewing | For Opening | Frame | ||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Wd. | Ht. | Wd. | Ht. | Glass Thick. | For Door Thick. | Material | Color | Glass Type | Specifications Met | Mounting Hardware Included | Each | |
| 3" | 33" | 5" | 35" | 3/16" | 1 3/4" | Primed Steel | Gray | Pyran | UL Listed | Yes | 0000000 | 0000000 |
| 4" | 25" | 6" | 27" | 3/16" | 1 3/4" | Primed Steel | Gray | Pyran | UL Listed | Yes | 0000000 | 000000 |
| 5" | 20" | 7" | 22" | 3/16" | 1 3/4" | Primed Steel | Gray | Pyran | UL Listed | Yes | 0000000 | 000000 |
| 7" | 7" | 9" | 9" | 3/16" | 1 3/4" | Primed Steel | Gray | Pyran | UL Listed | Yes | 0000000 | 000000 |
| 10" | 10" | 12" | 12" | 3/16" | 1 3/4" | Primed Steel | Gray | Pyran | UL Listed | Yes | 0000000 | 000000 |
Frames for Door Windows
Only one frame per door is required.
Window Viewing | For Opening | For Glass | Frame | ||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Wd. | Ht. | Wd. | Ht. | Wd. | Ht. | Thick. | For Door Thick. | Material | Color | Specifications Met | Mounting Hardware Included | Each | |
| 3" | 33" | 5" | 35" | 4" | 34" | 3/16", 1/4", 5/16" | 1 3/4" | Primed Steel | Gray | UL Listed | Yes | 000000 | 000000 |
| 4" | 25" | 6" | 27" | 5" | 26" | 3/16", 1/4", 5/16" | 1 3/4" | Primed Steel | Gray | UL Listed | Yes | 000000 | 00000 |
| 5" | 20" | 7" | 22" | 6" | 21" | 3/16", 1/4", 5/16" | 1 3/4" | Primed Steel | Gray | UL Listed | Yes | 000000 | 00000 |
| 10" | 10" | 12" | 12" | 11" | 11" | 3/16", 1/4", 5/16" | 1 3/4" | Primed Steel | Gray | UL Listed | Yes | 000000 | 00000 |
| 22" | 28" | 24" | 30" | 23" | 29" | 3/16", 1/4", 5/16" | 1 3/4" | Primed Steel | Gray | UL Listed | Yes | 000000 | 00000 |
| 24" | 30" | 26" | 32" | 25" | 31" | 3/16", 1/4", 5/16" | 1 3/4" | Primed Steel | Gray | UL Listed | Yes | 000000 | 000000 |
Shatter-Resistant Glass Door Windows with Frames
Also known as wired glass, the glass contains wire mesh that holds it together if broken. UL listed for use in fire-rated doors.
Window Viewing | For Opening | Frame | ||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Wd. | Ht. | Wd. | Ht. | Glass Thick. | For Door Thick. | Material | Color | Glass Type | Specifications Met | Mounting Hardware Included | Each | |
| 17 3/4" | 28 3/4" | 19 3/4" | 30 3/4" | 1/4" | 1 3/4" | Primed Steel | Gray | Wired | UL Listed | Yes | 0000000 | 0000000 |
| 17 3/4" | 32 3/4" | 19 1/4" | 34 3/4" | 1/4" | 1 3/4" | Primed Steel | Gray | Wired | UL Listed | Yes | 0000000 | 000000 |
| 21 3/4" | 28 3/4" | 23 3/4" | 30 3/4" | 1/4" | 1 3/4" | Primed Steel | Gray | Wired | UL Listed | Yes | 0000000 | 000000 |
| 21 3/4" | 32 3/4" | 23 3/4" | 34 3/4" | 1/4" | 1 3/4" | Primed Steel | Gray | Wired | UL Listed | Yes | 0000000 | 000000 |
| 21 3/4" | 44" | 23 3/4" | 46" | 1/4" | 1 3/4" | Primed Steel | Gray | Wired | UL Listed | Yes | 0000000 | 000000 |
| 22" | 28" | 24" | 30" | 1/4" | 1 3/4" | Primed Steel | Gray | Wired | UL Listed | Yes | 0000000 | 000000 |
| 24" | 30" | 26" | 32" | 1/4" | 1 3/4" | Primed Steel | Gray | Wired | UL Listed | Yes | 0000000 | 000000 |
| 33 3/4" | 32 3/4" | 35 3/4" | 34 3/4" | 1/4" | 1 3/4" | Primed Steel | Gray | Wired | UL Listed | Yes | 0000000 | 000000 |
Folding Security Gates for Windows
Secure windows and other small openings without sacrificing visibility and air circulation. These gates mount to the inside or outside of the window frame.
Expanded | Folded | Mount. | |||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|
| Max. Wd., ft. | Ht. | Wd. | Ht. | Material | Hasp Type | For Max. Padlock Shackle Dia. | For Use Outdoors | Fasteners Included | Hole Dia. | Each | |
| 4 | 25" | 7" | 31" | Galvanized Steel | Padlockable | 5/8" | Yes | No | 5/16" | 0000000 | 0000000 |
| 4 | 27" | 7" | 33" | Galvanized Steel | Padlockable | 5/8" | Yes | No | 5/16" | 0000000 | 000000 |
| 4 | 31" | 7" | 37" | Galvanized Steel | Padlockable | 5/8" | Yes | No | 5/16" | 0000000 | 000000 |
| 4 | 34" | 7" | 40" | Galvanized Steel | Padlockable | 5/8" | Yes | No | 5/16" | 0000000 | 000000 |
| 4 | 37" | 7" | 43" | Galvanized Steel | Padlockable | 5/8" | Yes | No | 5/16" | 0000000 | 000000 |
| 4 | 40" | 7" | 46" | Galvanized Steel | Padlockable | 5/8" | Yes | No | 5/16" | 0000000 | 000000 |
| 4 | 43" | 7" | 49" | Galvanized Steel | Padlockable | 5/8" | Yes | No | 5/16" | 0000000 | 000000 |
| 4 | 53" | 7" | 59" | Galvanized Steel | Padlockable | 5/8" | Yes | No | 5/16" | 0000000 | 000000 |
| 4 | 55" | 7" | 61" | Galvanized Steel | Padlockable | 5/8" | Yes | No | 5/16" | 0000000 | 000000 |
| 4 | 57" | 7" | 63" | Galvanized Steel | Padlockable | 5/8" | Yes | No | 5/16" | 0000000 | 000000 |
| 4 | 60" | 7" | 66" | Galvanized Steel | Padlockable | 5/8" | Yes | No | 5/16" | 0000000 | 000000 |
| 4 | 65" | 7" | 71" | Galvanized Steel | Padlockable | 5/8" | Yes | No | 5/16" | 0000000 | 000000 |
