42 Products

Clean Room Foam Mounting Tape

Repair ceiling tiles and pass-through windows in clean rooms with this foam tape with adhesive on both sides. The closed-cell foam restricts absorption.

Wd.	Lg., ft.	Overall Thick.	Material	Adhesive Location	Adhesive Type	Temperature Range, °F	Cell Type	Tensile Strength, psi	Adhesion to Steel, oz./in. wd.	Color	Environmental Rating		Each
1"	54	0.127"	Polyethylene Foam	Both Sides	Rubber	40° to 150°	Closed	25	95	White	Fed. Std. Class 1, ISO Class 3	0000000	000000
1 1/2"	54	0.127"	Polyethylene Foam	Both Sides	Rubber	40° to 150°	Closed	25	95	White	Fed. Std. Class 1, ISO Class 3	0000000	00000
2"	54	0.127"	Polyethylene Foam	Both Sides	Rubber	40° to 150°	Closed	25	95	White	Fed. Std. Class 1, ISO Class 3	0000000	00000

Clean Room Mounting Tape

Particle and residue free, this tape meets clean room requirements. It has adhesive on both sides.

Wd.	Lg., ft.	Overall Thick.	Material	Adhesive Location	Adhesive Type	Temperature Range, °F	Tensile Strength, lbs./in. wd.	Adhesion to Steel, oz./in. wd.	Color	Environmental Rating		Each
1/4"	108	0.0078"	Polyester Plastic	Both Sides	Acrylic	-10 to 175°	10	90	Clear	Fed. Std. Class 1, ISO Class 3	0000000	000000
1/2"	108	0.0078"	Polyester Plastic	Both Sides	Acrylic	-10 to 175°	10	90	Clear	Fed. Std. Class 1, ISO Class 3	0000000	00000
3/4"	108	0.0078"	Polyester Plastic	Both Sides	Acrylic	-10 to 175°	10	90	Clear	Fed. Std. Class 1, ISO Class 3	0000000	00000
1"	108	0.0078"	Polyester Plastic	Both Sides	Acrylic	-10 to 175°	10	90	Clear	Fed. Std. Class 1, ISO Class 3	0000000	00000
2"	108	0.0078"	Polyester Plastic	Both Sides	Acrylic	-10 to 175°	10	90	Clear	Fed. Std. Class 1, ISO Class 3	0000000	000000

Clean Room Repositionable Mounting Tape

This tape has adhesive on both sides and can be removed and repositioned without leaving residue behind. It meets clean room requirements.

Wd.	Lg., ft.	Overall Thick.	Material	Adhesive Location	Adhesive Type	Temperature Range, °F	Tensile Strength, lbs./in. wd.	Adhesion to Steel, oz./in. wd.	Color	Environmental Rating		Each
1/2"	108	0.0033"	Polyester Plastic	Both Sides	Acrylic	-10° to 140°	10	20	Clear	Fed. Std. Class 1, ISO Class 3	0000000	000000
3/4"	108	0.0033"	Polyester Plastic	Both Sides	Acrylic	-10° to 140°	10	20	Clear	Fed. Std. Class 1, ISO Class 3	0000000	00000
1"	108	0.0033"	Polyester Plastic	Both Sides	Acrylic	-10° to 140°	10	20	Clear	Fed. Std. Class 1, ISO Class 3	0000000	00000
2"	108	0.0033"	Polyester Plastic	Both Sides	Acrylic	-10° to 140°	10	20	Clear	Fed. Std. Class 1, ISO Class 3	0000000	000000

Clean Room Packaging Tape

For use in clean rooms, this tape won't leave residue behind. It comes sealed in a plastic bag.

Wd.	Lg., ft.	Overall Thick.	Material	Adhesive Type	Temp. Range, °F	Roll Dia.	Spool ID	Tensile Strength, lbs./in. wd.	Adhesion to Steel, oz./in. wd.	Environmental Rating	Choose a Color		Each
1/2"	108	0.0045"	Polyethylene Plastic	Acrylic	-10° to 175°	4 1/2"	3"	10	50	Fed. Std. Class 1, ISO Class 3	Blue, Clear, Red, White	0000000	000000
3/4"	108	0.0045"	Polyethylene Plastic	Acrylic	-10° to 175°	4 1/2"	3"	10	50	Fed. Std. Class 1, ISO Class 3	Blue, Clear, Red, White	0000000	00000
1"	108	0.0045"	Polyethylene Plastic	Acrylic	-10° to 175°	4 1/2"	3"	10	50	Fed. Std. Class 1, ISO Class 3	Blue, Clear, Red, White	0000000	00000
1 1/4"	108	0.0045"	Polyethylene Plastic	Acrylic	-10° to 175°	4 1/2"	3"	10	50	Fed. Std. Class 1, ISO Class 3	Blue, Clear, Red, White	0000000	00000
1 1/2"	108	0.0045"	Polyethylene Plastic	Acrylic	-10° to 175°	4 1/2"	3"	10	50	Fed. Std. Class 1, ISO Class 3	Blue, Clear, Red, White	0000000	00000
2"	108	0.0045"	Polyethylene Plastic	Acrylic	-10° to 175°	4 1/2"	3"	10	50	Fed. Std. Class 1, ISO Class 3	Blue, Clear, Red, White	0000000	00000
3"	108	0.0045"	Polyethylene Plastic	Acrylic	-10° to 175°	4 1/2"	3"	10	50	Fed. Std. Class 1, ISO Class 3	Blue, Clear, Red, White	0000000	00000

Clean Room Repair Tape

This tape has a high-bond adhesive that won't leave residue behind so it meets clean room requirements. Use it to mend and strengthen seams, joints, and surfaces.

Wd.	Lg., ft.	Overall Thick.	Material	Adhesive Type	Temperature Range, °F	Tensile Strength, lbs./in. wd.	Adhesion to Steel, oz./in. wd.	Environmental Rating	Choose a Color		Each
1/4"	108	0.007"	Polyethylene Plastic	Rubber	-10° to 175°	15	60	Fed. Std. Class 1, ISO Class 3	Black, Blue, Clear, Red, White	0000000	000000
1/2"	108	0.007"	Polyethylene Plastic	Rubber	-10° to 175°	15	60	Fed. Std. Class 1, ISO Class 3	Black, Blue, Clear, Red, White	0000000	00000
3/4"	108	0.007"	Polyethylene Plastic	Rubber	-10° to 175°	15	60	Fed. Std. Class 1, ISO Class 3	Black, Blue, Clear, Red, White	0000000	00000
1"	108	0.007"	Polyethylene Plastic	Rubber	-10° to 175°	15	60	Fed. Std. Class 1, ISO Class 3	Black, Blue, Clear, Red, White	0000000	00000
1 1/2"	108	0.007"	Polyethylene Plastic	Rubber	-10° to 175°	15	60	Fed. Std. Class 1, ISO Class 3	Black, Blue, Clear, Red, White	0000000	00000
2"	108	0.007"	Polyethylene Plastic	Rubber	-10° to 175°	15	60	Fed. Std. Class 1, ISO Class 3	Black, Blue, Clear, Red, White	0000000	00000
3"	108	0.007"	Polyethylene Plastic	Rubber	-10° to 175°	15	60	Fed. Std. Class 1, ISO Class 3	Black, Blue, Clear, Red, White	0000000	00000
4"	108	0.007"	Polyethylene Plastic	Rubber	-10° to 175°	15	60	Fed. Std. Class 1, ISO Class 3	Black, Blue, Clear, Red, White	0000000	00000

Clean Room Masking Tape

This vinyl tape meets clean room requirements and won't leave residue behind. Use it for sealing, masking, and hanging plastic sheeting. It comes sealed in a plastic bag.

Wd.	Lg., ft.	Overall Thick.	Material	Adhesive Type	Temperature Range, °F	Environmental Rating	Choose a Color		Each
1/4"	108	0.005"	Vinyl Plastic	Rubber	-10° to 175°	Fed. Std. Class 1, ISO Class 3	Black, Blue, Clear, Red, White	0000000	000000
1/2"	108	0.005"	Vinyl Plastic	Rubber	-10° to 175°	Fed. Std. Class 1, ISO Class 3	Black, Blue, Clear, Red, White	0000000	00000
3/4"	108	0.005"	Vinyl Plastic	Rubber	-10° to 175°	Fed. Std. Class 1, ISO Class 3	Black, Blue, Clear, Red, White	0000000	00000
1"	108	0.005"	Vinyl Plastic	Rubber	-10° to 175°	Fed. Std. Class 1, ISO Class 3	Black, Blue, Clear, Red, White	0000000	00000
1 1/2"	108	0.005"	Vinyl Plastic	Rubber	-10° to 175°	Fed. Std. Class 1, ISO Class 3	Black, Blue, Clear, Red, White	0000000	00000
2"	108	0.005"	Vinyl Plastic	Rubber	-10° to 175°	Fed. Std. Class 1, ISO Class 3	Black, Blue, Clear, Red, White	0000000	00000
3"	108	0.005"	Vinyl Plastic	Rubber	-10° to 175°	Fed. Std. Class 1, ISO Class 3	Black, Blue, Clear, Red, White	0000000	00000
4"	108	0.005"	Vinyl Plastic	Rubber	-10° to 175°	Fed. Std. Class 1, ISO Class 3	Black, Blue, Clear, Red, White	0000000	00000

Clean Room Marking Tape

Made to the highest standards for cleanliness, this tape meets clean room requirements. It releases minimal contaminants, leaves no residue behind, and comes sealed in a plastic bag. Use it to mark hazardous items or areas—it's striped with warning colors that won't fade over time.

Wd.	Lg., ft.	Overall Thick.	Material	Adhesive Type	Temperature Range, °F	Tensile Strength, lbs./in. wd.	Adhesion to Steel, oz./in. wd.	Environmental Rating	Choose a Color		Each
1/2"	54	0.009"	Vinyl Plastic	Rubber	-20° to 140°	30	20	Fed. Std. Class 1, ISO Class 3	Black with White Stripe, Black with Yellow Stripe, Red with White Stripe	0000000	000000
1"	54	0.009"	Vinyl Plastic	Rubber	-20° to 140°	30	20	Fed. Std. Class 1, ISO Class 3	Black with White Stripe, Black with Yellow Stripe, Red with White Stripe	0000000	00000
1 1/2"	54	0.009"	Vinyl Plastic	Rubber	-20° to 140°	30	20	Fed. Std. Class 1, ISO Class 3	Black with White Stripe, Black with Yellow Stripe, Red with White Stripe	0000000	00000
2"	54	0.009"	Vinyl Plastic	Rubber	-20° to 140°	30	20	Fed. Std. Class 1, ISO Class 3	Black with White Stripe, Black with Yellow Stripe, Red with White Stripe	0000000	00000
3"	54	0.009"	Vinyl Plastic	Rubber	-20° to 140°	30	20	Fed. Std. Class 1, ISO Class 3	Black with White Stripe, Black with Yellow Stripe, Red with White Stripe	0000000	00000

Clean Room Striped Floor Marking Tape

Designate aisles and work zones in your clean room. Individually bagged, this tape is made to the highest standards for cleanliness, releasing minimal contaminants and leaving no residue behind. The colored warning stripes resist fading over time.

Wd.	Lg, ft.	Thick.	For Use Outdoors	For Surface Texture	Material	Tape Type	Environmental Rating	Choose a Color		Each
2"	54	0.009"	No	Smooth	Vinyl	Clean Room, Marking	Fed. Std. Class 1, ISO Class 3	Black/Yellow, Green/White, Red/White	000000	000000
3"	54	0.009"	No	Smooth	Vinyl	Clean Room, Marking	Fed. Std. Class 1, ISO Class 3	Black/Yellow, Green/White, Red/White	000000	00000
