74 Products

Plastic Spill-Control Pallets

Ramp For Style A

Ramp For Style B

Ramp For Style C

Ramp For Style E

These pallets have removable grating for easy cleaning.

Style B have a double-layer polyethylene bladder that deploys to capture overspills of up to 65 gallons. This one-time-use bladder is 65 1/2" Lg. × 66" Wd. when fully deployed.

Style D has recessed rings for secure drum storage. The grating can be removed with a forklift.

Pallets
									Max. Fork					Ramps
Style	For No. of 55-Gal. Drums	Cap., gal.	Weight Cap., lbs.	Lg.	Wd.	Ht.	Color	No. of Entry Points for Forklifts	Wd.	Ht.	Space Saving Features		Each	Weight Cap., lbs.		Each
Polyethylene Plastic—Meets EPA 40 CFR 264.175
A	2	30	5,000	51 1/2"	26 1/4"	6 1/2"	Yellow	__	__	__	Stackable	00000000	0000000	__	00000000	0000000
A	4	60	10,000	52 1/2"	51 1/2"	6 1/2"	Yellow	__	__	__	Stackable	00000000	000000	__	00000000	000000
A	6	85	10,000	78 1/4"	51 1/2"	6 1/2"	Yellow	__	__	__	Stackable	00000000	000000	__	00000000	000000
A	8	120	10,000	103"	51 1/2"	6 1/2"	Yellow	__	__	__	Stackable	00000000	000000	__	00000000	000000
B	1	75	1,500	30 1/2"	26"	5 3/4"	Yellow	__	__	__	__	0000000	000000	600	0000000	000000
B	2	85	3,000	52"	30 1/2"	5 3/4"	Yellow	__	__	__	__	0000000	000000	600	0000000	000000
B	4	110	6,000	56 3/4"	52"	5 3/4"	Yellow	__	__	__	__	0000000	000000	600	0000000	000000
C	1	60	800	40"	40"	12"	Yellow	2	7"	4"	Nestable, Stackable	00000000	000000	700	00000000	000000
C	2	65	3,000	53"	29"	16 1/2"	Orange	2	10 3/4"	4"	Nestable, Stackable	00000000	000000	__	000000	00
C	4	65	3,000	98 1/4"	25 1/4"	11 1/2"	Yellow	2	9"	3"	Nestable, Stackable	00000000	000000	__	000000	00
C	4	65	6,000	53"	53"	11 3/4"	Orange	4	14 3/4"	4"	Nestable, Stackable	00000000	000000	700	00000000	000000
D	4	85	6,500	51"	51"	17 1/2"	Red	4	7 1/2"	4"	Nestable, Stackable	00000000	000000	__	000000	00
Polyethylene Plastic
A	1	15	2,000	26 1/4"	26"	6 1/2"	Yellow	__	__	__	Stackable	00000000	000000	__	000000	00
E	2	22	3,000	49"	24"	6 1/2"	Yellow	2	6 31/32"	1"	Stackable	00000000	000000	1,000	00000000	000000
E	4	40	6,000	49"	48"	6 1/2"	Yellow	4	6 31/32"	1"	Stackable	00000000	000000	1,000	00000000	000000
E	6	75	12,000	72"	49"	6 1/2"	Yellow	2	6 31/32"	1"	Stackable	00000000	000000	1,000	00000000	000000
E	8	100	16,000	96"	49"	6 1/2"	Yellow	2	6 31/32"	1"	Stackable	00000000	000000	1,000	00000000	000000

Replacement Bladder for Style B, 26" Lg. × 4 1/2" Wd. × 4 1/2" Ht. Housing (Includes Inlet Fitting)

0000000

Each

0000000

Steel Spill-Control Pallets

Ramp (Sold Separately)

Made of 12-gauge steel, these pallets are more durable than plastic pallets. They have removable grating for easy cleaning.

Pallets
							Usable				Max. Fork					Ramps
	For No. of 55-Gallon Drums	Cap., gal.	Weight Cap., lbs.	Lg.	Wd.	Ht.	Lg.	Wd.	Color	No. of Entry Points for Forklifts	Wd.	Ht.	Space Saving Features		Each	Weight Cap., lbs.		Each
Powder-Coated Steel—Meets EPA 40 CFR 264.175
A	4	65	6,000	51"	51"	6 1/2"	50 1/2"	49"	Gray	__	__	__	Stackable	0000000	000000000	1,500	00000000	0000000
A	6	100	9,000	76 1/2"	51"	6 1/2"	74"	50 1/2"	Gray	__	__	__	Stackable	0000000	00000000	1,500	00000000	000000
B	2	65	2,000	51"	26"	16"	50 1/2"	24"	Gray	4	18"	4"	Stackable	0000000	000000	__	000000	00
B	4	65	4,000	51"	51"	10 1/2"	50 1/2"	49"	Gray	4	35"	4"	Stackable	0000000	00000000	1,500	00000000	000000
B	6	95	6,000	76 1/2"	51"	10 1/2"	74"	50 1/2"	Gray	4	28"	4"	Stackable	0000000	00000000	1,500	00000000	000000
Powder-Coated Steel
A	2	35	3,000	51"	26"	6 1/2"	50 1/2"	24"	Gray	__	__	__	Stackable	0000000	000000	1,500	00000000	000000

Plastic Spill-Control Pallets for UN-Compliant Tanks

Shown with Bucket (Sold Separately)

The 52" × 52" grating is sized to hold an IBC tank. The grating is removable for easy cleaning.

Add a bucket (sold separately) to catch spills and drips when dispensing from the tank. Bucket has a spill capacity of 3 gallons; spills larger than 3 gallons are channeled into the well in the bottom of the pallet.

					Usable						Max. Fork
Capacity, gal.	Weight Capacity, lbs.	Lg.	Wd.	Ht.	Lg.	Wd.	Grating Material	Color	Grating Color	No. of Entry Points for Forklifts	Wd.	Ht.	Space Saving Features		Each
Polyethylene Plastic—Meets EPA 40 CFR 264.175
350	8,500	62"	62"	28"	52"	52"	Polyethylene Plastic	Yellow	Black	2	7 1/4"	4"	Stackable	00000000	000000000

Black Polyethylene Plastic Bucket, 19 1/2" Lg. × 16" Wd. × 14 1/2" Ht.

00000000

Each

0000000

Spill-Control Trays

Styles A, B, D, and E have removable grating for easy cleaning. The grating on Style B also prevents contents from catching fire.

Style C is filled with polypropylene sorbent to prevent dripping liquids from splashing. It is not reusable.

Style D has a pour spout to make it easy to drain.

Style K can hold a 55-gallon drum. Its octagonal shape provides greater spill control than same-sized round containers.

Style A

Powder-Coated Steel
Capacity	Dia.	Ht.	Bottom ID	Grating Material	Color	Features		Each
32 fl. oz.	13 3/4"	1 1/4"	12"	Steel	Red	Removable Grating	0000000	000000

Style B

Powder-Coated Steel
Capacity	Dia.	Ht.	Bottom ID	Grating Material	Color	Specifications Met	Features		Each
1 gal.	9 1/2"	4 1/2"	7 7/8"	Steel	Red	FM Approved	Removable Grating	0000000	000000

Style C

				Bottom Inside
Capacity	Lg.	Wd.	Ht.	Lg.	Wd.	Color	Space Saving Features	Features		Each
Polyethylene Plastic
1 gal.	10 1/2"	10 1/2"	3"	10"	10"	Yellow	Stackable	Sorbent	00000000	000000

Style D

				Bottom Inside
Capacity	Lg.	Wd.	Ht.	Lg.	Wd.	Grating Material	Color	Grating Color	Space Saving Features	Features		Each
Polyethylene Plastic
1 3/4 gal.	17"	12"	4"	13 1/8"	8 1/2"	Polyethylene Plastic	White	Black	Stackable	Removable Grating, Pour Spout	00000000	000000
2 3/4 gal.	21"	17"	4"	17 1/8"	13 1/8"	Polyethylene Plastic	White	Black	Stackable	Removable Grating, Pour Spout	00000000	000000

Style E

				Bottom Inside
Capacity	Lg.	Wd.	Ht.	Lg.	Wd.	Grating Material	Color	Grating Color	Space Saving Features	Features		Each
Polyethylene Plastic
2 1/2 gal.	25"	21 1/2"	3"	20 3/4"	17 1/4"	Polyethylene Plastic	Yellow	Black	Stackable	Removable Grating	00000000	000000

Style F

				Bottom Inside
Capacity	Lg.	Wd.	Ht.	Lg.	Wd.	Space Saving Features		Each
Galvanized Steel
2 gal.	25 3/4"	17 3/4"	1"	25 5/8"	17 5/8"	Nestable	0000000	00000

Style G

				Bottom Inside
Capacity	Lg.	Wd.	Ht.	Lg.	Wd.	Color	Space Saving Features		Each
Polyethylene Plastic
3 1/2 gal.	36"	24"	1 1/2"	32"	20"	Black	Nestable	000000	000000
12 gal.	52 1/4"	16 1/4"	5"	48"	12"	Black	Nestable	000000	00000
24 gal.	52 1/4"	28 1/4"	5"	48"	24"	Black	Nestable	000000	00000

Style H

				Bottom Inside
Capacity	Lg.	Wd.	Ht.	Lg.	Wd.	Color	Space Saving Features		Each
Polyethylene Plastic
27 gal.	40"	40"	5"	36"	36"	Black	Nestable	0000000	0000000
30 gal.	52"	44"	4"	48"	40"	Black	Nestable	0000000	000000

Style J

				Bottom Inside
Capacity	Lg.	Wd.	Ht.	Lg.	Wd.	Color	Features		Each
Polyethylene Plastic
24 gal.	32 3/4"	21 1/4"	8"	30 3/4"	19 3/8"	Gray	Removable Platform	0000000	0000000

Style K

Polyethylene Plastic
Capacity	Dia.	Ht.	Bottom ID	Color	Space Saving Features		Each
19 gal.	34"	7 1/4"	26 1/4"	Yellow	Nestable	00000000	0000000

Spill-Control Berms

Prevent slipping hazards by surrounding equipment that might leak or create condensation. Cut pieces to length, secure to the floor with sealant, and seal edges with vinyl adhesive. Select additional straight and corner sections to create a berm to fit any size and shape needed.

Full Kit

Full Kit

Lg.	Wd.	Ht.	Material	Color	Includes		Each
50 ft.	5 1/2"	2"	Vinyl Plastic	Yellow	Two 25-ft. Lg. Straight Sections Four Corner Sections One Roll of 10-ft. Lg. Connecting Tape Six 10.3-oz. Tubes of Floor Sealant One 8-oz. Can of Vinyl Adhesive	0000000	000000000

Straight Section

Lg.	Wd.	Ht.	Material	Color		Each
15 ft.	5 1/2"	2"	Vinyl Plastic	Yellow	0000000	0000000

Corner Section

Lg.	Wd.	Ht.	Material	Color		Each
7 1/4"	5 1/2"	2"	Vinyl Plastic	Yellow	0000000	000000

Connecting Tape

Lg.	Wd.	Material	Color		Each
10 ft.	3"	Vinyl Plastic	Yellow	0000000	000000

Floor Sealant

Container
Type	Size, fl. oz.		Each
Tube	10.3	0000000	000000

Vinyl Adhesive

Container
Type	Size, fl. oz.		Each
Brush-Top Can	8	0000000	000000

Collapsible Spill-Control Berms

Collapse these large berms when not in use for easy storage. Supports are reinforced with steel and snap up to brace the walls when open.

				Bottom Inside				Collapsed
Capacity, gal.	Lg.	Wd.	Ht.	Lg.	Wd.	No. of Supports	Color	Lg.	Wd.	Ht.		Each
PVC-Coated Polyester Fabric
180	72"	72"	8"	61"	61"	12	Yellow	24"	20"	6"	0000000	0000000
500	10ft.	10ft.	9 3/4"	9ft.	9ft.	20	Yellow	28"	20"	6"	0000000	00000000
950	17 1/2ft.	13 1/2ft.	8"	16ft.	12ft.	24	Yellow	46"	34"	8"	0000000	00000000

Spill-Control Tubs

Lid For Style A (Sold Separately)

Style A have recessed rings to secure drums and “HAZARDOUS” stenciled on the side.

Style B has removable grating for easy cleaning.

Tubs
										Max. Fork					Lids
Style	For No. of 55-Gal. Drums	Cap., gal.	Wt. Cap., lbs.	Dia.	Lg.	Wd.	Ht.	Color	No. of Entry Points for Forklifts	Wd.	Ht.	Space Saving Features		Each		Each
Polyethylene Plastic—Meets EPA 40 CFR 264.175
A	1	60	900	30 1/4"	__	__	26"	Orange	2	8 1/4"	5 3/4"	__	0000000	0000000	0000000	0000000
A	2	100	1,800	__	58"	30 1/2"	22"	Orange	2	9 1/2"	5 3/4"	__	0000000	000000	0000000	000000
A	4	170	3,600	__	50 1/2"	50 1/2"	17 1/2"	Orange	__	__	__	__	0000000	000000	0000000	000000
B	2	130	1,200	__	60"	33 1/2"	25"	Yellow	2	11"	3 5/8"	Nestable	00000000	000000	000000	00

Collapsible Spill-Control Trays

A flexible alternative to spill-control pallets, these trays collapse when not in use for easy storage.

Style A have flexible sidewalls that spring back into shape. Drive over them to drop drums directly onto the mat.

						Bottom Inside			Collapsed
Style	For Number of 55-Gallon Drums	Capacity, gal.	Lg.	Wd.	Ht.	Lg.	Wd.	Color	Lg.	Wd.	Ht.	Features		Each
PVC-Coated Polyester Fabric
A	1	7 1/2	30"	30"	3"	24"	24"	Yellow	30"	8"	8"	Flexible Sidewalls	0000000	0000000
A	2	15	54"	30"	3"	48"	24"	Yellow	30"	10"	10"	Flexible Sidewalls	0000000	000000
A	4	30	54"	54"	3"	48"	48"	Yellow	30"	12"	12"	Flexible Sidewalls	0000000	000000
A	6	45	78"	54"	3"	72"	48"	Yellow	30"	16"	16"	Flexible Sidewalls	0000000	000000
B	1	30	36"	36"	6"	32"	32"	Yellow	34"	8 1/2"	10"	Carrying Strap	0000000	000000
B	2	60	48"	48"	6"	44"	44"	Yellow	45 1/2"	8"	7"	Carrying Strap	0000000	000000

Spill-Control Drum Dispensing Trucks

Shown in Dispensing Position

Spills while dispensing drums are contained in an internal sump, so you can transport the drum even after a spill occurs. A U-shaped platform with a recessed step and molded handles makes loading, unloading, and tipping to dispense easy. A strap secures the drum. In the dispensing position, the drum is held at a slight downward angle for better flow. The sump has two openings with garden hose threads for drainage.

Use trucks with polypropylene wheels on smooth surfaces. Trucks with rubber wheels absorb shock to roll on smooth and rough surfaces. Meets EPA 40 CFR 264.175 for secondary containment of hazardous waste.

For Container							O'all			Wheel
Type	Cap., gal.	Dia.	Ht.	Spill Cap., gal.	O'all Cap., lbs.	Dispensing Ht.	Lg.	Wd.	Ht.	Dia.	Material	Type		Each
Polyethylene Plastic
Fiber, Plastic, Steel	55	24"	34"	80	600	15"	26 1/2"	32 1/2"	69"	10"	Polypropylene Plastic	Solid	00000000	0000000
Fiber, Plastic, Steel	55	24"	34"	80	600	15"	26 1/2"	34 1/2"	69"	10"	Rubber	Solid	00000000	000000

Spill-Control Drum Dollies

Contain spills when moving and storing drums. Dollies have plastic wheels for use on smooth surfaces.

Dollies with solid, textured platforms have a drain spout to dump spills into a container. Add the optional handle to pull the dolly.

Dollies with solid, smooth platforms includes a drum container that rests on the dolly. It is nestable for easy storage. They meet EPA 40 CFR 264.175 for secondary containment of hazardous waste.

Dollies with perforated platforms have removable top grating deck for easy cleaning and a drain plug in the base. Wheel brakes prevent dollies from rolling. They meet EPA 40 CFR 264.175 for secondary containment of hazardous waste.

Dollies with four swivel casters have better maneuverability. Dollies with two swivel casters and two axle mounted wheels have better steering control.

Solid, Textured Platform

				O'all					Wheel
For Container Cap., gal.	O'all Cap., lbs.	Spill Cap., gal.	For Max. No. of Containers	Dia.	Ht.	Lip Ht.	Wheel Configuration	Caster Mount Type	Material	Type		Each
Yellow Polyethylene Plastic
55	500	11	1	34"	8 13/16"	5 3/4"	Four Swivel Casters	Replaceable	Plastic	Solid	0000000	0000000

Optional Steel T-Handle

0000000

Each

000000

Solid, Smooth Platform

Solid, Smooth Platform

					O'all						Wheel
For Container Cap., gal.	O'all Cap., lbs.	Spill Cap., gal.	For Max. No. of Containers	ID	Dia.	Ht.	Platform Ht.	Lip Ht.	Wheel Configuration	Caster Mount Type	Material	Type		Each
Yellow Polyethylene Plastic Body and Orange Enamel Steel
55	600	66	1	29"	32 1/2"	35"	4"	2 1/2"	Four Swivel Casters	Permanent	Polypropylene Plastic	Tread-on-Core	00000000	0000000

Perforated Platform

Perforated Platform

				O'all							Wheel
For Container Cap., gal.	O'all Cap., lbs.	Spill Cap., gal.	For Max. No. of Containers	Wd.	Lg.	Ht.	No. of Handles	Wheel Configuration	No. of Wheel Brakes	Caster Mount Type	Material	Type		Each
Yellow Polyethylene Plastic
55	500	57	2	29"	66 1/2"	43 7/8"	1	Two Swivel Casters and Two Axle-Mounted Wheels	2	Replaceable	Plastic	Solid	00000000	0000000
