Angle Grinder Cutoff Wheel
for Metal, 6" Diameter, 0.045" Thick, 10000 rpm Maximum Speed
2-D PDF
00000 each
4003A64
In stock
4003A64
00000 each
Each
Select a compatible file type: Parasolid
Available for Solidworks 2017 or newer.
Diameter | 6" |
Thickness | 0.045" |
Arbor Hole Size | 7/8" |
Maximum Rotation Speed | 10,000 rpm |
Grinding Wheel | |
Designation | Type 1 |
Shape | Straight |
Material | |
Abrasive | Aluminum Oxide |
Reinforcement | Fiberglass Mesh |
For Use On | Aluminum, Iron, Stainless Steel, Steel |
Grit | 60 |
Arbor Hole | Unthreaded |
Arbor Hole Shape | Round |
For Use With | Angle Grinders |
Grit Rating | Coarse |
Country of Origin | United States |
DFARS Compliance | Specialty Metals COTS-Exempt |
Export Control Classification Number (ECCN) | EAR99 |
REACH Compliance | Not Compliant |
RoHS Compliance | Not Compliant |
Schedule B Number | 680422.0000 |
U.S.–Mexico–Canada Agreement (USMCA) Qualifying | Yes |
Use these wheels to cut through metal such as iron, stainless steel, and steel. They are reinforced with two layers of fiberglass mesh. Choose coarser grit for fast cuts; choose finer grit for smooth cuts.
Warning: Use wheels that have a greater rpm rating than the no-load rpm of your tool.
The information in this 3-D model is provided for reference only.
