    Installation Type
    Installation Type
    Removable
    Drill Bushing Style
    Drill Bushing Style
    Serrated
    Smooth
    OD Increment
    OD Increment
    0.0001"
    Drill Bushing Type
    Drill Bushing Type
    SF
    Material
    Material
    Steel
    ID Increment
    ID Increment
    0.0001"
    Length Increment
    Length Increment
    1/16"
    Hardness
    Hardness
    Rockwell C61
    Maximum Length
    Maximum Length
    3"
    REACH (Registration, Evaluation, Authorization and Restriction of Chemicals)
    REACH (Registration,
    Evaluation, Authorization
    and Restriction of Chemicals)
    REACH Compliant
    RoHS (Restriction of Hazardous Substances)
    RoHS (Restriction of
    Hazardous Substances)
    RoHS Compliant
    Maximum ID
    Maximum ID
    2.2656"
    Maximum OD
    Maximum OD
    2.7500"
    Minimum ID
    Minimum ID
    0.0135"
    Minimum Length
    Minimum Length
    0.125"
    Minimum OD
    Minimum OD
    0.1562"
    DFARS (Defense Acquisition Regulations Supplement)
    DFARS (Defense Acquisition
    Regulations Supplement)
