Battery-Powered Mobile Lift Tables
Push the button and a hydraulic pump adjusts the load. Tables run on a motor that is powered by a sealed, maintenance-free battery and built-in charger. The NEMA rating only applies to the push-button control. The control has a self-retracting cord. A floor lock keeps the table stationary.
Post-style lift tables have posts that raise the tables straight up—no pinch points like scissor-style lift tables.
Warning: Do not roll or reposition while under load. Never use to lift people.
Wheel | ||||||||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Capacity, lbs. | Lg. | Wd. | Ht. | Elevation Speed, in./sec. | Duty Cycle | Batteries Included | Battery Charger Current, A | Battery Recharge Time, hrs. | Plug Type | Control Cord Lg., ft. | Tabletop Ga. | Material | Handle Ht. | Material | Dia. | Environmental Rating | Each | |
| 2,000 | 36" | 24" | 25"-37" | 3/4 | 15 cycles per hour | Yes | 10 | 6-8 | Three Prong | 4-10 | 7 | Steel | 24 1/2" | Plastic | 5" | NEMA 1 | 0000000 | 000000000 |
| 2,000 | 36" | 24" | 34"-52" | 3/4 | 15 cycles per hour | Yes | 10 | 6-8 | Three Prong | 4-10 | 7 | Steel | 33 1/2" | Plastic | 5" | NEMA 1 | 0000000 | 00000000 |
Wheel | ||||||||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Capacity, lbs. | Lg. | Wd. | Ht. | Elevation Speed, in./sec. | Duty Cycle | Batteries Included | Battery Charger Current, A | Battery Recharge Time, hrs. | Plug Type | Control Cord Lg., ft. | Tabletop Ga. | Material | Handle Ht. | Material | Dia. | Environmental Rating | Each | |
| 1,000 | 36" | 24" | 9 1/2"-33" | 2 1/4 | 15 cycles per hour | Yes | 5 | 6-8 | Three Prong | 2 1/2-8 | 7 | Steel | 35 1/2" | Phenolic Plastic | 5" | NEMA 1 | 0000000 | 000000000 |
| 1,000 | 48" | 24" | 9 1/2"-45" | 2 1/2 | 15 cycles per hour | Yes | 5 | 6-8 | Three Prong | 2 1/2-8 | 7 | Steel | 35 1/2" | Phenolic Plastic | 5" | NEMA 1 | 0000000 | 00000000 |
| 1,500 | 48" | 24" | 9 1/2"-45" | 1 3/4 | 15 cycles per hour | Yes | 5 | 6-8 | Three Prong | 2 1/2-8 | 7 | Steel | 35 1/2" | Phenolic Plastic | 5" | NEMA 1 | 0000000 | 00000000 |
| 1,500 | 48" | 36" | 9 1/2"-45" | 1 3/4 | 15 cycles per hour | Yes | 5 | 6-8 | Three Prong | 2 1/2-8 | 7 | Steel | 35 1/2" | Phenolic Plastic | 5" | NEMA 1 | 0000000 | 00000000 |
| Battery Voltage | Each | |
| 12V DC | 0000000 | 0000000 |
| Each | ||
| 0000000 | 0000000 |
| Each | ||
| 0000000 | 000000 |
Battery-Operated Lift Trucks with Platform
Platforms support material directly without an additional pallet. A hydraulic pump powered by a rechargeable battery raises and lowers loads with the push of a button. A charge indicator lets you know how much battery life is left. The push-button control has a self-retracting cord. Two swivel casters at the rear of the lift truck makes steering and pivoting easy. Once the truck is in place, engage the floor lock to lift and lower loads. They have nonmarking phenolic wheels that roll best on smooth surfaces.
Warning: Never use to lift people.
Platform | O'all | Base Leg | Wheel | ||||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| O'all Cap., lbs. | Ht. | Lg. | Wd. | Load Center | Lg. | Ht. | For Pallet Wd. | Handle Ht. | Inside Spread | Outside Spread | Wheel Configuration | Dia. | Material | Type | Specifications Met | Each | |
Steel Body | |||||||||||||||||
| 2,000 | 6"-5'8" | 24" | 27" | 15" | 3'2" | 6'11" | 26"-40" | 52" | 20" | 26" | Two Swivel Casters and Two Axle-Mounted Wheels | 5" | Phenolic Plastic | Solid | ASME B56.10 | 0000000 | 000000000 |
Battery-Operated Lift Trucks with Forks
A hydraulic pump powered by a rechargeable battery raises and lowers loads with the push of a button. A charge indicator lets you know how much battery life is left. The push-button control has a self-retracting cord. Two swivel casters at the rear of the lift truck make steering and pivoting easy. Once the truck is in place, engage the floor lock to lift and lower loads.
Counterbalanced bases have shorter legs for closer access to the load. A counterweight set (sold separately) is required.
Straddle bases have a greater distance between the legs for easier access to loads on pallets.
Polyurethane wheels are nonmarking, abrasion-resistant, and shock absorbing. Use them on all floor types, including areas with debris. Phenolic wheels are nonmarking and roll best on smooth surfaces, but can be noisy.
Warning: Never use to lift people.
Fork | O'all | Base Leg | |||||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| O'all Cap., lbs. | Lg. | Wd. | Min. Ht. | Max. Ht. | Outside Spread | Inside Spread | Load Center | Lg. | Ht. | For Pallet Wd. | Handle Ht. | Inside Spread | Outside Spread | Wheel Configuration | Wheel Material | Each | |
Steel Body | |||||||||||||||||
Counterbalanced Base | |||||||||||||||||
| 1,000 | 25" | 3" | 1" | 5'4" | 6 1/2"-24 1/2" | 1/2"-18 1/2" | 13" | 5'1" | 6'11" | 26"-32" | 38" | 20 1/4" | 26 1/4" | Two Swivel Casters and Two Axle-Mounted Wheels | Phenolic Plastic | 0000000 | 000000000 |
| 1,000 | 25" | 3" | 1" | 6'4" | 6 1/2"-24 1/2" | 1/2"-18 1/2" | 13" | 5'1" | 7'8" | 26"-32" | 38" | 20 1/4" | 26 1/4" | Two Swivel Casters and Two Axle-Mounted Wheels | Phenolic Plastic | 0000000 | 00000000 |
Straddle Base | |||||||||||||||||
| 2,000 | 42" | 3" | 1 1/2" | 5'4" | 6"-29" | 0"-23" | 24" | 4'1" | 6'11" | 26"-40" | 51" | 42" | 48" | Two Swivel Casters and Two Axle-Mounted Wheels | Polyurethane Rubber | 0000000 | 00000000 |
