    Standard-Wall Stainless Steel Threaded Pipe Nipple and Pipe Assortment

    Type 316/316L, 1-1/2 NPT Male, 25 Pieces

    Image of Product. Front orientation. Contains Annotated. Standard-Wall Stainless Steel Threaded Pipe Nipple and Pipe Assortment, Type 316/316L, 1-1/2 NPT Male, 25 Pieces.
    0000000 each
    4967N133
    In stock
    4967N133
    0000000 each
    Each
    In stock
    Pressure Rating

    Low Pressure

    Wall Thickness Rating

    Standard

    Thread Type

    NPT

    Gender

    Male

    Material

    316/316L Stainless Steel

    Pipe Size

    1 1/2

    Number of Pieces

    25

    Pipe Schedule

    40

    Includes

    5 fully threaded 1 3/4" Lg. nipples
    20 threaded-on-both-ends nipples in the following lengths:
    2” (5 ea.), 2 1/2” (3 ea.), 3” (2 ea.), 3 1/2” (2 ea.), 4” (2 ea.), 4 1/2” (1 ea.), 5” (2 ea.), 5 1/2” (1 ea.), 6" (2 ea.)

    Connects To

    Pipe

    Construction

    Welded

    Fitting Connection

    Threaded

    Fitting Type

    Pipe

    For Fitting Material

    316 Stainless Steel, 316/316L Stainless Steel

    For Flange Material

    316 Stainless Steel, 316/316L Stainless Steel

    For Fitting Pressure Class

    150

    For Use With

    Air, Natural Gas, Oil, Steam, Water

    ID

    1.61"

    Shape

    Straight

    Length

    1 3/4", 2", 2 1/2", 3", 3 1/2", 4", 4 1/2", 5", 5 1/2", 6"

    OD

    1 29/32"

    Performance

    Chemical Resistant, Ultra Corrosion Resistant

    Specifications Met

    ASME B1.20.1, ASTM A733

    System of Measurement

    Inch

    Wall Thickness

    0.145"

    Country of Origin

    United States

    DFARS Compliance

    Specialty Metals COTS-Exempt

    Export Control Classification Number (ECCN)

    2B999

    REACH Compliance

    REACH (EC 1907/2006) (01/21/2025, 247 SVHC) Compliant

    RoHS Compliance

    RoHS 3 (2015/863/EU) Compliant

    Schedule B Number

    730722.1000

    U.S.–Mexico–Canada Agreement (USMCA) Qualifying

    Yes

    Keep a variety of lengths of pipe and pipe nipples on hand for areas where corrosion is a concern. These assortments have threaded pipe, which you can take apart as needed for maintenance and repair. They are designed for low-pressure applications. This pipe is welded, so it has a weld bead on the inside. Fully threaded pipe is also known as a close nipple; it is threaded on each end to the center.

    316/316L Stainless Steel—Pipe is the most corrosion resistant. It stands up to wet environments, just like 304 stainless steel pipe, but unlike 304 stainless steel, it will not corrode from salt water, chlorine solutions, and chemicals.
