Choose the right hinge based on mounting style, clearance, leaf thickness, knuckle length, and other important dimensions.
Spring Hinges
 |  |  |
With Mounting Holes | Without Mounting Holes | Self-Close |
Get a spring assist for opening doors and gates or closing them behind you.
Aluminum—One-third the weight of steel, these hinges are often used on enclosures, carts, and other equipment where you want to limit the load.
Self-Close—These hinges automatically swing doors closed.
Door Leaf | Frame Leaf | Mounting Holes | Self-Close—Fixed Closing Tension | |||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|
Ht. | Wd. | Ht. | Wd. | Overall Wd. | Pin Dia. | No. of | Fasteners Included | Range of Motion | Each | |||
With Mounting Holes | ||||||||||||
Aluminum | ||||||||||||
| 2 1/2" | 17/32" | 2 1/2" | 17/32" | 1 1/16" | 3/32" | 4 | No | 260° | 15205A111 | 000000 | ||
| 3 1/2" | 3/4" | 3 1/2" | 3/4" | 1 1/2" | 3/32" | 4 | No | 260° | 15205A112 | 0000 | ||
| 5" | 1" | 5" | 1" | 2" | 1/8" | 6 | No | 260° | 15205A113 | 00000 | ||
Without Mounting Holes | ||||||||||||
Aluminum | ||||||||||||
| 2 1/2" | 17/32" | 2 1/2" | 17/32" | 1 1/16" | 3/32" | — | — | 270° | 15205A313 | 00000 | ||
| 3 1/2" | 3/4" | 3 1/2" | 3/4" | 1 1/2" | 3/32" | — | — | 270° | 15205A314 | 0000 | ||
| 5" | 1" | 5" | 1" | 2" | 1/8" | — | — | 270° | 15205A315 | 00000 | ||
